8. OIL CADDY
The Oil Caddy is welded to the Opener's Tool Box and is designed to serve
a dual purpose. Primarily, the Oil Caddy allows the operator to keep a
bottle of air tool oil on-hand at all times; secondly, the Oil Caddy serves as
a reminder to check the oil level in the Lubricator. The oil level should be
checked daily.
9. CYLINDER SHIELD
The Cylinder Shield protects the pneumatic cylinder which shifts the
pivoting linkage at the cylinder plate forcing the shaft and fork frame to
turn at a predetermined angle. The Cylinder Shield has safety lock
pinholes that extend through the pivoting linkage plates and restrict wheel
direction change until the pin is removed. This pivot wheel action allows
the GO-A8 to travel with rolling capstans.
10. PIVOT LOCKING PIN
The Pivot Locking Pin is used to lock the wheels and the Height
Adjustment Forks in the straight or pivot position. The Pin, attached to
the GO-A8 by a coated lanyard, must be removed before actuating the
pivot Toggle Switch. The Pin should be reinserted into the correct pinhole
on the Cylinder Shield when the wheels are in the desired position. A
label located on the Cylinder Shield, See Figure 3, shows which pin hole
is used to lock the GO-A8's wheels in the desired position.
Figure 3: Locking Pin Label
CAUTION
STEERING LOCK PIN MUST
BE REMOVED BEFORE
ACTUATING PIVOT WHEEL
CONTROL SWITCH
PIVOT
LOCK
STRAIGHT
LOCK
7
