- Page 1 Operating manual TINY a Look Solutions product...
- Page 2 Set of Equipment supplied – 1 Tiny F07 – 1 Powercord with push-pull plugs – 1 control panel with cable – 1 rechargeable battery-pack 11.1V – 1 charger – 1 fluid tank (50 milliliters) with quick connector and air valve –...
-
Page 3: Table Of Contents
1. Procedure of the Tiny-Fogger 2. Safety Instructions 3. Descriptions of the parts 4. Fluid 4.1 General 5. Operating the Tiny F07 5.1 Selecting the Location 5.2 Mounting the Tiny F07 5.3 Starting-up the Tiny F07 5.4 Programming of a fixed fogging time 5.4.1 Programming the fogging time... -
Page 4: Procedure Of The Tiny-Fogger
However, the Tiny F07 only heats when fog is actually produced. Due to the Sleep-mode the Tiny F07 uses only 15 mA in idle status and conse- quently it may remain connected to the the battery for several hours with no discharging to speak of. -
Page 5: Safety Instructions
2. Safety instructions A fog machine is not a toy! • Very hot steam escapes from the nozzle. Danger of getting burnt. • Occasionally very hot droplets of fluid may escape when in operation. Thus never aim at persons directly and keep a minimum distance of 3 m to the nozzle. -
Page 6: Descriptions Of The Parts
3. Description of the parts 1: · Air slots 4: · Start button 2: · Fog nozzle 5: · Yellow LED 3: · Screws to unscrew the stainless steel hood · Start button · Sockets for control panel and radio remote... - Page 7 3. Description of the parts · Socket for connecting · Connector for the cable of the control fluid tube panel or the receiver of the radio remote · Socket for connecting the battery cable 6: · Screws for connecting the vaporizer to the connecting pins 7: ·...
-
Page 8: Fluid
Please do not use Tiny-fluid if it looks blue or green. This can clog the vaporizer! Note: If the Tiny F07 will not be in use for a long period, please empty the fluid tank and pour the fluid back into the original fluid bottle despatched with the unit. -
Page 9: Starting-Up The Tiny F07
Caution: Do not put anything into the fog nozzle. This may destroy the vaporizer and it then has to be changed (see point 8.1) Sleep-mode: After approx. 1 minute the Tiny F07 automatically switch to the Sleep-mode. The yellow LED [5] does not light anymore. The machine can be activated at any time by pressing the start button at the lid, the cable remote or the radio remote. -
Page 10: Delete A Fixed Fogging Time
The programmed fogging time cannot be recalled by pressing the start button in the machines lid [4]. If the start button in the lid is pressed, the Tiny F07 will produce fog as long as the button is hold down, no matter whether a fogging time has been programmed in. -
Page 11: The Rechargeable Battery
The supplied battery is a maintenance-free 11.1V Lithium-Polymer-battery. It can be used in every position. The connection to the Tiny F07 is established by a powercord with a push-pull- plug. The connection to the charger is established by a low volt plug at the charger. -
Page 12: Fuse
6. The Battery Lithium-Polymer-batteries must only be recharged and stored on fireproofed and not inflammable subsoils! The battery must not be recharged unsupervised. The ambient operating temperature while charging should be between 10°C and 40°C. 6.5 Fuse To avoid too high emitting current, the battery-pack is equipped with a 7.5 A Miniblade-fuse. -
Page 13: The Charger
– If the yellow Charge-LED does not expire even after 1.5 hours, the battery-pack might be damaged and should not be used anymore. – Cover the charger against heat and wet. – Use the charger exclusively for charging the Tiny F07 and Tiny C07 battery. 7.3 Technical Data Model... -
Page 14: Service And Maintenance
8. Service and Maintenance 8.1 Changing the Vaporizer The micro vaporizer especially developed for the Tiny F07 has a limited working life. Depending on application duration, the fogging output will reduce after a while and the vaporizer has to be changed. -
Page 15: Calibrating The Vaporizer
8. Service and Maintenance 8.1.3 Calibrating the Vaporizer Since all vaporizers have different electrical qualities, the Tiny F07 must be calibrated after every exchange of the vaporizer. IMPORTANT: During the calibration process the vaporizer temperature must be at 20° C. Never start fogging before the calibrating process. Too cold or too warm units must first adapt to the room temperature (20°... -
Page 16: The Machine Does Not Work Perfectly
Vaporizer cannot be calibrated: Try once again to calibrate the vaporizer as explained in point 8.1. If this should not help, the vaporizer is broken and cannot be used. – lights permanently The battery is completely discharged: Disconnect the Tiny F07 from the battery- pack and recharge the battery. -
Page 17: The New Vaporizer Cannot Be Calibrated
– Should the vaporizer become clogged, please change it in the way as described in section 8.1. – If the Tiny F07 isn‘t in use for a longer time, please take care that the fluid tube is emptied. It could be that some fluid drops come out of the nozzle and the surrounding gets wet and greasy. -
Page 18: Technical Data
Continuous output with battery 10 min. Temperature control Microprocessor Control cable remote radio remote (option) Dimensions (L x W x H) 10.6 x 4.9 x 5.0 cm Weight TINY approx. 310 g Look Solutions Manufactured for - Fog machines made in Germany... -
Page 19: Warranty Conditions
10. Warranty conditions For the miniature fog machine Tiny F07 Look‘ guarantee is: 1. Free of charge, subject to the following conditions (No. 2 - 6) we will repair any defect or fault in the unit if it is caused by a proven factory fault and has been advised immediately after appearance and within 24 month of delivery to the end user. - Page 20 Look Solutions product...
