INSTALLATION GUIDE
EN
INSERT
BOXTHERM 70 AIR 9 BASIC M1
BOXTHERM 70 AIR 9 SLIDE M1
BOXTHERM 60 AIR 6 BASIC M1
BOXTHERM 60 AIR 6 SLIDE M1
PART 2 - OPERATION AND CLEANING
Instructions in English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BOXTHERM 70 AIR 9 SLIDE M1 and is the answer not in the manual?

Questions and answers

Summary of Contents for MCZ BOXTHERM 70 AIR 9 SLIDE M1

  • Page 1 INSTALLATION GUIDE INSERT BOXTHERM 70 AIR 9 BASIC M1 BOXTHERM 70 AIR 9 SLIDE M1 BOXTHERM 60 AIR 6 BASIC M1 BOXTHERM 60 AIR 6 SLIDE M1 PART 2 - OPERATION AND CLEANING Instructions in English...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS ....................II 14-FIRST START-UP .....................3 15-SYSTEM REQUIREMENTS ..................4 16-FIRST APP START-UP AND ASSOCIATION WITH MCZ STOVES ........5 17-STOVE ACCESSORY CONFIGURATION ................8 18-COMFORT SETTING ....................10 19-EMERGENCY PANEL ....................13 20-EMERGENCY PANEL FUNCTIONS ................14 21-MANUAL CONFIGURATION ..................15...
  • Page 3: 14-First Start-Up

    14-FIRST START-UP WARNINGS BEFORE IGNITION GENERAL PRECAUTIONS Remove all parts that may burn from the brazier and the glass (manual, various adhesive labels or any polystyrene). Check that the brazier is positioned correctly and rests properly on the base. The first ignition may not be successful as the feed screw is empty and does not always manage to load the brazier with the required amount of pellets in time to light the flame.
  • Page 4: 15-System Requirements

    15-SYSTEM REQUIREMENTS The MCZ Maestro App is already available on the “Handheld remote control” accessory or will be available in various playstores. STOVE Equipped with MAESTRO system OPERATION For the utmost versatility of use, two Wi-Fi modules have been designed, supporting priority connection with your smartphone and/or handheld remote control (optional).
  • Page 5: 16-First App Start-Up And Association With Mcz Stoves

    16-FIRST APP START-UP AND ASSOCIATION WITH MCZ STOVES The app lets you communicate with MCZ stoves using two technologies: • home Wi-Fi • remote Wi-Fi HOME WI-FI Point-to-point connection between the telephone and the stove, to communicate with the stove without relying on routers or internet connections.
  • Page 6 16-FIRST APP START-UP AND ASSOCIATION WITH MCZ STOVES IMPORTANT!! Do not lose or remove the QR code from the stove. If the stove is reset and/or the smartphone and/or handheld remote control are changed, you must have the QR code and passwords available to configure the system.
  • Page 7 16-FIRST APP START-UP AND ASSOCIATION WITH MCZ STOVES MANUAL MODE The QR code and the passwords are located at the back of the stove and in the warranty. In this case, the codes must be used. EXAMPLE OF QR AND PASSWORD LABEL If the stove cannot be configured using the QR code, it can be done using the DIRECT or REMOTE key.
  • Page 8: 17-Stove Accessory Configuration

    In order to configure the accessories, the mobile phone must be near the accessories. CONFIGURATION OF REMOTE WI-FI MODULE FROM MCZ MAESTRO APP To do this, connect to the stove in home mode through the app. From the “settings” / “basic settings” menu, select the configure accessories item: if there are still accessories to be configured, the two keys can be selected.
  • Page 9 17-STOVE ACCESSORY CONFIGURATION CONFIGURATION OF WI-FI TEMPERATURE PROBE FROM MCZ MAESTRO APP The Wi-Fi temperature probe (ACCESSORY) is supplied without batteries. From when the batteries are inserted, the probe can be configured within the next 8 minutes. Therefore insert the three AA batteries shortly before you are ready to proceed with the configuration.
  • Page 10: 18-Comfort Setting

    18-COMFORT SETTING Maestro technology allows the heater to express its utmost potential with even an easier and more intuitive use. A real integrated micro- computer communicates with your smartphone and further improves the performance of the heater that continues to work perfectly even in non-ideal conditions.
  • Page 11 18-COMFORT SETTING MANUAL SETTING The MANUAL setting can be selected by typing the relative symbol in the screen that is also highlighted through the notches on the selection ring. The user has the ability to manage ventilation and power. To set the desired parameters, press the temperature at the centre of the circle, and the pop-up appears to make the setting. Technical Dept.
  • Page 12 18-COMFORT SETTING SET DYNAMIC The DYNAMIC setting can be selected by typing the relative symbol in the screen that is also highlighted through the notches on the selection ring. The user has the possibility to manage ventilation and temperature. To set the desired temperature, press the temperature at the centre of the circle, and the pop-up appears to make the setting.
  • Page 13: 19-Emergency Panel

    19-EMERGENCY PANEL A - MULTICOLOUR LED B - BUTTON - functions Green LED that indicates: Turns the product ON • Stove in OPERATION Turns the product OFF Red LED that indicates: Changes the operating POWER: • Stove OFF • 1 beep = LOW •...
  • Page 14: 20-Emergency Panel Functions

    20-EMERGENCY PANEL FUNCTIONS The emergency panel provides the following information: • through a multicolour LED (A) it provides information about the stove status (off-starting-up-in operation-cooling for shutdown- in error conditions) • using the button (B) the following functions can be activated: •...
  • Page 15: 21-Manual Configuration

    (on the QR code label) Once the Wi-Fi probe is connected, you can configure the stove to use the remote sensor; to do so, open the MCZ MAESTRO APP, connect to your previously configured stove, use the shortcut by clicking on the temperature indicator at the top right of the app screen and select the “Wi-Fi probe”...
  • Page 16: 22-App Functions

    22-APP FUNCTIONS Once the devices are configured, the App will automatically try to connect to the last device used. If connection is successful, the App will display the “I/O” screen. It is possible to switch on and use all stove functions from here. If it tries to connect to the last connected device and something goes wrong, the App will display the list of configured devices.
  • Page 17 22-APP FUNCTIONS FAN SCREEN This screen manages the fan power of each single fan. There are 5 power levels that can be set. Each fan has the option of automatic operation and the option to switch off the fan If the ventilation is set MANUALLY, the function which limits the maximum power of the stove according to the ventilation is enabled. COMFORT AIR (3 FANS): maximum power level = total of the ventilation levels/2 AIR: maximum power level = twice the total of the levels of ventilation Each fan is available with automatic function and NO AIR function to switch ventilation off, in the models where this is possible, to...
  • Page 18: 23-Side Drop Down Menu

    23-SIDE DROP DOWN MENU SET SCREEN The menu can be selected on the top left of the three lines and includes SHORTCUTS (shortcut and / or quick settings) • LANGUAGE • LIST OF DEVICES • CHRONOTHERMOSTAT • ECOSTOP SETTINGS • SET FACTORY PARAMETERS •...
  • Page 19: 24-Shortcuts Settings / Rapid Settings

    24-SHORTCUTS SETTINGS / RAPID SETTINGS SHORTCUTS (shortcut and / or quick settings) • LANGUAGE • DEVICES LIST • CHRONOTHERMOSTAT • ECOSTOP LANGUAGE SCREEN Entering the side menu, select LANGUAGE and the system will display all the languages available. Select the desired language. Press the SAVE button to confirm the chosen language.
  • Page 20 24-SHORTCUTS SETTINGS / RAPID SETTINGS LIST OF DEVICES This screen displays which devices have been configured. Only the device depicting the icon of a stove next to it can be selected. From the menu next to the configured device it is possible to access the MODIFY or DELETE function.
  • Page 21 24-SHORTCUTS SETTINGS / RAPID SETTINGS CHRONOTHERMOSTAT Temperature selection option (T1-T2-T3) Option to set the weekly programs. Option to set different temperatures for different days of the week and different time bands. Technical Dept. - All rights reserved - Reproduction prohibited...
  • Page 22 24-SHORTCUTS SETTINGS / RAPID SETTINGS ECOSTOP From the ECO STOP menu, it is possible to set and/or edit delayed activation (min) and Reignition hysteresis (C°). ECO is an automatic mode with the only difference that if the set temperature is reached and remains so for the time (in minutes) that was selected from the delayed activation drop-down menu (value ranging between 5 and 30 minutes), the product switches off and remains in stand-by until the room temperature drops below the desired temperature (hysteresis frequency ranges between 2 and 5 minutes).
  • Page 23: 25-Set Factory Parameters

    25-SET FACTORY PARAMETERS SET FACTORY PARAMETERS • DATE AND TIME • BOARD INPUTS • CONFIGURE WIFI PROBE • BEEP ON / OFF • ACCESSORIES DATE AND TIME Press the DATE AND TIME key to access the screen to edit data. After setting the data, press SAVE and exit the screen. Technical Dept.
  • Page 24 25-SET FACTORY PARAMETERS BOARD INPUTS Room input is used to set the Wi-Fi probe, thermostat or room probe. Click the drop-down menu to select the desired option.
  • Page 25 25-SET FACTORY PARAMETERS CONFIGURE WIFI PROBE This screen configures the frequency (in minutes) and shows the last connection made. Technical Dept. - All rights reserved - Reproduction prohibited...
  • Page 26 25-SET FACTORY PARAMETERS BEEP ON / OFF This function is used to enable/disable the tones.
  • Page 27 25-SET FACTORY PARAMETERS ACCESSORIES Entering the ACCESSORIES menu it is possible to CONFIGURE: • REMOTE CONFIGURATION • T PROBE CONFIGURATION Refer to Chapter 3 (“Configure stove accessories”) for the mode. REMOTE CONFIGURATION CONFIGURE PROBE T° Technical Dept. - All rights reserved - Reproduction prohibited...
  • Page 28: 26-Operation Menu

    26-OPERATION MENU FUNCTIONALITY • CHRONOTHERMOSTAT • ECO STOP • SLEEP CHRONOTHERMOSTAT Temperature selection option (T1-T2-T3) Option to set the weekly programs. Option to set different temperatures for different days of the week and different time bands.
  • Page 29 26-OPERATION MENU ECOSTOP From the ECO STOP menu, it is possible to set and/or edit delayed activation (min) and Reignition hysteresis (C°). ECO is an automatic mode with the only difference that if the set temperature is reached and remains so for the time (in minutes) that was selected from the delayed activation drop-down menu (value ranging between 5 and 30 minutes), the product switches off and remains in stand-by until the room temperature drops below the desired temperature (hysteresis frequency ranges between 2 and 5 minutes).
  • Page 30 26-OPERATION MENU SLEEP Sleep mode allows to quickly set the time when the product must switch off. This function is only available in MAN and AUTO mode. To enable or disable the SLEEP function, touch the relative key.
  • Page 31: 27-Settings Menu

    27-SETTINGS MENU SETTINGS • FEED SCREW ON • RECIPES • SUMMER/WINTER • PELLET SENSOR • BRAZIER CLEANING FEED SCREW ON This function, which can only be activated with the stove off, enables you to load pellets into the loading system (feed screw), and is used every time pellets in the hopper run out.
  • Page 32 27-SETTINGS MENU Modifying the pellet recipe and air recipe This function is for adapting the stove to the type of pellet in use. In fact, since there are many types of pellets on the market, operation of the stove varies significantly depending on the good or poor quality of the fuel. The amount of pellets in the brazier can be increased or reduced: • If the pellets tend to jam in the brazier due to an excess of fuel • If the flame is increasingly higher even at low power values...
  • Page 33 27-SETTINGS MENU SUMMER/WINTER Option to select the operating season. Technical Dept. - All rights reserved - Reproduction prohibited...
  • Page 34 27-SETTINGS MENU PELLET SENSOR The pellet sensor is used to measure the level of pellets in the hopper. It can be activated from the side menu, SETTINGS after having assembled the sensor on the hopper and carried out the appropriate connection in the card (see next page).
  • Page 35 27-SETTINGS MENU ASSEMBLING PELLET LEVEL SENSOR The pellet sensor is a low fuel indicator that warns the user that the pellets are finishing. With the hopper empty, lift the pellet loading cover and manually remove the cap “J” fitted inside, then insert the pellet level sensor “K” from inside the hopper.
  • Page 36 27-SETTINGS MENU BRAZIER CLEANING Only for “MATIC” products with automatic brazier cleaning system. Press “ENABLE” to set a complete cleaning cycle for the product.
  • Page 37: 28-Software Version

    28-SOFTWARE VERSION SOFTWARE VERSION The SOFTWARE VERSION option is found in the SETTINGS menu. Through this item it is possible to know all the stove information e.g. Database and app version Technical Dept. - All rights reserved - Reproduction prohibited...
  • Page 38: 29-Technical Menu

    29-TECHNICAL MENU TECHNICAL MENU To enter the TECHNICAL MENU, select the three dashes at the top, scroll to the end of the drop-down menu and select the item. To enter the functions it is necessary to enter a Password (available for authorised technicians) and press OK.
  • Page 39 29-TECHNICAL MENU The main functions that can be changed and/or controlled from the technical menu are: • PARAMETERS • ACTIVE ON/OFF • SYSTEM T° • DIAGNOSTICS • SELECT DATABASE • FACTORY RESET • SERVICE RESET • LAST ALARMS • WORKING HOURS Technical Dept.
  • Page 40: 30-Info Menu

    30-INFO MENU ABOUT The INFO menu provides certain information regarding the stove’s status...
  • Page 41: 31-Safety Devices And Alarms

    31-SAFETY DEVICES AND ALARMS SAFETY DEVICES The product is fitted with the following safety devices. SMOKE TEMPERATURE PROBE It detects the temperature of the smoke, thereby enabling start-up or stopping the product when the temperature drops below the preset value. PELLET HOPPER TEMPERATURE PROBE If the temperature exceeds the preset safety value, it immediately stops the product, which must cool down before the stove is restarted.
  • Page 42 31-SAFETY DEVICES AND ALARMS ALARM ALERTS In the event an operating anomaly occurs the stove starts switching off due to the alarm. The type of alarm appears on the App. The app signals the active alarm codes while a red LED lights up on the stove panel. The following table describes the possible alarms indicated by the stove, associated to the respective code that appears on the emergen- cy panel and helpful tips to solve the problem.
  • Page 43 31-SAFETY DEVICES AND ALARMS Pellet supply fault Contact an authorised service centre to have the component replaced. Faulty gear motor driving sensor (PWM) Contact an authorised service centre. Electronic control unit overheating The structure is too hot because the product has been used for too long at the maximum power or there is poor ventilation.
  • Page 44 If these causes are excluded, check and if necessary clean the smoke duct and flue (it is recommended for this operation to be carried out by an MCZ qualified technician). The product can be switched on again only after having eliminated the cause permanently.
  • Page 45 31-SAFETY DEVICES AND ALARMS In the event that alarm A21 is triggered often, please note that: Open stove door Close the door Open fuel loading hatch Close the hatch. TRIPPED Lower the fuel level in the hopper. SAFETY DE- VICES Air pressure switch Draught difficulties or brazier clogged.
  • Page 46 31-SAFETY DEVICES AND ALARMS Remembering that the draught recommended for the products to work properly is 10 Pa at maximum capacity and 5 Pa at minimum (according to the technical data sheet found in the user and maintenance manual), adjustments may be required in worse draught conditions (also due to the position of the flue in areas that are particularly subject to adverse weather such as prevailing winds, snow, northern exposure, etc.) so as to always guarantee the required negative pressure inside the hopper.
  • Page 47 31-SAFETY DEVICES AND ALARMS NEGATIVE PRESSURE INSIDE THE HOPPER WITH FACTORY-SET PARAMETERS AND A DRAUGHT OF 5 Pa (MINIMUM RECOMMENDED) POWER VALUES 13.7/14.2 Pa 15.1/15.6 Pa 17.1/17.5 Pa 19.1/19.5 Pa 22.0/22.2 Pa Draught 6 kW 95°C 110°C 125°C 141°C 165°C Smoke temperature 13.8/14.3 Pa 15.6/16.1 Pa...
  • Page 48: 32-Recommendations For Safe Use

    32-RECOMMENDATIONS FOR SAFE USE ONLY CORRECT INSTALLATION AND APPROPRIATE MAINTENANCE AND CLEANING OF THE APPLIANCE CAN GUARANTEE CORRECT OPERATION AND SAFE USE OF THE PRODUCT. We would like to inform you that we are aware of cases of malfunctioning of domestic pellet-fuelled heating products, mainly due to incorrect installation and inappropriate maintenance.
  • Page 49: 33-Maintenance And Cleaning

    33-MAINTENANCE AND CLEANING EXAMPLE OF A DIRTY BRAZIER EXAMPLE OF A CLEAN BRAZIER Only by properly servicing and cleaning the product is it possible to ensure its safety and correct operation. ATTENTION! All the cleaning operations of all parts must be performed with the product completely cold and the plug disconnected.
  • Page 50 33-MAINTENANCE AND CLEANING For the brazier to be cleaned properly, remove it from its housing completely and thoroughly clean all the holes and the grate on the bottom. If good quality pellets are used, you will normally only need to use a brush to restore the optimal operating conditions of the component.
  • Page 51 33-MAINTENANCE AND CLEANING CLEANING THE GLASS It is recommended to clean the ceramic glass with a dry brush, or if it is very dirty, spray a little specific detergent and clean with a cloth. ATTENTION! Do not use abrasive products and do not spray the glass cleaning product on the painted parts and on the door gaskets (ceramic fibre seal).
  • Page 52 33-MAINTENANCE AND CLEANING PERIODIC CLEANING PERFORMED BY A QUALIFIED TECHNICIAN EXTRACTING THE PRODUCT To perform maintenance of some devices and cleaning of certain parts, it is required to extract a part of the product from its housing. The movable part is fitted on sliding guides, which facilitate the handling process. Before extracting it, release the handle lock following the instructions in this manual.
  • Page 53 33-MAINTENANCE AND CLEANING Use a flexible brush to scrape the walls of the firebox (arrow 1 in the figure) so as to make the ash fall into the ash pan. Use a vacuum cleaner nozzle to vacuum up any remaining ash and dust in the ash pan and brazier zone. Repeatedly pass it between the exchangers pipes (arrow 2 in the figure) to remove the fuel deposits and residues.
  • Page 54 33-MAINTENANCE AND CLEANING After cleaning as described above and before reassembling the cast iron firebox panels, it is advisable to vacuum the ash pan and brazier zone. Also vacuum in the top part, under the front grille, to remove any accumulated dust. Then thoroughly clean the lower exchanger, replace any gaskets if needed, and reassemble.
  • Page 55 33-MAINTENANCE AND CLEANING CLEANING THE SMOKE DUCT AND FITTING When the product has been extracted, it is possible to operate on the left side to clean and maintain the smoke fan (1). Clearly, the smoke evacuation fan must be removed for such maintenance to be performed. A gasket (3) is applied on the fan outlet, which guarantees the tightness with the smoke fitting (2).
  • Page 56 33-MAINTENANCE AND CLEANING PERIODICAL CHECK OF THE DOOR CLOSURE Make sure the door closure ensures a correct sealing action (with the “paper sheet” test) and that when the door is closed, the closing block (X in the figure) does not protrude from the sheet metal to which it is secured. For some products it will be necessary to disassemble the cladding to be able to assess the anomalous protrusion of the block when the door is closed.
  • Page 57 33-MAINTENANCE AND CLEANING CHECKING THE INTERNAL COMPONENTS ATTENTION! The internal electromechanical components must only be checked by qualified personnel whose technical expertise includes combustion and electricity. We recommend that an annual maintenance service is carried out (with a scheduled service contract). This service is essentially a visual and functional inspection of the internal components.
  • Page 58: 34-Troubleshooting

    34-TROUBLESHOOTING ATTENTION! All repairs must only be carried out by a specialised technician, with the product switched off and the plug disconnected. ANOMALY POSSIBLE CAUSES SOLUTIONS The pellets are not fed into the The pellet hopper is empty. Fill the hopper with pellets. combustion chamber.
  • Page 59 34-TROUBLESHOOTING ANOMALY POSSIBLE CAUSES SOLUTIONS The product works for a few minutes Start-up phase is not completed. Repeat start-up. and then switches off. Temporary power cut. Switch it back on. Clogged smoke duct. Clean smoke duct. Faulty or malfunctioning temperature Check and replace the probes.
  • Page 60 34-TROUBLESHOOTING ANOMALY POSSIBLE CAUSES SOLUTIONS The air fan does not switch on. The product has not reached the Wait. temperature. The remote control does not work. The remote control battery is flat. Replace the battery. Remote control faulty. Replace the remote control. The product always runs at maximum The room thermostat is in the maximum Reset the temperature of the remote...
  • Page 61: 35-Circuit Board

    35-CIRCUIT BOARD LIVE ELECTRICAL CABLES DISCONNECT THE POWER SUPPLY CABLE 230V BEFORE CARRYING OUT ANY OPERATIONS ON THE ELECTRICAL BOARDS 1. KLIXON 9. MAESTRO CONTROL PANEL (OPTIONAL) 2. AIR PRESSURE SWITCH 10. SMOKE TEMPERATURE PROBE 3. AIR FAN 3 (IF ANY) 11.
