Omada Smart Switch
LED
Indication
Flashing: The switch works properly.
SYS
On or Off: The switch works improperly.
Green: All the fans work properly.
FAN
Yellow: Not all the fans work properly.
On: The remaining PoE power is ≤ 7 W.
PoE Max
Flashing: The remaining PoE power keeps ≤ 7 W after this LED is on for 2 minutes.
Off: The remaining PoE power is > 7 W.
Green On: Running at 100 Mbps, but no activity.
Green Flashing: Running at 100 Mbps and is transmitting or receiving data.
10/100M or PoE
Yellow On: Running at 10 Mbps, but no activity.
(When the Speed
Yellow Flashing: Running at 10 Mbps and is transmitting or receiving data.
LED is on)
Off: No device is linked to the corresponding port.
Note: Only for SL2428P.
Green On: Running at 1000 Mbps, but no activity.
Green Flashing: Running at 1000 Mbps and is transmitting or receiving data.
1000M
Yellow On: Running at 10/100 Mbps, but no activity.
Speed or PoE
Yellow Flashing: Running at 10/100 Mbps and is transmitting or receiving data.
(When the Speed
Off: No device is linked to the corresponding port.
LED is on)
Note: 1000M for SL2428P. Speed or PoE for SG2210MP, port 1–16 of SG2218P, and
port 1–24 of SG2428P.
Green On: The port is supplying power normally.
Green Flashing: The supply power exceeds the correponding port's maximum power.
10/100M or PoE
Yellow On: Overload or short circuit is detected.
Speed or PoE
Yellow Flashing: Power-on self-test failed.
(When the PoE LED
Off: Not providing PoE power on the port.
is on)
Note: 10/100M or PoE for SL2428P. Speed or PoE for SG2210MP, port 1–16 of
SG2218P, and port 1–24 of SG2428P.
Green On: A 1000 Mbps device is linked to the corresponding port, but no activity.
Green Flashing: A 1000 Mbps device is linked to the corresponding port and data is
being transmitted or received.
Speed
Yellow On: A 10/100 Mbps device is linked to the corresponding port, but no activity.
1000Base-X
Yellow Flashing: A 10/100 Mbps device is linked to the corresponding port and is
transmitting or receiving data.
SFP1, SFP2
Off: No device is linked to the corresponding port.
Note: 1000Base-X for port 25–28 of SG2428P. Speed for SG2218P. SFP1/SFP2 for
SG2210MP.
LED Mode Switch Button
Press this button to switch the LED status indication between Speed and PoE.
Reset
With the switch powered on, press Reset button for 5 seconds to reset the switch to its factory default
settings.
10/100 Mbps RJ45 Port
Designed to connect to the device with a bandwidth of 10 Mbps or 100 Mbps.
10/100/1000 Mbps RJ45 Port
03
