- Page 1 Operating manual orka luxe a Look Solutions product...
- Page 2 Set of Equipment supplied – 1 Orka deLuxe – 1 tank lid with quick connector, silicon tube and air valve filter – 1 Operating manual Please check whether all the products you ordered are supplied. Original operating manual, version 01/2023...
-
Page 3: Table Of Contents
Content 1. Introduction 2. Safety instructions 3. Description of the parts 4. Fluid 4.1 General Notes 4.2 Refilling the fluid container 5. Operating the Orka deLuxe 5.1 Selecting the location 5.2 Putting into operation 5.3 Switching the device off 5.4 Control via DMX 512 5.4.1 Adjusting the DMX start address 5.4.2 RDM 5.5 Stand alone mode 5.6 Wiring of the sockets 6. Cleaning, Care and Maintenance 7. Troubleshooting 8. Specifications 9. Warranty Conditions... -
Page 4: Introduction
1. Introduction The Orka deLuxe is probably the most powerful touring machine on the market. Built into a robust flight case with a powerful fan, the Orka deLuxe is ready for any use. New features make it even easier to use - placing and fogging without wasting a lot of time setting and preparing. The new 20L flat tank can be filled conveniently and easily, guaranteeing a longer ope- rating time. The castor dishes allow for easy and safe stacking and stowing of the equipment. The performance of the machine allows applications from clubs to large halls, festivals, stadiums and events, as well as use for airflow or leak testing in large buildings and tunnels. The intended use of the device is to create artificial fog. -
Page 5: Safety Instructions
2. Safety instructions A fog machine is not a toy! • Very hot steam escapes from the nozzle. Danger of getting burnt. • Occasionally very hot droplets of fluid may escape when in operation. Thus never aim at persons directly and keep a minimum distance of 3 m to the nozzle. • Never touch the nozzle when in operation. Danger of getting burnt. • The location for the machine must be non-flammable, non-combustible and not sensitive to heat. It has to be twice as big as the machine. • Keep a minimum distance of 60 cm to all flammable, combustible objects and objects sensitive to heat. • Glycol is alcohol and burns with a slightly bluish, almost invisible flame. Never point the fog at strong sources of ignition like fire or pyrotechnic effects. • Never open the machine and leave the machine unattended when connected to a power supply. • It is only allowed to fly/hang the machine by using the original hanging set. • The visibility has to be more than 2 m in rooms where people walk around. • Do not swallow the fog fluid. Keep it away from children. In case of eye contact, rinse with a lot of water. Consult a doctor should you have accidentally swallowed some fluid. • Spilled fluid or splashed fluid droplets can cause slip hazard. Mop up the fluid and dispose of it according to regulations. • Fog may activate smoke detectors. Artificially-made fog can be produced in many different ways. The method used here to produce fog, with a device which works according to the vaporizer principle, is the most harmless one. -
Page 6: Description Of The Parts
3. Description of the parts Front view 1: Fog nozzle 2: Diverter 3: Fan grille and fan 4: Carrying handles 5: Filter 6: Castor dishes 7: Automatic wheels Rear view Control-Box orka luxe Look Solutions XXX = address PXX = pump FXX = fan · · active power in power out power out analog out analog out (FOG) (FAN) - Page 7 3. Description of the parts Rear view 8: Control-Box 9: Cable outlet 10: CEE-plug 11: 20L-Fluid tank 12: Velcro tape to secure the tank Tank lid 13 Plastic spigot Quick coupling Tank lid Filter...
-
Page 8: Fluid
4. Fluid 4.1 General notes The Orka deLuxe has been designed to be used with original Look fog fluids. The following Look fog fluids are available: Quick-Fog thick, quick disappearing fog fluid Regular-Fog thick, long lasting fog fluid Slow-Fog thick, extremely long lasting fog fluid If fluids have been used other than Look fog fluids we can‘t grant warranty. PLEASE NOTE: The vaporizer of our machines does not have to be cleaned! Cleaners, available on the market, can damage the vaporizer! We cannot grant warranty in this case. 4.2 Refilling the fluid tank Before refilling the fluid canister, make sure that there are no impurities inside the tank. If necessary, the canister must be rinsed out. This will prevent clogging of the heater. – Disconnect the tank lid by pressing the springs in the finger recesses inwards and lift out the cover. – Disconnect the fluid tube from the lid by pressing the quick coupling [13] and removing the plastic spigot [12]. – Loosen the Velcro and tilt the canister about 45 degrees. – To refill, unscrew the large blue cap from the canister and fill the tank with fluid. – Tilt the canister back in an upright position and tighten it with the Velcro strap. – Push the plastic spigot [12] into the quick coupling [13], until you hear a click. The spigot... -
Page 9: Operating The Orka Deluxe
5. Operating the Orka deLuxe 5.1 Selecting the location The location in which the Orka deLuxe is operated should – be dry, – be free from dusty or polluted air, – be free from vibrations, – be an non-flammable place or surface, – be well-ventilated with fog-free air keeping the ambient operating temperature between 5° C and 45° C and the relative air humidity below 80%. 5.2 Putting into operation XXX = address PXX = pump FXX = fan · · Active-LED active Up button... -
Page 10: Switching The Device Off
Press the Mode button until „ OFF” appears on the display. After 15 seconds the machine will switch off automatically. On the right bottom edge of the display a red dot will appear, indicating that the machine is not heating anymore. You can also switch off the machine within these 15 seconds by pressing the Enter button. b. If the DMX signal is lost, the device will be switched off automatically after 15 seconds for safety reasons. 5.4 Operating via DMX 512 Connect the Orka deLuxe to a DMX-desk using the 5pin-XLR socket „ DMXin“ of the con- trol box. As soon as the machine receives a correct DMX signal, the yellow DMX-LED shines. Now the pump and the fan can be adjusted via the lighting console. Please note: The Orka deLuxe uses two channels at the desk! Channel 1 = Pump, Channel 2 = Fan. 5.4.1 Adjusting the DMX start address a) Press the Mode button on the control panel, until three figures appear on the LED display. b) Adjust the requested start address by pressing the Up/Down buttons. -
Page 11: Rdm
5. Operating the Orka deLuxe c) Save the start address by pressing the Enter button once. Otherwise the start address will not be saved when you disconnect the machine from the mains supply. Adjust the pump and fan via the desk. If you switch off the console, the Orka deLuxe is automatically switched off aftr 15 seconds. 5.4.2 RDM The following functions are possible via RDM: - DMX-Patch: set/change/check the DMX start address and display DMX channels - Restart the device - General Information about the machine 5.5 Stand alone The Orka deLuxe can be used in the Stand alone mode. In this mode the control of the pump and the fan must be adjusted at the machine. a) Press and release the Mode button until a „ P” and two figures appear on the display. b) Adjust the pump output with the Up/Down buttons and press the Enter button once to start the fogging process. The machine now produces fog until the Enter-button is pressed again. The output can be changed during the fogging process by pressing the Up/Down buttons. To adjust the fan output a) press the Mode button again, until a „ F“ and two figures appear on the display. b) Adjust the fan output with the Up/Down buttons. -
Page 12: Cleaning, Care And Maintenance
6. Cleaning, Care and Maintenance – Make sure that the filters are not clogged with dust. If necessary, the filters must be cleaned. – Take care that the machine is not overheating. – Do not run the Orka deLuxe without any fluid, as the pump will run dry. – Wipe up spiled Fluid immediately. Moisture – also fluid – can destroy the electric of the machine. – Before refilling the fluid canister, make sure that there are no impurities inside the tank. If necessary, the canister must be rinsed out. This will prevent clogging the heater. – For cleaning the surface of the device use a suitable, solvent-free cleaner. – PLEASE NOTE: The vaporizer of our machines does not have to be cleaned! Cleaners, available on the market, can damage the vaporizer! We cannot grant warranty in this case. -
Page 13: Troubleshooting
7. Troubleshooting The fog machine does not fog • Check external control signals • Check mains supply • Check fluid tank (empty?) • Check for correct connections at the fluid bottle • Check for fluid in the fluid tube • Check if the tank lid is clogged • Disconnect the filter mat on the right side of the machine and check through the grille, whether the display shows a malfuntion code (f.e. E - 1). If yes, please contact your dealer for further information. The fog machine fogs uncontrollably • Check mains supply • Check unit for moisture (moisture inside the machine, especially on the PCB can cause fogging) The fog machine switches off suddenly • The „ Temperature cutout“ has switched off due to overheating. Remove external heat source (for instance lamps shining right onto the housing) and ensure fresh air supply. After 15 to 30 minutes the unit should switch back to „ on“ again. Loud droning sound during fogging • The pump is running dry. Avoid this absolutely! • Refill the fluid bottle • Double check connection fluid tube and fluid bottle. -
Page 14: Specifications
8. Specifications Fog generator Procedure: vaporizing fog generator Power requirement: 9000 Watt Voltage: 400 V/50 Hz/16 A CEE Heat-up time: approx. 15 min. Fluid tank capacity: 20 Litres Fluid consumption: 500 ml/min. a max. output Fog output: adjustable in 99 steps, steps à 1% Output projection: max. 30 m Fogging time: at 100% output: approx. 2.5 min. at <50% output: continuous output Control: DMX 512 Stand alone mode Temperature control: Microprocessor controlled Overheating protection: Heater block/Thermostat Pump/Thermal switch Procedure: Centrifugal blower Power requirement: 450 Watt Voltage: 230 V/ 50/60 Hz Air volume: 1605 m Current: 2.8 A Dimensions incl. flight case (L x W x H): 77 x 49.5 x 83.5 cm... -
Page 15: Warranty Conditions
2. Guarantee Service will be done in the following way: Faulty parts will be repaired or replaced (our choice) with correct parts. Faulty units have to be brought to us or our service centres or to be sent to us or our service centres at customer‘s expense. The invoice and/or receipt showing the purchase date and the serial number has to come with the faulty unit, otherwise this will not be guarantee service. Replaced parts become our property. 3. The customer loses all rights for guarantee services, if any repairs or adjustments are done to the units by unauthorized persons and/or if spare parts are used which are not approved by us. The right of guarantee service is also lost if fluids other than original Look fog fluids have been used or if units are sent to us with full fluid bottles. Also non compliance with the instructions in this manual or mistakes by incorrect handling/treating of the machine will lead to a loss of guarantee and also any faults and damages caused by undue force. 4. Certain parts of the machine are „ consumable parts” and are not covered by the warranty. 5. Guarantee services do not cause an extension of the guarantee time or the start of a new guarantee time. The warranty for replaced parts ends with the guarantee time of the whole unit. 6. If a defect/fault can not be repaired by us in a satisfactory time, we will, within 6 months after sale of the unit, on choice of the customer, either: • replace the whole unit for free or • refund the lesser value or • take back the whole unit and refund the purchase price, but not more than the usual market price at the time of the refund. 7. Further claims, especially for damages, losses etc. outside the unit are excluded. Other guarantee regulations may be valid outside Germany. Please check with your dealer! If you should send the unit for service, do not forget to remove any liquid from the fluid bottle. Manufactured for: Look Solutions GmbH & Co. KG • Bünteweg 33 • D - 30989 Gehrden • www.looksolutions.com... - Page 16 Look Solutions product...
