EcoFlow DELTA Pro - Portable Power Station Manual

Specifications

General Info
Net Weight	Approximately 45kg (99 lbs)
Dimension (L × W × H)	635×285×416mm (25 × 11 × 16 in)
Capacity	3,600Wh, 48V
Wi-Fi	Frequency Range: 2412-2462MHz Maximum Output Power: 0.05862W
Bluetooth	Frequency Range: 2402-2480MHz Maximum Output Power: 0.0006W
Output Ports
AC (×5)	Pure sine wave, 3,600W total (surge 7,200W), 120V~ (60Hz)
USB-A (×2)	5V 2.4A, 12W Max per port, total 24W
USB-A Fast Charging (×2)	5V 2.4A 9V 2A 12V 1.5A, 18W Max per port, total 36W
USB-C (×2)	5/9/12/15/20V 5A, 100W Max per port, total 200W
Car Charger	12.6V 10A, 126W Max
DC5521 Output (×2)	12.6V 3A, 38W Max per port
Anderson Output	12.6V 30A, 378W Max
Input Ports
AC Charge	120V~ 1,800W Max, 240V~ 3,000W Max
AC Input Voltage	100-120V~ 15A, 220-240V~ 12.5A, 50Hz/60Hz
Solar Charger	11-150V 15A Max, 1,600W Max
Car Charger	Supports 12V/24V Battery, default 8A
Battery Info
Cell Chemistry	LFP
Cycle Life	3,500 cycles to 80% + capacity
Protection Type	Over Voltage Protection, Overload Protection, Over Temperature Protection, Short Circuit Protection, Low Temperature Protection, Low Voltage Protection, Overcurrent Protection
Operating Temperature
Optimal Operating Temperature	20℃~30℃ (68℉ ~ 86℉)
Discharging Temperature	-10℃~45℃ (14℉ ~ 113℉)
Charging Temperature	0℃~45℃ (32℉ ~ 113℉)
Storage Temperature	-10℃~45℃ (14℉ ~ 113℉) (optimal: 20℃~30℃ (68℉ ~ 86℉))
Add-ons (sold separately)
DELTA Pro Smart Extra Battery	Up to two units
EcoFlow Smart Generator
DELTA Pro Remote Control	Wired or wireless
Double Voltage Hub
EV X-Stream Adapter	Charge from electric vehicle charging

1. A car charger shares power with the DC5521 output port, offering a maximum output of 126W.
2. Whether the product can be charged or discharged depends on the actual temperature of the battery pack.

EcoFlow App

Control, monitor and customize your EcoFlow DELTA Pro from afar with the EcoFlow App. Download at: https://download.ecoflow.com/app

Privacy policy
By using EcoFlow Products, Applications and Services, you consent to the EcoFlow Term of Use and Privacy Policy, which you can access via the "About" section of the "User" page on the EcoFlow App or on the official EcoFlow website at
https://www.ecoflow.com/policy/terms-of-use and https://www.ecoflow.com/policy/privacy-policy

What's in the Box

Product Details

Overview

1. Ambient light detector
2. LCD screen
3. USB-A output port
4. Main power button
5. AC power button
6. AC output socket (20 A max. per port)
7. Pairing indicator
8. USB-A fast charging output port
9. Main power button indicator
10. USB-C 100W output port
11. AC output socket (30 A max.)
12. AC charge speed switch
13. Solar/car charging input port
14. X-Stream charging input port
15. Overload protection switch
16. Extra battery port

The type of AC socket varies in different countries or regions, the picture above is for illustration only, please refer to the actual product.

1. Anderson port
2. 12V DC power button
3. IOT button
4. Pairing button
5. Car outlet
6. DC5521 output port
7. Remote control port
8. Bluetooth standby switch
9. Infinity port

Bluetooth standby:
After the Bluetooth standby switch is turned on, DELTA Pro still works with the main power button turned off, use EcoFlow app or remote control (sold separately) to turn on/off the product (Bluetooth standby has a certain amount of power consumption, please turn it off if you don't need to remotely control the product).

LCD Screen

1. Remaining battery percentage
2. EV X-Stream charging indicator
3. Bluetooth connection
4. WiFi connection
5. Remote control
6. State of charge
7. Fan
8. Input power
9. Output power
10. Battery failure warning
11. Error code
12. Solar charging
13. Smart generator
14. Overload warning
15. High temp warning
16. Remaining charge/discharge time
17. Low-temp warning
18. Extra battery
19. AC output
20. USB-A output
21. USB-C output
22. DC output

Icon	Name	State
	Remaining battery	Rotating clockwise: charging 100%: fully charged Flashing: flat battery
	Error code	Refer to the EcoFlow app for details
	Wi-Fi	Flashing: the product is ready for pairing; pair with the product via hotspot on your phone Solid: Internet connection succeeded Off: Internet connection failed

Refer to "Troubleshooting" for details.

Power On/Off

Press the main power button once to turn on the product, then the LCD screen lights up and the main power indicator becomes breathing white; press and hold the main power button for at least 3 seconds to turn off the product, meanwhile, the LCD screen also goes off.

1. After main power turned on, press the main power button once to turn off the LCD screen
2. If the product is not used for 5 minutes, it will enter hibernation state with the LCD screen gone off. When you start to use the product again, the LCD screen will turn on automatically.
3. The product defaults to 2 hours of standby time. With the output power buttons turned off and no other load for 2 hours, the product will shut off automatically. You can set the standby duration in the app.

Charging Your Devices

Press "DC power button" or "AC power button" once to turn on their corresponding DC/AC ports or sockets; press again to turn them off.

1. Please make sure that the product is turned on.
2. After the DC output power button is turned on, the product will not shut off automatically.
3. Make sure that the sum power of all loaded devices is lower than that of the rated power.
4. After 12 hours without any load for the AC output ports, the AC power button will shut down automatically.

Charging DELTA Pro

Grid Power

EcoFlow's X-Stream fast charging technology is specifically for AC charging, offering 1800W of max input power. You can control the charging power through the AC charging Speed Switch. The default max input power for the AC charging speed is 400W, which can be modified in the EcoFlow app.
In case of unusual situations where the AC input current remains higher than 20A, the X-Stream charging input port will initiate a self-protection function, and the Overload Protection Switch on the product will automatically pop up. After confirming that there is no product failure, you can press the Overload Protection Switch to resume charging.

The charging power can be adjusted through the AC Charge Speed Switch on the back of the product. You can set the charging power range in the EcoFlow App.

Please use the AC Charging Cable included in the package for fast charging. Do not use other cables to charge. Plug directly into an AC wall outlet and make sure that the wall output current is more than 15A. Otherwise, reduce the unit charging speed with the AC Charge Speed Switch. EcoFlow takes no responsibilities for any consequences caused by failures to follow instructions, including but not limited to charging with other AC charging cables.

Solar Charging

1. Solar charging cable (MC4-XT60 adapter cable) and the solar panel are supplied separately.
2. When using an EcoFlow solar panel to charge the product, please follow the instructions that come with the solar panel.
3. Before connecting the solar panel, please ensure that the solar panel's output voltage is within 150V to avoid product damages.

Car Charging

Users can recharge the product through the Car Outlet. It supports 12V/24V car chargers and an 8A default charging current.
Please charge using the car charger after you've started the car to avoid failure to start due to insufficient car battery. In addition, please make sure that the cigarette lighter of the Car Outlet and the Car Charger Input Cable are in good condition. EcoFlow takes no responsibilities for any losses or damages caused by failures to follow instructions.

Smart Extra Battery

A single DELTA Pro can link with up to two Smart Extra Batteries at once for added capacity. Refer to the user manuals of the Smart Extra Battery and Smart Generator for detailed instructions.

1. Turn off both the Smart Extra Battery and DELTA Pro before connecting or disconnecting them.
2. Before using, make sure both DELTA Pro and Smart Extra Battery display the extra battery icon on their screens.
3. Turn off the Smart Battery before connecting or disconnecting it.
4. Do not touch the metal terminals of the Smart Extra Battery connector. If the metal terminals need to be cleaned, gently wipe them with a dry cloth.

X-Boost and EPS

X-Boost

With EcoFlow X-Boost technology, the product can power a 4,500W max. device while the rated output power remains 3,600W, avoiding operation failure due to overload protection. X-Boost Tips:

1. X-Boost is not available when the AC output is turned on in a recharging state (in bypass mode).
2. X-Boost is not applicable for all electrical appliances; it's incompatible with appliances with strict voltage requirements and a rated power over 3600W. Appliances with voltage protection (such as precise instruments) are not supported. X-Boost mode is more suitable for heating devices. Please conduct your own tests with your devices with X-Boost enabled.

Bypass mode: When the product is plugged into the power socket for recharging and connected to other devices at the same time, it cannot provide power to the devices if the AC power button is turned on, instead, the devices are powered by the grid.

EPS

The product supports EPS. When you connect the grid power to the AC Input Port of the product through an AC cable, you can power electrical devices through the AC Output Port (AC power will come from the grid and not the power station in this situation). In case of a sudden blackout, the product can automatically switch to the battery powered supply mode within 30ms.
As a basic UPS function, this function does not support 0ms switching. Please do not connect the product to any device that requires 0ms UPS, such as data servers and workstations. Please test and confirm the compatibility before using the product. We recommend that you only charge one device at a time and avoid using multiple ones at the same time to avoid overload protection. EcoFlow takes no responsibilities for any device failures or data losses caused by failures to follow instructions.

FAQ

1. What battery does the product use?
   High-quality LFP battery.
2. What devices can the product's AC output port power?
   With 3600W rated power and 7200W peak power, the product's AC output ports can power most household appliances. Before you use it, we recommend that you confirm the power of the appliances first and ensure the sum power of all loaded appliances is lower than that of the rated power.
3. How long can the product charge my devices?
   The charging time is shown on the product's LCD Screen, which can be used to estimate the charging time of most appliances with stable power usage.
4. How do I know if the product is charging?
   When it's charging, the remaining charging time will be shown on the LCD Screen. Meanwhile, the charging indicator icon begins to rotate with the remaining battery percentage and the input power shown on the right of the circle.
5. How do I clean the product?
   Gently wipe it with a dry, soft, clean cloth or paper towel.
6. How do I store the product?
   Before storing, please turn off the product first, and then store it in a dry and ventilated place at room temperature. Do not place it near water sources. For long-term storage, please discharge and recharge it every three months to extend its battery life (See "Storage and Maintaince" for details).
7. Can I bring the product on a plane?
   No.
8. How do I recharge DELTA Pro at 200V–240V in a 100V–120V region?
   The cable provided with your DELTA Pro cannot be plugged into higher-voltage outlets, you need a third party adapter/charging cable.

Storage and Maintenance

1. Ideally, use and store the product in a place of between 20°C ~ 30°C (68°F ~ 86°F), and always keep it away from water, intense heat, and sharp objects. For an extended product lifespan, do not store it in places of temperatures above 45°C (113°F) or below -10°C (14°F).
2. For long-term storage, please discharge the product every three months (firstly discharge it to 0%, then fully recharge it, and lastly discharge it to 60%); the product will not be covered by the warranty if it is not charged or discharged for more than 6 months.

Troubleshooting

Indicator	Problem	Solution
(Flashing)	USB-A Overload Protection	Resume normal operation by removing the electrical device connected to the USB-A port.
(Flashing)	USB-C Overload Protection	Resume normal operation by removing the electrical device connected to the USB-C port.
(Flashing)	USB-C High Temperature Protection	After the product cools down, it will resume normal operation automatically.
(Flashing)	High Temperature Charge Protection	Charging can be resumed automatically after the battery cools down.
(Flashing)	High Temperature Discharge Protection	The power supply can be resumed automatically after the battery cools down.
(Flashing)	Low Temperature Charge Protection	Charging can be resumed automatically after battery temperature rises above 5°C (41°F).
(Flashing)	Low Temperature Discharge Protection	The power supply can be resumed automatically after the battery temperature rises above -12°C (10°F).
(Flashing)	AC Output Overload Protection	Normal operation will be resumed automatically after you remove the overloaded device and restart the product. Electrical appliances should be used within rated power. (Refer to X-Boost instructions to get more details about power limitations).
(Flashing)	AC High Temperature Protection	Please confirm whether the fan inlet and outlet are blocked, if not, normal operation will be resumed automatically after the product temperature drops.
(Flashing)	AC Low Temperature Protection	Normal operation will be resumed automatically after the product is used at optimum environmental temperatures.
(Flashing)	Fan Blockage	Please check if the fan is blocked by foreign materials.
(Flashing)	Car Charger Overload Protection	The product will resume normal operation automatically after you remove the device connected to the car charger.
(Flashing)	Car Charger High Temperature Protection	After the product cools down, it will resume normal operation automatically.
(Stays on)	Battery Failure	Contact EcoFlow customer service.

If the alarm prompt shows on the product LCD screen during use and does not disappear after a restart, please stop using it immediately (do not try to charge or discharge). If you require any other assistance, please contact EcoFlow Customer Service.
