DEMO MANUAL DC2017A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 2 C1, C2
2 1 C3
3 1 C4
4 2 C5, C7
5 1 C6
6 1 R1
7 1 R2
8 1 R3
9 1 R4
10 1 U1
Optional Demo Circuit Components
1 0 C8, C10, C18(OPT)
2 1 C9
3 0 C11(OPT)
4 0 C12, C13, C15, C16(OPT) CAP., OPTION, 1210
5 0 C14(OPT)
6 1 C17
7 0 D1, D2(OPT)
8 0 L1, L2(OPT)
9 0 R5, R9, R13(OPT)
10 2 R6, R7
11 0 R8(OPT)
12 1 R10
13 1 R11
14 1 R12
15 0 U2(OPT)
Hardware: For Demo Board Only
1 13 E1-E13
2 4 J1, J2, J3, J4
3 4 MH1-MH4
6
PART DESCRIPTION
CAP., CER., 4.7µF, X7R, 50V, 10%, 1210
CAP., CER., 0.22µF, X7R, 16V, 10%, 0603
CAP., CER., 0.01µF, X7R, 16V, 10%, 0603
CAP., CER., 22µF, X5R, 25V, 20%, 0805
CAP., TANT., 68µF, 25V, 20%, 7343
RES., 36.5k, 1/10W, 1%, 0603
RES., 11k, 1/10W, 1%, 0603
RES., 100k, 1/10W, 1%, 0603
RES., SENSE, 0.008Ω, 1/2W, 1%, 2010
I.C., 36V Buck-Boost µModule Regulator
IN
CAP., OPTION, 0603
CAP., ALUM. ELECT.,100µF, 50V, 8 × 10.2
CAP., OPTION, 1206
CAP., OPTION, 7343
CAP., CER., 0.1µF, X7R, 25V, 10%, 0603
DIODE, OPTION, SOD-123
IND., 10µH
RES., OPTION, 0603
RES., 0Ω, 1/10W, 0603
RES., OPTION, 2010
RES., 332k, 1/10W, 1%, 0603
RES., 121k, 1/10W, 1%, 0603
RES., 20Ω, 1/10W, 5%, 0603
I.C., LT1636CMS8#PBF, 8-MSOP
TESTPOINT, TURRET, .094" MTG. HOLE
JACK BANANA
STANDOFF, NYLON, SNAP-ON, 0.500"
MANUFACTURER/PART NUMBER
MURATA, GRM32ER71H475KA88L
TDK, C1608X7R1C224K
MURATA, GRM188R71C103KA01D
SAMSUNG, CL21A226MAQNNNE
AVX, TPSE686M025R0200
VISHAY, CRCW060336K5FKEA
VISHAY, CRCW060311K0FKEA
VISHAY, CRCW0603100KFKEA
VISHAY, WSL20108L000FEA
LINEAR TECH., LTM8055EY#PBF
SUN ELECT., 50CE100LX
MURATA, GRM188R71E104KA01D
WÜRTH, 74477010
VISHAY, CRCW0603000Z0EA
VISHAY, CRCW0603332KFKEA
VISHAY, CRCW0603121KFKEA
VISHAY, CRCW060320R0JNEA
LINEAR TECH., LT1636CMS8#PBF
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 575-4
KEYSTONE, 8833
