ECOVACS DEEBOT 900 - Robot Vacuum Cleaner Manual

Package Contents and Technical Specifications

Package Contents

Package Contents

Note: Figures and illustrations are for reference only and may differ from actual product appearance.
Product design and specifications are subject to changes without notice.

Specifications

Model DE5G
Working voltage 12V DC
Docking Station Model CH1630A
Input 100-130V AC, 50/60Hz, 0.5A Output

20V DC,

0.8A

Laser Max. Power 2.5mW
Frequency 1.8KHz
Rotate Speed 300± 5 circle/min

Note: Figures and illustrations are for reference only and may differ from actual product appearance.
Product design and specifications are subject to changes without notice.

Product Diagram

Robot
Product Diagram - Robot

Bottom View
Product Diagram - Bottom View

Operating and Programming

Notes Before Cleaning


Do not use DEEBOT on wet surfaces or surfaces with standing water.

Before using the product on a rug with tasseled edges, please fold the Remove power cords and small objects from the floor that the robot rug edges under. could be obstructed by, and tidy up the area to be cleaned by putting furniture, such as chairs, in their proper place.
Notes Before Cleaning - Step 1

Remove power cords and small objects from the floor that the robot could be obstructed by, and tidy up the area to be cleaned by putting furniture, such as chairs, in their proper place.
Notes Before Cleaning - Step 2

It may be necessary to place a physical barrier at the edge of a drop to stop the unit from falling over the edge.
Notes Before Cleaning - Step 3

Operating and Programming

Quick Start

  1. Remove Protective Strip
    Quick Start - Remove Protective Strip
  2. Docking Station Placement
    Quick Start - Docking Station Placement
  3. Install Side Brushes
    Quick Start - Install Side Brushes
  4. Power ON
    Quick Start - Power ON
  5. Charge DEEBOT
    Quick Start - Charge DEEBOT
  6. Start
    Quick Start - Start
  7. Pause
    Quick Start - Pause
    Note: The robot's Control Panel stops glowing after the robot is paused for a few minutes. Press the AUTO Mode Button on DEEBOT to wake up the robot.
  8. Power OFF
    Quick Start - Power OFF
    Note: When DEEBOT is not working, it is recommended to keep it switched ON and charging.

All the functions mentioned above can be enabled on the App. Download ECOVACS App to access more features, including MAX Mode, Scheduled Cleaning, etc.

www.apple.com
play.google.com
Download ECOVACS App

Choosing a Suction Option

Main Brush Option: The best choice for deep cleaning, with a combination of the Main Brush and strong suction.
Main Brush Option

Direct Suction Option: The best choice for daily cleaning. This Suction Option is specifically designed to pick up hair without getting clogged by it, and is ideal for pet owners.
Direct Suction Option

Install the Direct Suction Option

Install the Direct Suction Option

Install the Main Brush Option

Install the Main Brush Option

Maintenance

Before performing cleaning and maintenance tasks on DEEBOT, turn the robot OFF and unplug the Docking Station.

Dust Bin and Filters

Dust Bin
Dust Bin and Filters - Dust Bin

Filters
Dust Bin and Filters - Filters - Step 1
Dust Bin and Filters - Fitlers - Step 2
Dust Bin and Filters - Fitlers - Step 3
Dust Bin and Filters - Fitlers - Step 4
Dust Bin and Filters - Fitlers - Step 5

Main Brush, Direct Suction Option and Side Brushes

Note: A Multi-Function Cleaning Tool is provided for easy maintenance. Handle with care, this cleaning tool has sharp edges.

Man Brush

Main Brush, Direct Suction Option and Side Brushes - Main Brush

Direct Suction Option
Main Brush, Direct Suction Option and Side Brushes - Direct Suction Option

Side Brushes
Main Brush, Direct Suction Option and Side Brushes - Side Brushes

Other Components

Note: Before cleaning the robot's Charging Contacts and Docking Station Pins, turn the robot OFF and unplug the Docking Station.
Other Components

Maintenance

Regular Maintenance

To keep DEEBOT running at peak performance, perform maintenance tasks and replace parts with the following frequencies:

Robot Part Maintenance Frequency Replacement Frequency
Side Brush Once every 2 weeks Every 3-6 months
Main Brush Once per week Every 6-12 months
Sponge Filter/ High Efficiency Filter Once per week Every 3-6 months

Universal Wheel

Anti-Drop Sensors Bumper

Charging Contacts

Docking Station Pins

Once per week /

A multi-function Cleaning Tool is provided for easy maintenance. Handle with care, this cleaning tool has sharp edges.
Note:
ECOVACS manufactures various replacement parts and fittings. Please contact Customer Service for more information on replacement parts.

Troubleshooting

DEEBOT will tell you something is wrong with an alarm indicator light and sounds.
More detailed support is available through the ECOVACS App and online.

No. Malfunction Possible Causes Solutions
1 DEEBOT is not charging. DEEBOT is not switched ON. Switch ON DEEBOT.
DEEBOT has not connected to the Docking Station. Be sure that the robot's Charging Contacts have connected to the Docking Station Pins.
The battery is completely discharged. Re-activate the battery. Switch ON Place DEEBOT on the Docking Station by hand, remove after charging for 3 minutes, repeat 3 times; then charge normally.
2 DEEBOT cannot return to the Docking Station. The Docking Station is not correctly placed. Refer to Quick Start section to correctly place the Docking Station.
3 DEEBOT gets stuck while working and stops. DEEBOT is tangled with something on the floor (electrical wires, curtains, carpet fringing, etc.). DEEBOT will try various ways to free itself. If it is unsuccessful, manually remove the obstacles and restart.
4 DEEBOT returns to the Docking Station before it has finished cleaning. When the battery gets low, DEEBOT automatically switches to Return to Charger Mode and returns to the Docking Station to recharge itself. This is normal. No solution necessary.
Working time varies according to floor surface, room complexity and the Cleaning Mode selected. This is normal. No solution necessary.
5 DEEBOT does not clean automatically at the scheduled time. Time Scheduling function is cancelled. Program DEEBOT to clean at specific times using the ECOVACS App.
The Continued Cleaning function is turned ON and. DEEBOT has just finished cleaning the scheduled cleaning area. This is normal. No solution necessary.
DEEBOT is switched OFF. Switch ON DEEBOT.
The robot's battery is low.

Keep DEEBOT switched ON and connected to the

Docking Station to make sure it has a full battery to work at any time.

The robot's Suction Intake is blocked and/or there is debris stuck in its components. Power OFF DEEBOT, clean the Dust Bin and invert the robot. Clean the robot's Suction Intake, Side Brushes and the Main Brush as described in Maintenance section.
6 DEEBOT does not clean the whole area The cleaning area is not tidy. Remove small objects from the floor and tidy up the cleaning area before DEEBOT starts cleaning.
7 DEEBOT is not able to connect to the home Wi-Fi network. Incorrect home Wi-Fi username or password entered. Enter the correct home Wi-Fi username and password.
DEEBOT is not within range of your home Wi-Fi signal. Make sure DEEBOT is within range of your home Wi-Fi signal.
Network setup started before DEEBOT was ready. Turn ON Power Switch. Press the RESET Button using a needle for 3 seconds. DEEBOT is ready for network setup when it plays a musical tune and its Wi-Fi Indicator light flashes slowly.
Your smartphone's operating system needs to be updated. Update your smartphone's operating system. The ECOVACS App runs on iOS 9.0 and above, Android 4.0 and above.
