Performance Specification (IO-SA0400T)
Items
Thermocouple Type
Digital Conversion
Range of Temperature
Input
RJC
Detecting
the Breaking of Wires
Accuracy
Max Converted Tate
No. of Input Channels
Type of Insulation
Connection Terminal
Current
+3.3 V
Consumption
+24 V
(mA)
Digitally converted value: 0–16000 (-8000–8000)/
Converted temperature value: Range of measured temperature
(one digit after the decimal point * 10)
Thermocouple
DIN Code
Types
K
J
E
T
ITS-90
B
R
S
N
±[(Full Scale) x 0.3% + 1°C (RJC Error)]
Between input terminal and PLC: photo coupler
Insulation between channels: no insulation
- 10 -
Specification
K, J, E, T, B, R, S, N type
- 192–16191 (-8192–8191)
Range of measured
Temp. ( ℃ )
–
-200.0 1200.0
-200.0–800.0
-200.0–600.0
-200.0–400.0
400.0–1800.0
-0.0–1750.0
-0.0–1750.0
-200.0–1250.0
Automatic
Per channel
50 ms/4 Channels
4 Channels/Module
9-point terminal
40
10
Range of measured
Voltage ( ㎶ )
-5891–48838
-7890–48494
-8825–45093
-5603–20872
787–13591
0–20877
0–18503
-3990–45694
