COUGAR MX440 Mesh RGB Manual

MX440
MESH RGB
MX440 Mesh RGBʼs design has continued COUGARʼs iconic sturdy and solid style. With included
three ARGB fans and a mesh front panel, it combines excellent air flow performance and great
lighting view. Besides, it has wide and powerful interior spaces, which allows you to have
hardware expandability, high cooling performance, and abundant storage space.
Strength, Sturdy, and Superior Airflow
MX440 Mesh RGBʼs front panel features bold lines and rugged structures. It is the chassis
that brings the new concept of strength and sturdy to the gaming world. Moreover, the
mesh front panel provides superior airflow and keeps your advanced components safe from
overheating.
Incredible RGB Lighting
MX440 Mesh RGB comes with 3 ARGB fans. You are freely to control several amazing lighting
effects that we have preset for you with the dedicated RGB button.
Massive Tempered Glass Left Panel
With the full-length PSU cover hides cables and a massive tempered glass left panel presents
a clean and tidy build, you can easily build a pro-level system.
Wider but More Compact and Powerful
MX440 Mesh RGBʼs 215mm width allows much larger interior space with better cooling
performance and cable management. However, its compact exterior dimension takes
up less desktop space. MX440 Mesh RGB can surely fit a full-sized ATX Motherboard,
320mm-length Graphic card, four 2.5" SSDs, and two 3.5" HDDs, which allow you to
achieve the extreme operation and abundant storage space.
Sufficient for Multiple USB Devices
The top panel is equipped with two USB 3.0 ports and one USB 2.0 ports, let you easily
connect multiple peripheral devices and accessory charging. Not only optimize your processing
experiences, but also keep all USB devices without limitations.
Strong Cooling Performance
MX440 Mesh RGBʼs interior space supports up to 170mm height CPU air cooler, a 360mm
water cooling radiator, and high-end cooling components. It helps you to protect critical
components from overheating.
Model Name MX440 Mesh RGB
Model No. CGR-56C1B-MESH-RGB
Case Form Factor Mid Tower
Motherboard Type Mini ITX / Micro ATX / ATX
Dimension 215 (W) x 505 (H) x 424 (D) mm / 8.5 (W) x 19.9 (H) x 16.7 (D) inch
I/O Panel USB 3.0 x 2 , USB 2.0 x 1 , Mic x 1, Audio x 1 , RGB Button
3.5" : 2
Case Drive Bays
2.5" : 4 + 1 (converted from 3.5" drive bays) / (2 SSD trays included)
Expansion Slots 7
Front : 120mm x 3 / 140mm x 2 (120mm ARGB Fans x 3 pre-installed)
Cooling Fan Support Top : 120mm x 2
Rear : 120mm x 1 / 140mm x 1
Maximum Number of Fans 6 Max.
Front : 360mm / 280mm / 240mm / 140mm / 120mm
Water Cooling Radiator Support Top : 240mm / 120mm
Rear : 140mm / 120mm
Transparent Left Panel 4mm Tempered Glass
Max. Graphics Card Length 320mm / 12.6inch
Max. CPU Cooler Height 170mm / 6.7inch
Max. PSU Length 150mm / 5.9inch
Specifications might vary depending on the country or region of sale.
Assembly Drawing
FEATURES
ENGLISH
• Mesh front panel combines with excellent appearance and
sufficient airflow
• Massive tempered glass left panel
• Support for up to six fans and a 360mm radiator
• Support for up to 320mm long graphics cards
• Support for two 3.5" HDDs and four 2.5" SSDs
DEUTSCH
• Mesh-Frontpanel kombiniert mit exzellentem Erscheinungsbild
und ausreichendem Luftstrom
• Linker Abdeckung aus massivem gehärtetem Glas
• Unterstützt bis zu sechs Lüfter und einen 360-mm-Kühlkörper
• Unterstützt Grafikkarten mit einer Länge von bis zu 320 mm
• Unterstützt 2 3,5" Zoll-Festplatten und 4 2,5" Zoll-SSDs
РУССКИЙ
• Сетчатая передняя панель отлично сочетается с внешним
видом корпуса и мощным потоком воздуха
• массивной левой панелью из закаленного стекла
• Поддержка до шести вентиляторов и 360-мм радиатора
• Поддержка видеокарт длиной до 320 мм
• Поддержка двух 3.5-дюймовых жестких дисков и четыре
2.5-дюймовых SSD
ESPAÑOL
• El panel frontal de malla, realiza una excelente combinación
entre apariencia y su sistema de flujo de aire
• Panel izquierdo de vidrio templado
• Soporta hasta 6 ventiladores y un radiador de 360mm
• Soporte para tarjetas gráficas de hasta 320mm de largo
• Soporte para 2 HDD de 3.5" y 4 SSD de 2.5"
FRANÇAIS
• Le panneau avant en maille se combine avec une excellente
apparence et un flux d'air suffisant
• Un capot gauche en verre trempé massi
• Prend en charge jusqu'à 6 ventilateurs et un radiateur de 360 mm
• Prend en charge les cartes graphiques jusqu'à 320 mm de longueur
• Prise en charge de 2 disques durs 3,5" et 4 SSD 2,5"
PORTUGUÊS
• Painel frontal Mesh combina excelente design com alto fluxo de ar
• Painel lateral esquerdo em vidro temperado
• Suporta até 6 ventoinhas e radiador de 360mm
• Suporta placas gráficas de até 320mm
• Suporta até 2 HDDs de 3.5" e 4 SSDs de 2.5"
POLISH
• Siatkowy panel przedni łączy się z doskonałym wyglądem i
wystarczającym przepływem powietrza
• Lewej pokrywie z litego szkła hartowanego
• Obsługa maksymalnie 6 wentylatorów i radiatora do 360 mm
• Możliwość montażu kart graficznych o długości do 320 mm
• Obsługa 2 dysków twardych 3,5" i 4 SSD 2,5"
한국어
• 우수한 외관과 충분한 공기 흐름이 결합 된 메쉬 전면 패널
• 강력한 강화 유리 좌측 덮개가 있는
• 최대 6 개의 팬 및 360mm 라디에이터 지원
• 최대 320mm의 긴 그래픽 카드를 지원
• 3.5" HDD 2개와 2.5" SSD 4개
日本語
․フロントパネルはメッシュ設計で、優れた外観と十分な通気性を備えています
• 強化ガラスウィンドウでPCの内部が見えるので内部のパーツを引き立てます
• 6個のファンと360ｍｍの水冷ラジエーターを装着でき、優れた放熱効果を確保します
• 最大320mmグラフィックカードに対応できます
• 2つの3.5"のHDDと4つの2.5" SSDを搭載可能です
中 文
• 铁网面板结合美观设计与畅通气流
• 全透钢化玻璃左侧盖
• 最高可支援6个风扇与360mm的水冷散热器
• 支援长达320mm的显示卡
• 支援2个 3.5" HDD硬碟与4个 2.5" SSD硬碟
A H
Power button / RGB button Slot covers
B I
USB 3.0 / USB 2.0 / HD audio ports Air filter for top panel
C J
Front panel Air filter for front panel
D K
Tempered glass side panel Air filter for bottom panel
E L
Right side panel 2 x 120mm fans for top panel (optional)
3 x 120mm / 2 x 140mm fans for front panel
F M
3.5" HDD cage (compatible for 2.5" HDD/SSD)
(3 x 120mm ARGB Fans pre-installed)
G N
2.5" HDD/SSD trays 120mm / 140mm fan for rear panel (optional)
Installing the Front I/O Connectors
USB 3.0 USB 2.0 HD AUDIO POWER SW
USB
HD AUDIO
ACCESSORY KIT
3.5" HDD screws
Motherboard screws and 2.5" SSD screws
Power supply screws
Stand-off
Fan screws
2.5"HDD / SSD EVA washers
Cable ties
GLOBAL WARRANTY POLICY
WARRANTY PERIODS OF COUGAR GAMING DEVICES
Product : COUGAR MX440 Mesh RGB
Warranty : 1 Year
● This warranty gives you specific legal rights. You may also have other rights granted under local law. These rights may vary.
● Only for electrical components.
ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ
год и месяц изготовления продукции указаны в серийном номере продукта.
(существует 2 способа определения даты изготовления, оба способа описаны ниже)
A После S/N: первые две цифры означают год, вторые две – месяц изготовления.
Например, S/N: H1702000001 означает, что товар был произведен в феврале 2017 года.
B После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже,и означают год,
последующие две цифры – месяц изготовления.
Например, S/N: DAG02REVI000001 означает, что товар был произведен в феврале 2017 года.
A B C D E F G H I J
1 2 3 4 5 6 7 8 9 0
БЪЛГАРИЯ
• Подробни инструкции за употреба изтеглете от: https://cougargaming.com/bg
POWER LED H.D.D LED
X 8
X 29
X 4
X 3
X 20
X 8
X 5
Например,
●
AG = 17 = 2017 год
България QR код
