LISTA DE EMPAQUE
COMPONENTES DE LA MÁQUINA DE REMO
1.Frame
5.Cubierta del riel frontal
9.Hoja de conexión
13.M12 circlip
13.Circlip M12
LISTA DE EMPAQUE
17.Palanca de
parada
23.Perno
24.Perno de carro
M5* 16mm
29. Perno de
cabeza hexagonal
perilla
2. Tubo de patas frontal
6.Juego de pernos de
bloqueo x 2
10.Cubierta del riel trasero
14.Pedal izquierdo
18.Arandela
19. Arandela
plana M10 * 4
dividida M10
25.Tuerca
M8*55mm * 4
ciega M8*4
30. Tornillo de
31. Arandela plana
grande M8*2
M8*20mm *2
3. Riel
7.Asiento
11 .Tubo de patas trasero
15.Pedal derecho
20.Perno Allen
M8*16mm * 9
26.Tornillo de
27. Contratuerca
cabeza hexagonal
M10*100mm
32.Llave Allen*2
-4-
4. Conexión del marco
8.Soporte trasero
12. M12 flat washerx 2
12. Arandela plana M12* 2
16.Tubo de pedal
21.Arandela
22.Arandela
plana M8 * 8
dividida M8 * 8
28. Pasador de
M10
retención
33. Llave de boca abierta*4
