These accessories were available when the unit was purchased. They are also available at most Sears retail outlets and
service centers. Most Sears stores can order repair parts for you when you provide the model numbers of your tractor and
sweeper

CARTON CONTENTS

1. Sweeper Housing Assembly
2. Bag Arm Tube (2)
3. Left Hitch Tube
4. Hitch Bracket
5. Hitch Bracket (Straight)
6. Height Adjustment Strap
11
10
11
12
15

ACCESSORIES AND ATTACHMENTS

The Front Mount Dethatcher, Model 486.24219 attaches
to the lawn sweeper to help loosen and remove dead
grass and thatch from the lawn while sweeping.
(Loose Parts in Carton)
7. Height Adjustment Handle
8. Right Hitch Tube
9. Brush Assembly (2)
10. Upper Hopper Side Tube (2)
11. Rear Hopper Tube (2)
12. Lower Hopper Side Tube (2)
10
12
13
14
16
9
2
8
3
13. Hopper Support Rod (2)
14. Bag Frame Strap
15. Hopper Bag
16. Rope
2
1
3
6
7
4
5
