Analog Output (Specifications)
Items
Analog Output Point
Analog Output
Output Setting Method
Digital Conversion
Accuracy
Conversion Speed
Absolute Max. Output
Insulation Method
Power Supply
I/O Occupation
I/O Terminal
Inner
Current
Consumption
(mA)
External
IO-SA0202Y
2 points
Voltage: 0–5 V,
1–5 V, 0–10 V,
-10–10 V
Current: 0–20 mA,
4–20 mA
Setting by
MAPLELOGIC
14-bit, 0–16000
16-bit, 0–64000
Setting by
MAPLELOGIC
±0.05% (Full scale)
±12 V
24 mA
Photocoupler between input terminal and PLC
12-point terminal
@DC 3.3 V, 45 mA
@DC 24 V, 75 mA
- 8 -
IO-SA0004V
4 points
0–10 V.
-10–10V
(switch mode)
Switch OFF: 0–10V
Switch ON: -10–10V
MAPLELOGIC setting
14-bit, 0–16000
±0.1% (Full scale)
< 2 ms/4 Ch
±12 V
External DC 24 V
16 points
8-point terminal
@DC 3.3 V, 40 mA
@DC 24 V, 50 mA
IO-SA0004C
4–20 mA
Not possible
±24 mA
@DC 3.3 V, 40 mA
@DC 24 V, 90 mA
