Page 1 Compass 2 0 1 8 O W N E R ’ S M A N U A L...
Page 2 VEHICLES SOLD IN CANADA This manual illustrates and describes the operation of With respect to any Vehicles Sold in Canada, the name features and equipment that are either standard or op- FCA US LLC shall be deemed to be deleted and the name tional on this vehicle.
Page 3 TABLE OF CONTENTS SECTION PAGE INTRODUCTION ..............3 GRAPHICAL TABLE OF CONTENTS .
Page 5 INTRODUCTION CONTENTS INTRODUCTION ......4 ▫ Symbols .......6 ROLLOVER WARNING .
Page 6: Introduction 3
When it comes to service, remember that your authorized dealer knows your Jeep® vehicle best, has factory-trained technicians and genuine MOPAR® parts, and cares about your satisfaction.
Page 7: Introduction
INTRODUCTION HOW TO USE THIS MANUAL Essential Information Consult the Table of Contents to determine which section contains the information you desire. Since the specification of your vehicle depends on the items of equipment ordered, certain descriptions and illustra- tions may differ from your vehicle’s equipment. The detailed index at the back of this Owner’s Manual contains a complete listing of all subjects.
Page 8: Symbols
6 INTRODUCTION Symbols Consult the following table for a description of the symbols that may be used on your vehicle or throughout this Owner’s Manual:...
Page 9: Warnings And Cautions
INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against oper- ating procedures that could result in a collision, bodily injury and/or death. It also contains CAUTIONS against procedures that could result in damage to your vehicle. If you do not read this entire Owner’s Manual, you may miss important information.
Page 11 GRAPHICAL TABLE OF CONTENTS CONTENTS FRONT VIEW ......10 INTERIOR ......13 REAR VIEW.
Page 12 10 GRAPHICAL TABLE OF CONTENTS FRONT VIEW Front View 1 — Hood/Engine Compartment 4 — Wheels/Tires 2 — Headlights 5 — Exterior Mirrors 3 — Windshield 6 — Doors...
Page 13 GRAPHICAL TABLE OF CONTENTS 11 REAR VIEW Rear View 1 — Rear Lights 2 — Rear Windshield Wiper 3 — Liftgate...
Page 14 12 GRAPHICAL TABLE OF CONTENTS INSTRUMENT PANEL Instrument Panel 1 — Headlight Switch 5 — Instrument Cluster 2 — Air Vents 6 — Windshield Wiper Lever 3 — Multifunction Lever (Behind Steering Wheel) 7 — Glove Compartment 4 — Steering Wheel...
Page 15 GRAPHICAL TABLE OF CONTENTS 13 INTERIOR Interior Features 1 — Power Window Switches 5 — Climate Controls 2 — Seats 6 — Switch Panel 3 — Select Terrain Mode Knob — If Equipped 7 — Uconnect Radio 4 — Transmission Gear Selector (Automatic/Manual Options)
Page 17: Table Of Contents
GETTING TO KNOW YOUR VEHICLE CONTENTS KEYS ....... . .19 ▫...
Page 18 16 GETTING TO KNOW YOUR VEHICLE ▫ Power Door Locks ..... .34 ▫ Inside Day/Night Mirror — If Equipped ..51 ▫...
Page 19 GETTING TO KNOW YOUR VEHICLE 17 ▫ Lights-On Reminder .....58 ▫ Automatic Temperature Control (ATC) — If Equipped ......76 ▫...
Page 20 18 GETTING TO KNOW YOUR VEHICLE ▫ Opening Power Shade — Manual Mode ..85 ▫ Closing ......88 ▫...
Page 21: Keys
GETTING TO KNOW YOUR VEHICLE 19 KEYS Key Fob Your vehicle uses a keyless ignition system. The ignition system consists of a key fob with Remote Keyless Entry (RKE) and a START/STOP push button ignition system. The Remote Keyless Entry system consists of a key fob and Keyless Enter-N-Go feature if equipped.
Page 22 20 GETTING TO KNOW YOUR VEHICLE All doors can be programmed to unlock on the first push of the unlock button. Refer to “Uconnect Settings” in “Multi- media” for further information. The turn signal lights will flash to acknowledge the unlock signal.
Page 23 GETTING TO KNOW YOUR VEHICLE 21 Replacing The Battery In The Key With Remote Control The recommended replacement battery is one CR2032 battery. NOTE: • Perchlorate Material — special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate for fur- ther information. • Do not touch the battery terminals that are on the back housing or the printed circuit board.
Page 24 22 GETTING TO KNOW YOUR VEHICLE 2. Separate the key fob halves using the tip of the emer- gency key, a #2 flat blade screwdriver, or a coin and gently pry the two halves of the key fob apart. Make sure not to damage the seal during removal.
Page 25 GETTING TO KNOW YOUR VEHICLE 23 Programming Additional Key Fobs Programming the key fob may be performed by your authorized dealer. Request For Additional Key Fobs NOTE: Only key fobs that are programmed to the vehicle electronics can be used to start and operate the vehicle. Once a key fob is programmed to a vehicle, it cannot be programmed to any other vehicle.
Page 26: Ignition Switch
24 GETTING TO KNOW YOUR VEHICLE General Information The START/STOP push button ignition has three operating modes. The three modes are OFF, ON/RUN, and START. The following regulatory statement applies to all radio frequency (RF) devices equipped in this vehicle: NOTE: If the ignition state/mode does not change with the push of a button, the key fob may have a low or dead This device complies with Part 15 of the FCC Rules and...
Page 27: Vehicle On Message
GETTING TO KNOW YOUR VEHICLE 25 The push button ignition can be placed in the following WARNING! (Continued) modes: should be warned not to touch the parking brake, brake pedal or the gear selector. • Do not leave the key fob in or near the vehicle, or in •...
Page 28: Remote Start - If Equipped
26 GETTING TO KNOW YOUR VEHICLE to remind you to place the ignition in the OFF mode. In WARNING! (Continued) addition to the chime, the Vehicle On message will display should be warned not to touch the parking brake, in the cluster. brake pedal or the gear selector.
Page 29: Remote Start Abort Message On The Instrument Cluster Display - If Equipped
GETTING TO KNOW YOUR VEHICLE 27 • To drive the vehicle, push unlock button, insert the key • Ignition in STOP/OFF position in the ignition and turn to the ON/RUN position. • Fuel level meets minimum requirement • With remote start, the engine will only run for 15 •...
Page 30: To Enter Remote Start Mode
28 GETTING TO KNOW YOUR VEHICLE • Remote Start Aborted — Liftgate Open • The engine can be started two consecutive times with the key fob. However, the ignition must be cycled by • Remote Start Disabled — Start Vehicle To Reset pushing the START/STOP button twice (or the ignition •...
Page 31: Remote Start Comfort Systems - If Equipped
GETTING TO KNOW YOUR VEHICLE 29 Remote Start Windshield Wiper De–Icer Activation NOTE: — If Equipped • For vehicles not equipped with the Keyless Enter-N-Go — Passive Entry feature, the ignition switch must be in When remote start is active and the outside ambient the ON/RUN position in order to drive the vehicle.
Page 32: Sentry Key
30 GETTING TO KNOW YOUR VEHICLE SENTRY KEY occur, have the vehicle serviced as soon as possible by your authorized dealer. The Sentry Key Immobilizer system prevents unauthorized vehicle operation by disabling the engine. The system does CAUTION! not need to be armed or activated. Operation is automatic, regardless of whether the vehicle is locked or unlocked.
Page 33: Customer Key Programming
GETTING TO KNOW YOUR VEHICLE 31 NOTE: Duplication of key fobs may be performed at your NOTE: Changes or modifications not expressly approved authorized dealer. This procedure consists of programming by the party responsible for compliance could void the a blank key fob to the vehicle electronics. A blank key fob user’s authority to operate the equipment.
Page 34: To Arm The System
32 GETTING TO KNOW YOUR VEHICLE To Arm The System NOTE: • The driver’s door key cylinder and the liftgate button on Follow these steps to arm the vehicle security alarm: the key fob cannot arm or disarm the vehicle security 1.
Page 35: Security System Manual Override
GETTING TO KNOW YOUR VEHICLE 33 remain armed when the battery is reconnected; the exterior WARNING! lights will flash, and the horn will sound. If this occurs, disarm the vehicle security alarm. • For personal security and safety in the event of a collision, lock the vehicle doors before you drive as Security System Manual Override well as when you park and exit the vehicle.
Page 36: Power Door Locks
34 GETTING TO KNOW YOUR VEHICLE Power Door Locks Keyless Enter-N-Go — Passive Entry A power door lock switch is located on each of the front The Passive Entry system is an enhancement to the vehi- door trim panels. Use this switch to lock or unlock the cle’s Remote Keyless Entry system and a feature of Keyless doors, liftgate and fuel door.
Page 37 GETTING TO KNOW YOUR VEHICLE 35 To Unlock From The Driver’s Side To Unlock From The Passenger Side With a valid Passive Entry key fob within 5 ft (1.5 m) of the With a valid Passive Entry key fob within 5 ft (1.5 m) of the driver’s door handle, grab the front driver door handle to passenger door handle, grab the front passenger door unlock the driver’s door automatically.
Page 38 36 GETTING TO KNOW YOUR VEHICLE • A lock request is made by the door panel switch while To Lock The Liftgate the door is open. With a valid Passive Entry key fob within 5 ft (1.5 m) of the When any of these situations occur, after all open doors are liftgate, push the passive entry lock button located to the shut, the FOBIK-Safe search will be executed.
Page 39 GETTING TO KNOW YOUR VEHICLE 37 the passive entry lock button located on the outside door handle, to lock the vehicle doors and liftgate. NOTE: DO NOT grab the door handle, when pushing the door handle lock button. This could unlock the door(s). DO NOT Grab The Door Handle When Locking NOTE: •...
Page 40: Automatic Unlock Doors On Exit
38 GETTING TO KNOW YOUR VEHICLE • The Passive Entry system will not operate if the key fob engaged, that door can only be opened by using the battery is dead. outside door handle even if the inside door lock is in the unlocked position.
Page 41: Seats
GETTING TO KNOW YOUR VEHICLE 39 SEATS • After engaging the Child-Protection Door Lock system, always test the door from the inside to make certain it is Seats are a part of the Occupant Restraint System of the in the desired position. vehicle.
Page 42: Manual Seats - If Equipped
40 GETTING TO KNOW YOUR VEHICLE Manual Seats — If Equipped While sitting in the seat, lift up on the bar and move the seat forward or rearward. Release the bar once you have Manual Front Seat Forward/Rearward Adjustment reached the desired position. Then, using body pressure, On models equipped with manual seats, the adjusting bar move forward and rearward on the seat to be sure that the is located at the front of the seats, near the floor.
Page 43 GETTING TO KNOW YOUR VEHICLE 41 Manual Seat Height Adjustment — If Equipped The driver’s seat height can be raised or lowered by using a lever, located on the outboard side of the seat. Pull upward on the lever to raise the seat height or push downward on the lever to lower the seat height.
Page 44: Power Seats - If Equipped
42 GETTING TO KNOW YOUR VEHICLE instrument panel). The fold-forward seat back has a soft- back surface that you cannot use as a work surface when the seat is folded forward and the vehicle is not in motion. Pull upward on the recline lever to fold or unfold the seat. NOTE: You may experience deformation in the seat cush- ion from the seat belt buckles if the seats are left folded for an extended period of time.
Page 45 GETTING TO KNOW YOUR VEHICLE 43 Tilt Adjustment The angle of the seat cushion can be adjusted up or down. Pull upward or push downward on the front of the seat switch and the front of the seat cushion will move in the direction of the switch.
Page 46: Front Heated Seats - If Equipped
44 GETTING TO KNOW YOUR VEHICLE Front Heated Seats — If Equipped Power Lumbar — If Equipped Vehicles equipped with power driver or passenger seats The front heated seats control buttons are located within may be equipped with power lumbar. The power lumbar the Uconnect system.
Page 47: 60/40 Split Folding Rear Seat With Fold-Flat Feature
GETTING TO KNOW YOUR VEHICLE 45 60/40 Split Folding Rear Seat With Fold-Flat Vehicles With Remote Start — If Equipped Feature On models that are equipped with remote start, the heated seats can be programmed to come on during a remote start. To provide additional storage area, each rear seat can be folded flat.
Page 48: Head Restraints
46 GETTING TO KNOW YOUR VEHICLE The release lever will show a red indicator while in the unlocked position. Once the seat is locked in, the red indicator will no longer be visible. WARNING! Be certain that the seatback is securely locked into position.
Page 49: Front Head Restraint Adjustment
GETTING TO KNOW YOUR VEHICLE 47 top of the head restraint to the forward most position and WARNING! (Continued) release. The head restraint will return to the rear most order to minimize the risk of neck injury in the event position.
Page 50: Rear Head Restraints
48 GETTING TO KNOW YOUR VEHICLE To raise the head restraint, pull upward on the head WARNING! restraint. To lower the head restraint, push the adjustment button, located at the base of the head restraint, and push • All occupants, including the driver, should not oper- downward on the head restraint.
Page 51: Steering Wheel
GETTING TO KNOW YOUR VEHICLE 49 STEERING WHEEL Tilt/Telescoping Steering Column This feature allows you to tilt the steering column upward or downward. It also allows you to lengthen or shorten the steering column. The tilt/telescoping lever is located below the steering wheel at the end of the steering column.
Page 52: Heated Steering Wheel - If Equipped
50 GETTING TO KNOW YOUR VEHICLE • Press the heated steering wheel button lock the steering column in position, push the control once to turn handle upward until fully engaged. the heating element on. • Press the heated steering wheel button a second time WARNING! to turn the heating element off.
Page 53: Mirrors
GETTING TO KNOW YOUR VEHICLE 51 WARNING! (Continued) • Do not place anything on the steering wheel that insulates against heat, such as a blanket or steering wheel covers of any type and material. This may cause the steering wheel heater to overheat. MIRRORS Inside Day/Night Mirror —...
Page 54: Outside Mirrors
52 GETTING TO KNOW YOUR VEHICLE NOTE: CAUTION! • The Electrochromic Mirror feature is disabled when the To avoid damage to the mirror during cleaning, never vehicle is in REVERSE to improve rear view viewing. spray any cleaning solution directly onto the mirror. •...
Page 55: Power Adjustment Mirrors
GETTING TO KNOW YOUR VEHICLE 53 Power Adjustment Mirrors The power mirror switch is located on the driver’s door panel. To adjust an exterior power mirror, select the right or left side using the mirror selector switch, then push the mirror adjustment switch in the desired direction indicated by the direction arrows.
Page 56: Folding Mirrors
54 GETTING TO KNOW YOUR VEHICLE Folding Mirrors Resetting The Power Folding Outside Mirrors The exterior mirrors are hinged to allow the mirror to pivot You may need to reset the power folding mirrors if the forward or rearward to help avoid damage. The mirror has following occurs: three detent positions: full forward, normal and full rear- •...
Page 57: Illuminated Vanity Mirrors
GETTING TO KNOW YOUR VEHICLE 55 Illuminated Vanity Mirrors Sun Visor “Slide-On-Rod” Feature — If Equipped An illuminated vanity mirror is located on each sun visor. The sun visor “Slide-On-Rod” feature allows for additional To use the mirror, rotate the sun visor down and swing the flexibility in positioning the sun visor to block out the sun.
Page 58: Daytime Running Lights (Drl) - If Equipped
56 GETTING TO KNOW YOUR VEHICLE NOTE: If allowed by law in the country in which the vehicle was purchased the Daytime Running Lights can be turned on and off using the Uconnect System, refer to “Uconnect Settings” in “Multimedia” for further informa- tion.
Page 59: High/Low Beam Switch
GETTING TO KNOW YOUR VEHICLE 57 High/Low Beam Switch NOTE: • The Automatic High Beam Headlamp Control can be Push the multifunction lever toward the instrument panel turned on or off using the Uconnect System. Refer to to switch the headlights to high beams. Pulling the multi- “Uconnect Settings”...
Page 60: Automatic Headlights - If Equipped
58 GETTING TO KNOW YOUR VEHICLE Automatic Headlights — If Equipped If you turn the headlights or parking lights on, or place the ignition in ACC or RUN, the system will cancel the delay. This system automatically turns the headlights on or off according to ambient light levels.
Page 61: Fog Lights - If Equipped
GETTING TO KNOW YOUR VEHICLE 59 Fog Lights — If Equipped NOTE: The fog lights will operate with the low beam headlights or parking lights on. However, selecting the The front fog light switch is built into the headlight switch. high beam headlights will turn off the fog lights.
Page 62: Lane Change Assist
60 GETTING TO KNOW YOUR VEHICLE Lane Change Assist Tap the lever up or down once, without moving beyond the detent, and the turn signal (right or left) will flash five times then automatically turn off. Battery Saver Feature To protect the battery, the interior lights will turn off automatically 15 minutes after the ignition switch is moved to the LOCK position.
Page 63 GETTING TO KNOW YOUR VEHICLE 61 Instrument Panel Dimmer Control Ambient Light Control — If Equipped The instrument panel dimmer control is part of the head- Rotate the ambient dimmer control upward or downward light switch and is located on the drivers side of the to increase or decrease the brightness of the ambient light instrument panel.
Page 64: Windshield Wipers And Washers
62 GETTING TO KNOW YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS interval is based on vehicle speed. Rotate to the third detent for low wiper operation and the fourth detent for The windshield wiper/washer controls are located on the high wiper operation. windshield wiper/washer lever on the right side of the steering column.
Page 65: Rain Sensing Wipers - If Equipped
GETTING TO KNOW YOUR VEHICLE 63 CAUTION! (Continued) WARNING! • Failure to follow these cautions can cause damage to Sudden loss of visibility through the windshield could the heating elements: lead to a collision. You might not see other vehicles or •...
Page 66: Rear Window Wiper/Washer
64 GETTING TO KNOW YOUR VEHICLE The sensitivity of the system can be adjusted with the speed is greater than 3 mph (5 km/h), or the wiper multifunction lever. Wiper delay position one is the least switch is moved out of and back into the Intermittent sensitive, and wiper delay position two is the most sensi- wipe position.
Page 67: Windshield Wiper De-Icer - If Equipped
GETTING TO KNOW YOUR VEHICLE 65 Windshield Wiper De-Icer — If Equipped • Vehicle in REVERSE: If the front wiper is active and the REVERSE gear is selected, the wiper will turn on for one Your vehicle may be equipped with a Windshield Wiper wipe.
Page 68: Climate Controls
66 GETTING TO KNOW YOUR VEHICLE CLIMATE CONTROLS Climate Controls Without A Touchscreen Overview The controls for the heating and air conditioning system in this vehicle can consist of a series of outer rotary dials, inner push knobs, and/or a touchscreen. These comfort controls can be set to obtain desired interior conditions.
Page 69 GETTING TO KNOW YOUR VEHICLE 67 Icon Description A/C Button Press and release to change the current setting, the indicator illuminates when A/C is ON. Recirculation Button Press and release this button to change the system between recirculation mode and outside air mode.
Page 70 68 GETTING TO KNOW YOUR VEHICLE Icon Description Rear Defrost Button Push and release the Rear Defrost Control button to turn ON the rear window defroster and the heated outside mirrors (if equipped). An indicator will illuminate when the rear window de- froster is on.
Page 71 GETTING TO KNOW YOUR VEHICLE 69 Icon Description Bi-Level Mode Bi-Level Mode Air comes from the instrument panel outlets and floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. NOTE: Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel out- lets and warmer air from the floor outlets.
Page 72: Climate Controls With A Touchscreen Overview
70 GETTING TO KNOW YOUR VEHICLE Climate Controls With A Touchscreen Overview inner push knobs, and/or a touchscreen. These comfort controls can be set to obtain desired interior conditions. The controls for the heating and air conditioning system in this vehicle can consist of a series of outer rotary dials, Uconnect 4 With 7-inch Display Automatic Climate Controls...
Page 73 GETTING TO KNOW YOUR VEHICLE 71 Uconnect 4/4C NAV With 8.4-inch Display Automatic Climate Controls Climate Controls Description Icon Description MAX A/C Button Press and release the MAX A/C Button in the touchscreen to change the current setting to the coldest output of air.
Page 74 72 GETTING TO KNOW YOUR VEHICLE Icon Description Recirculation Button Press and release this button to change the system between recirculation mode and outside air mode. Recirculation can be used when outside conditions such as smoke, odors, dust, or high humidity are present.
Page 75 GETTING TO KNOW YOUR VEHICLE 73 Icon Description Rear Defrost Button Push and release the Rear Defrost Control button to turn ON the rear window defroster and the heated outside mirrors (if equipped). An indicator will illuminate when the rear window de- froster is on.
Page 76 74 GETTING TO KNOW YOUR VEHICLE Icon Description Touchscreen • Faceplate: The blower speed increases as you turn the blower control knob clockwise from Buttons the lowest blower setting. The blower speed decreases as you turn the blower control knob counterclockwise.
Page 77: Climate Control Functions
GETTING TO KNOW YOUR VEHICLE 75 Icon Description Floor Mode Floor Mode Air comes from the floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. Mix Mode Mix Mode Air is directed through the floor, defrost, and side window demister outlets. This setting works best in cold or snowy conditions that require extra heat to the windshield.
Page 78: Getting To Know Your Vehicle
76 GETTING TO KNOW YOUR VEHICLE Automatic Temperature Control (ATC) — If MAX A/C Equipped MAX A/C sets the control for maximum cooling perfor- mance. Press and release to toggle between MAX A/C and Automatic Operation the prior settings. The button illuminates when MAX A/C 1.
Page 79: Operating Tips
GETTING TO KNOW YOUR VEHICLE 77 Operating Tips NOTE: • It is not necessary to move the temperature settings for NOTE: Refer to the chart at the end of this section for cold or hot vehicles. The system automatically adjusts suggested control settings for various weather conditions.
Page 80 78 GETTING TO KNOW YOUR VEHICLE Vacation/Storage Outside Air Intake Before you store your vehicle, or keep it out of service (i.e., Make sure the air intake, located directly in front of the vacation) for two weeks or more, run the air conditioning windshield, is free of obstructions, such as leaves.
Page 81 GETTING TO KNOW YOUR VEHICLE 79 Operating Tips Chart...
Page 82: Windows
80 GETTING TO KNOW YOUR VEHICLE WINDOWS NOTE: For vehicles equipped with the Uconnect, the power window switches will remain active for up to ten Power Window Controls minutes after the ignition is cycled to the OFF position. The window controls on the driver’s door control all the Opening either front door will cancel this feature.
Page 83: Auto-Up Feature With Anti-Pinch Protection
GETTING TO KNOW YOUR VEHICLE 81 To open the window part way, push the window switch WARNING! down briefly and release it when you want the window to stop. There is no anti-pinch protection when the window is almost closed. To avoid personal injury be sure to clear To stop the window from going all the way down during your arms, hands, fingers and all objects from the the Auto-Down operation, pull up on the switch briefly.
Page 84: Window Lockout Switch
82 GETTING TO KNOW YOUR VEHICLE Window Lockout Switch Wind Buffeting The window lockout switch on the driver’s door trim panel Wind buffeting can be described as the perception of allows you to disable the window controls on the rear pressure on the ears or a helicopter-type sound in the ears.
Page 85: Power Sunroof With Power Shade - If Equipped
GETTING TO KNOW YOUR VEHICLE 83 POWER SUNROOF WITH POWER SHADE — IF WARNING! EQUIPPED • Never leave children unattended in a vehicle, or with The power sunroof switches are located between the sun access to an unlocked vehicle. Never leave the key visors on the overhead console.
Page 86: Opening Sunroof - Express
84 GETTING TO KNOW YOUR VEHICLE Opening Sunroof — Express hold the switch again, the sunroof will open to the full open position and automatically stop. Any release of the A comfort stop position and full open position are the switch will stop the movement.
Page 87: Opening Power Shade - Express
GETTING TO KNOW YOUR VEHICLE 85 NOTE: Push and hold the shade switch again and the shade will open automatically to the full-open position. Any release of • If the sunshade is in the closed position when the vent the switch will stop the movement and the shade will switch is pushed, the sunshade will automatically cycle remain in a partially opened condition until the switch is to the halfway open position prior to the sunroof open-...
Page 88: Pinch Protect Feature
86 GETTING TO KNOW YOUR VEHICLE Pinch Protect Feature Sunroof Maintenance This feature will detect an obstruction in the opening of the Use only a non-abrasive cleaner and a soft cloth to clean the sunroof during Express Close operation. If an obstruction glass panel.
Page 89: Closing The Hood
GETTING TO KNOW YOUR VEHICLE 87 Closing The Hood 2. Move to the outside of the vehicle. The safety latch release lever is located behind the front edge of the hood at the center. Reach in at the center of the hood with a WARNING! palm facing the ground.
Page 90: Closing
88 GETTING TO KNOW YOUR VEHICLE The overhead console switch will release the liftgate when WARNING! the liftgate is unlocked or locked. The outside handle requires the liftgate to be unlocked. Driving with the liftgate open can allow poisonous exhaust gases into your vehicle. You and your passen- gers could be injured by these fumes.
Page 91: Power Liftgate - If Equipped
GETTING TO KNOW YOUR VEHICLE 89 Using any of the above ways: • When the liftgate is fully closed, the liftgate will open. • When the liftgate is fully open, the liftgate will close. • When the liftgate is moving, the liftgate will reverse. The key fob and the overhead console switch will open the liftgate when the liftgate is locked.
Page 92 90 GETTING TO KNOW YOUR VEHICLE • If the power liftgate encounters multiple obstructions Lock The Vehicle within the same cycle, the system will automatically WARNING! stop. If this occurs, the liftgate must be opened or closed manually. During power operation, personal injury or cargo •...
Page 93: Cargo Area Features
GETTING TO KNOW YOUR VEHICLE 91 • If your liftgate is power closing and you put the vehicle NOTE: Allow the power system to open the liftgate. in gear, the liftgate will continue to power close. How- Manually pushing or pulling the liftgate may activate the ever, vehicle movement may result in a detection of an liftgate obstacle detection feature and stop the power obstruction.
Page 94 92 GETTING TO KNOW YOUR VEHICLE To change the level of the load floor, pull upward on the Do not raise the floor beyond the point of resistance. In load floor handle, pull the floor outward, and place the vehicles equipped with a power liftgate, forcing the floor back of the floor into the desired position.
Page 95 GETTING TO KNOW YOUR VEHICLE 93 WARNING! • Cargo tie-downs are not safe anchors for a child seat tether strap. In a sudden stop or accident, a tie-down could pull loose and allow the child seat to come loose. A child could be badly injured. Use only the anchors provided for child seat tethers.
Page 96: Internal Equipment
94 GETTING TO KNOW YOUR VEHICLE INTERNAL EQUIPMENT WARNING! (Continued) Storage over or behind the rear axle can cause the vehicle to sway. Glove Compartment • Do not pile luggage or cargo higher than the top of The glove compartment is located on the passenger side of the seatback.
Page 97: Cupholders
GETTING TO KNOW YOUR VEHICLE 95 Cupholders The center console armrest can also be adjusted forward and rearward by pushing in the desired direction until it There are two cupholders for the front seat passengers, locks into place. located in the center console. Center Console Front Cupholders The center console has a storage area which can hold cell...
Page 98 96 GETTING TO KNOW YOUR VEHICLE Power outlets labeled with a “key” are powered when the The front power outlet is located on the center stack of the ignition is in the ON or ACC position, while the outlets instrument panel. labeled with a “battery”...
Page 99 GETTING TO KNOW YOUR VEHICLE 97 WARNING! (Continued) • Close the lid when not in use and while driving the vehicle. • If this outlet is mishandled, it may cause an electric shock and failure. CAUTION! • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e., cellular phones, etc.).
Page 100: Power Inverter - If Equipped
98 GETTING TO KNOW YOUR VEHICLE Power Inverter — If Equipped The power inverter is designed with built-in overload protection. If the power rating of 150 Watts is exceeded, the power inverter will automatically shut down. Once the electrical device has been removed from the outlet the inverter should automatically reset.
Page 101 GETTING TO KNOW YOUR VEHICLE 99 NOTE: Crossbars can be purchased at your authorized CAUTION! (Continued) dealer through Mopar parts. • Long loads, which extend over the windshield, such External racks do not increase the total load carrying as wood panels or surfboards, should be secured to capacity of the vehicle.
Page 102 GETTING TO KNOW YOUR INSTRUMENT PANEL CONTENTS INSTRUMENT CLUSTER ....102 ▫ Yellow Warning Lights ....123 ▫...
Page 103: Instrument Cluster
102 GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER Base Instrument Cluster...
Page 104 GETTING TO KNOW YOUR INSTRUMENT PANEL 103 Premium Instrument Cluster...
Page 105: Instrument Cluster Descriptions
104 GETTING TO KNOW YOUR INSTRUMENT PANEL Instrument Cluster Descriptions • The gauge pointer will likely indicate a higher tem- perature when driving in hot weather or up mountain 1. Tachometer grades. It should not be allowed to exceed the upper •...
Page 106: Instrument Cluster Display - If Equipped
GETTING TO KNOW YOUR INSTRUMENT PANEL 105 INSTRUMENT CLUSTER DISPLAY — IF EQUIPPED Instrument Cluster Display Location And Controls Your vehicle may be equipped with an instrument cluster The instrument cluster display features a driver-interactive display, which offers useful information to the driver. With display that is located in the instrument cluster.
Page 107 106 GETTING TO KNOW YOUR INSTRUMENT PANEL • Audio • Messages • Screen Setup • Vehicle Settings The systems allow the driver to select information by pushing the following buttons mounted on the steering wheel: Premium Instrument Cluster Display Location And Controls The instrument cluster display menu items consist of the following as equipped:...
Page 108: Oil Change Reset
GETTING TO KNOW YOUR INSTRUMENT PANEL 107 • Up Arrow Button • OK Button Push and release the up arrow button to scroll Push the OK button to access/select the information upward through the main menu and submenus. screens or submenu screens of a main menu item. Push and hold the OK button for one second to reset displayed/ selected features that can be reset.
Page 109: Instrument Cluster Display Menu Items
108 GETTING TO KNOW YOUR INSTRUMENT PANEL Instrument Cluster Display Menu Items Models Equipped With Keyless Enter-N-Go — Ignition NOTE: The instrument cluster display menu items display in the center of the instrument cluster. Menu items may vary depending on your vehicle features. Speedometer Push and release the up or down arrow button until the Speedometer Menu item is displayed in the instrument...
Page 110 GETTING TO KNOW YOUR INSTRUMENT PANEL 109 pressure values in each corner of the ICON with the Fuel Economy pressure value of the low tire displayed in a different Push and release the up or down arrow button until the color than the other tire pressure value.
Page 111 110 GETTING TO KNOW YOUR INSTRUMENT PANEL Driver Assist Adaptive Cruise Control Ready Push and release the up or down arrow button until the When ACC is activated but the vehicle speed setting has Driver Assist menu title is displayed is highlighted in the not been selected, the display will read “Adaptive Cruise instrument cluster display.
Page 112 GETTING TO KNOW YOUR INSTRUMENT PANEL 111 Refer to “Adaptive Cruise Control (ACC) — If Equipped” Audio in “Starting And Operating” for further information. Push and release the up or down arrow button until the Audio menu title is displayed in the instrument cluster Trip Info display.
Page 113 112 GETTING TO KNOW YOUR INSTRUMENT PANEL • Range Screen Setup Driver Selectable Items • Fuel Economy Average — Premium Cluster Upper Left • None • Fuel Economy Current — Premium Cluster • Compass (default setting) Restore Defaults (Restores All Settings To Default Set- tings) •...
Page 114 GETTING TO KNOW YOUR INSTRUMENT PANEL 113 • Fuel Economy Average NOTE: Most vehicle settings will be moved into the radio if a touchscreen radio is present, please refer to “Uconnect • Fuel Economy Current Settings” in “Multimedia” for further information. •...
Page 115 114 GETTING TO KNOW YOUR INSTRUMENT PANEL • Set Format: adjust the time format “12h” (12 hours) or • Rain Sensing Wipers (If Equipped): enabling/disabling “24h” (24 hours) the automatic operation of wipers in the event of rain • Set Date: adjust day/month/year •...
Page 116 GETTING TO KNOW YOUR INSTRUMENT PANEL 115 Lights • Auto Lock Doors: activate/deactivate the automatic locking of the doors with the vehicle moving By selecting Lights, the following adjustments can be • Auto Unlock Doors: automatic unlocking of the doors made: when exiting the vehicle •...
Page 117: Battery Saver On/Battery Saver Mode Message - Electrical Load Reduction Actions - If Equipped
116 GETTING TO KNOW YOUR INSTRUMENT PANEL Compass By selecting Compass, the following settings can be changed: Calibration (If Equipped) This compass is self-calibrating, which eliminates the need to set the compass manually. When the vehicle is new, the compass may appear erratic, and the cluster will display dashes (- -) until the compass is calibrated.
Page 118 GETTING TO KNOW YOUR INSTRUMENT PANEL 117 Load reduction is only active when the engine is running. The electrical loads that may be switched off (if equipped), It will display a message if there is a risk of battery and vehicle functions which can be effected by load depletion to the point where the vehicle may stall due to reduction: lack of electrical supply, or will not restart after the current...
Page 119: Trip Computer
118 GETTING TO KNOW YOUR INSTRUMENT PANEL • Installing options like additional lights, upfitter electri- – Check what may be plugged in to power outlets +12V, cal accessories, audio systems, alarms and similar de- 150W, USB ports vices. – Check HVAC settings (blower, temperature) –...
Page 120: Warning Lights And Messages
GETTING TO KNOW YOUR INSTRUMENT PANEL 119 WARNING LIGHTS AND MESSAGES Trip A • Shows the total distance traveled for Trip A since the last Red Warning Lights reset. — Air Bag Warning Light • Shows the elapsed time traveled for Trip A since the last This light indicates a fault with the airbag, and will turn on reset.
Page 121 120 GETTING TO KNOW YOUR INSTRUMENT PANEL System (ABS) / Electronic Stability Control (ESC) system. WARNING! In this case, the light will remain on until the condition has been corrected. If the problem is related to the brake Driving a vehicle with the red brake light on is booster, the ABS pump will run when applying the brake, dangerous.
Page 122 GETTING TO KNOW YOUR INSTRUMENT PANEL 121 — Battery Charge Warning Light — Electronic Throttle Control (ETC) Warning Light This light illuminates when the battery is not charging properly. If it stays on while the engine is running, there This light informs you of a problem with the Electronic may be a malfunction with the charging system.
Page 123 122 GETTING TO KNOW YOUR INSTRUMENT PANEL — Engine Coolant Temperature Warning Light NOTE: If the vehicle is moving, there will also be a single chime. This light warns of an overheated engine condition. If the engine coolant temperature is too high, this indicator will —...
Page 124: Yellow Warning Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL 123 flash or remain on continuously and a chime will sound. CAUTION! Refer to “Occupant Restraints Systems” in “Safety” for further information. Continuous driving with the Transmission Tempera- ture Warning Light illuminated will eventually cause —...
Page 125 124 GETTING TO KNOW YOUR INSTRUMENT PANEL If the ABS light does not turn on when the ignition is — Low Coolant Level Warning Light placed in the ON/RUN or ACC/ON/RUN position, have This telltale will turn on to indicate the vehicle coolant the brake system inspected by an authorized dealer.
Page 126 GETTING TO KNOW YOUR INSTRUMENT PANEL 125 The vehicle should be serviced if the light stays on through — Service 4WD Warning Light — If Equipped several typical driving styles. In most situations, the ve- If the light stays on or comes on during driving, it means hicle will drive normally and will not require towing.
Page 127 126 GETTING TO KNOW YOUR INSTRUMENT PANEL — Tire Pressure Monitoring System (TPMS) on the vehicle placard or tire inflation pressure label, you Warning Light should determine the proper tire inflation pressure for those tires.) The warning light switches on and a message is displayed to indicate that the tire pressure is lower than the recom- As an added safety feature, your vehicle has been mended value and/or that slow pressure loss is occurring.
Page 128: Yellow Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL 127 minute and then remain continuously illuminated. This CAUTION! (Continued) sequence will continue upon subsequent vehicle start-ups Monitoring System (TPMS) sensor to become inoper- as long as the malfunction exists. When the malfunction able. After using an aftermarket tire sealant it is indicator is illuminated, the system may not be able to recommended that you take your vehicle to your au- detect or signal low tire pressure as intended.
Page 129 128 GETTING TO KNOW YOUR INSTRUMENT PANEL If the ABS light remains on or turns on while driving, then — 4WD Lock Indicator Light the Anti-Lock portion of the brake system is not function- This light alerts the driver that the vehicle is in the ing and service is required.
Page 130: White Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL 129 White Indicator Lights • Each time the ignition is placed in the ON/RUN posi- tion, the ESC system will be ON, even if it was turned off — Cruise Control ON Indicator previously. This light will turn on when the speed control is on, but not •...
Page 131: Green Indicator Lights
130 GETTING TO KNOW YOUR INSTRUMENT PANEL — Speed Control SET Indicator Light — Park/Headlight On Indicator Light This light will turn on when the speed control is set. Refer This indicator will illuminate when the park lights or to “Speed Control — If Equipped” in “Starting And headlights are turned on.
Page 132: Blue Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL 131 ONBOARD DIAGNOSTIC SYSTEM — OBD II — Stop/Start Active Indicator Light — If Equipped Your vehicle is equipped with a sophisticated Onboard This telltale will illuminate when the Stop/Start function is Diagnostic system called OBD II. This system monitors the in “Autostop”...
Page 133: Onboard Diagnostic System (Obd Ii) Cybersecurity
132 GETTING TO KNOW YOUR INSTRUMENT PANEL CAUTION! (Continued) WARNING! (Continued) • If the MIL is flashing while the vehicle is running, vehicle control could occur that may result in an severe catalytic converter damage and power loss accident involving serious injury or death. will soon occur.
Page 134 GETTING TO KNOW YOUR INSTRUMENT PANEL 133 serviced, recently had a dead battery or a battery replace- • The MIL will not flash at all and will remain fully ment. If the OBD II system should be determined not ready illuminated until you place the ignition in the off posi- for the I/M test, your vehicle may fail the test.
Page 136 SAFETY CONTENTS SAFETY FEATURES ..... .136 ▫ Seat Belt Systems ..... .168 ▫...
Page 137: Safety Features
136 SAFETY SAFETY FEATURES These are all normal characteristics of ABS. Anti-Lock Brake System (ABS) WARNING! The Anti-Lock Brake System (ABS) provides increased • The ABS contains sophisticated electronic equip- vehicle stability and brake performance under most brak- ment that may be susceptible to interference caused ing conditions.
Page 138: Electronic Brake Control System
SAFETY Electronic Brake Control System WARNING! (Continued) Your vehicle is equipped with an advanced Electronic • The capabilities of an ABS equipped vehicle must Brake Control system (EBC). This system includes Elec- never be exploited in a reckless or dangerous manner tronic Brake Force Distribution (EBD), Anti-Lock Brake that could jeopardize the user’s safety or the safety of System (ABS), Brake Assist System (BAS), Hill Start Assist...
Page 139 138 SAFETY and controls the wheel spin across a driven axle. If one WARNING! wheel on a driven axle is spinning faster than the other, the system will apply the brake of the spinning wheel. This The Brake Assist System (BAS) cannot prevent the will allow more vehicle torque to be applied to the wheel natural laws of physics from acting on the vehicle, nor that is not spinning.
Page 140 SAFETY Dynamic Steering Torque (DST) Electronic Roll Mitigation (ERM) Dynamic Steering Torque is a feature of the ESC and This system anticipates the potential for wheel lift by Electric Power Steering (EPS) modules that provides monitoring the driver’s steering wheel input and the speed torque at the steering wheel for certain driving conditions of the vehicle.
Page 141 140 SAFETY Electronic Stability Control (ESC) Light” begins to flash during acceleration, ease up on the accelerator and apply as little throttle as possible. Be sure to This system enhances directional control and stability of adapt your speed and driving to the prevailing road the vehicle under various driving conditions.
Page 142 SAFETY WARNING! (Continued) the performance of the ESC system. Changes to the steering system, suspension, braking system, tire type and size or wheel size may adversely affect ESC performance. Improperly inflated and unevenly worn tires may also degrade ESC performance. Any vehicle modification or poor vehicle maintenance that reduces the effectiveness of the ESC system can increase the risk of loss of vehicle control, vehicle...
Page 143 142 SAFETY allows for more wheel spin than normally allowed. This WARNING! (Continued) mode may be useful if the vehicle becomes stuck. feature of TCS is disabled, and the enhanced vehicle To enter the “Partial Off” mode, momentarily push the stability offered by the ESC system is reduced.
Page 144 SAFETY returns to provide the stability feature at speeds above ESC Activation/Malfunction Indicator Light And 40 mph (64 km/h). The ESC OFF Indicator Light will ESC OFF Indicator Light always be illuminated when ESC is off. The “ESC Activation/Malfunction Indicator To turn ESC on again, momentarily push the “ESC Off”...
Page 145 144 SAFETY NOTE: Hill Descent Control (HDC) — If Equipped • The “ESC Activation/Malfunction Indicator Light” and the “ESC OFF Indicator Light” come on momentarily each time the ignition is turned ON. • Each time the ignition is turned ON, the ESC system will be on even if it was turned off previously.
Page 146 SAFETY HDC has three states: Driver Override: 1. Off (feature is not enabled and will not activate). The driver may override HDC activation speed with throttle or brake application at anytime. 2. Enabled (feature is enabled and ready but activation conditions are not met, or driver is actively overriding Deactivating HDC with brake or throttle application).
Page 147 146 SAFETY • The vehicle is driven greater than 25 mph (40 km/h) Hill Start Assist (HSA) (HDC exits immediately.) The HSA system is designed to mitigate roll back from a complete stop while on an incline. If the driver releases the Feedback To The Driver: brake while stopped on an incline, HSA will continue to The instrument cluster has an HDC icon and the HDC...
Page 148 SAFETY • HSA will work in REVERSE gear and all forward gears. WARNING! The system will not activate if the transmission is in PARK or NEUTRAL. For vehicles equipped with a • If you use a trailer brake controller with your trailer, manual transmission, if the clutch is pressed, HSA will the trailer brakes may be activated and deactivated remain active.
Page 149: Auxiliary Driving Systems
148 SAFETY Rain Brake Support (RBS) When TSC is functioning, the “ESC Activation/ Malfunction Indicator Light” will flash, the engine power Rain Brake Support may improve braking performance in may be reduced and you may feel the brakes being applied wet conditions.
Page 150 SAFETY sides of the vehicle when the vehicle speed reaches ap- proximately 6 mph (10 km/h) or higher and will alert the driver of vehicles in these areas. NOTE: • The BSM system does NOT alert the driver about rapidly approaching vehicles that are outside the detec- tion zones.
Page 151 150 SAFETY The area on the rear fascia where the radar sensors are present on that side of the vehicle, an audible chime will located must remain free of snow, ice, and dirt/road also be sounded. Whenever a turn signal and detected contamination so that the BSM system can function prop- object are present on the same side at the same time, both erly.
Page 152 SAFETY Entering From The Side Entering From The Rear Vehicles that move into your adjacent lanes from either Vehicles that come up from behind your vehicle on either side of the vehicle. side and enter the rear detection zone with a relative speed of less than 30 mph (48 km/h).
Page 153 152 SAFETY Overtaking Traffic If you pass another vehicle slowly with a relative speed less than 10 mph (16 km/h) and the vehicle remains in the blind spot for approximately 1.5 seconds, the warning light will be illuminated. If the difference in speed between the two vehicles is greater than 10 mph (16 km/h), the warning light will not illuminate.
Page 154 SAFETY Stationary Objects Opposing Traffic The BSM system will not alert you of objects that are WARNING! traveling in the opposite direction of the vehicle in adjacent lanes. The Blind Spot Monitoring system is only an aid to help detect objects in the blind spot zones. The BSM NOTE: The BSM system may experience drop outs (blink- system is not designed to detect pedestrians, bicyclists, ing on and off) in the side mirror LED icons while a...
Page 155 154 SAFETY Rear Cross Path (RCP) (5 km/h), to objects moving a maximum of approximately 20 mph (32 km/h), such as in parking lot situations. The Rear Cross Path (RCP) feature is intended to aid the driver when backing out of parking spaces where their NOTE: In a parking lot situation, oncoming vehicles can be vision of oncoming vehicles may be blocked.
Page 156 SAFETY Modes Of Operation NOTE: Whenever an audible alert is requested by the BSM system, the radio is also muted. Three selectable modes of operation are available in the Uconnect System. Refer to “Uconnect Settings” in “Multi- When the system is in RCP, the system shall respond with media”...
Page 157: Forward Collision Warning (Fcw) With Mitigation - If Equipped
156 SAFETY Forward Collision Warning (FCW) With Mitigation blockage. After removing the blockage, reset the system by — If Equipped cycling the ignition from ON to OFF and then back ON. General Information Forward Collision Warning (FCW) With Mitigation Operation The following regulatory statement applies to all Radio Frequency (RF) devices equipped in this vehicle: The Forward Collision Warning (FCW) system with mitigation...
Page 158 SAFETY If a Forward Collision Warning with Mitigation event NOTE: begins at a speed below 26 mph (42 km/h), the system may • The minimum speed for FCW activation is 1 mph provide the maximum braking possible to mitigate the (2 km/h).
Page 159 158 SAFETY FCW Settings Changing FCW Sensitivity and Operating Status The forward collision menu setting is located in the The FCW Sensitivity And Operation Settings are program- Uconnect settings. mable through the Uconnect System. Refer to “Uconnect Settings” in “Multimedia” for further information. NOTE: The default status of FCW is “Full On,”...
Page 160: Tire Pressure Monitor System (Tpms)
SAFETY NOTE: Service FCW Warning • The system will not retain the last setting selected by the If the system turns off, and the instrument cluster display driver after the ignition is turned OFF. The system will reads: reset to the default setting when the vehicle is restarted. •...
Page 161 160 SAFETY vehicle’s tires. The tire pressure will also increase as the may need to be driven for up to 20 minutes above 15 mph vehicle is driven. This is normal and there should be no (24 km/h) in order for the TPMS to receive this informa- adjustment for this increased pressure.
Page 162 SAFETY NOTE: CAUTION! • The TPMS is not intended to replace normal tire care and • The TPMS has been optimized for the original maintenance, or to provide warning of a tire failure or equipment tires and wheels. TPMS pressures and condition.
Page 163 162 SAFETY monitor tire pressure levels. Sensors, mounted to each the system receives the updated tire pressures, the system wheel as part of the valve stem, transmit tire pressure will automatically update and the “Tire Pressure Monitor- readings to the receiver module. ing Telltale Light”...
Page 164 SAFETY • Installing some form of aftermarket window tinting that 4. For each subsequent ignition cycle, a chime will sound affects radio wave signals. and the “TPMS Telltale Light” will flash on and off for 75 seconds and then remain on solid. •...
Page 165 164 SAFETY The TPMS consists of the following components: • Receiver Module • Four Tire Pressure Monitoring Sensors • Various Tire Pressure Monitoring System messages, which will display in the instrument cluster display. • Tire Pressure Monitoring Telltale Light Tire Pressure Monitoring Low Pressure Warnings The “Tire Pressure Monitoring Telltale Light”...
Page 166 SAFETY NOTE: When filling warm tires, the tire pressure may need • Jamming due to electronic devices or driving next to to be increased up to an additional 4 psi (30 kPa) above the facilities emitting the same radio frequencies as the recommended cold placard pressure in order to turn the TPMS sensors.
Page 167 166 SAFETY 3. After driving the vehicle for up to 20 minutes above TPMS Deactivation — If Equipped 15 mph (24 km/h), the “TPMS Telltale Light” will flash The TPMS can be deactivated if replacing all four wheel on and off for 75 seconds and then remain on solid. In and tire assemblies (road tires) with wheel and tire assem- addition, the instrument cluster will display a “SER- blies that do not have TPMS Sensors, such as when...
Page 168: Occupant Restraint Systems
SAFETY Occupant Restraint Systems Features Light will flash on and off for 75 seconds and then turn off. The instrument cluster will display the “SERVICE TPM • Seat Belt Systems SYSTEM” message and then display pressure values in • Supplemental Restraint Systems (SRS) Air Bags place of the dashes.
Page 169: Seat Belt Systems
168 SAFETY 3. Children that are not big enough to wear the vehicle seat 9. If the air bag system in this vehicle needs to be modified belt properly (refer to “Child Restraints” in this section to accommodate a disabled person, refer to the “Cus- for further information) should be secured in a vehicle tomer Assistance”...
Page 170 SAFETY risk of injury caused by striking the inside of the vehicle. BeltAlert Warning Sequence Everyone in a motor vehicle should be belted at all times. The BeltAlert warning sequence is activated when the Enhanced Seat Belt Use Reminder System (BeltAlert) vehicle is moving above a specified vehicle speed range and the driver or outboard front seat passenger is unbuck- Driver and Passenger BeltAlert (if equipped)
Page 171 170 SAFETY The outboard front passenger seat BeltAlert is not active and reduce your risk of striking the inside of the vehicle or when the outboard front passenger seat is unoccupied. being thrown out of the vehicle. BeltAlert may be triggered when an animal or other items WARNING! are placed on the outboard front passenger seat or when the seat is folded flat (if equipped).
Page 172 SAFETY WARNING! (Continued) WARNING! (Continued) driver, should always wear their seat belts whether • A twisted seat belt may not protect you properly. In or not an air bag is also provided at their seating a collision, it could even cut into you. Be sure the seat position to minimize the risk of severe injury or belt is flat against your body, without twists.
Page 173 172 SAFETY 2. The seat belt latch plate is above the back of the front WARNING! (Continued) seat, and next to your arm in the rear seat (for vehicles • A shoulder belt placed behind you will not protect equipped with a rear seat). Grasp the latch plate and you from injury during a collision.
Page 174 SAFETY 3. When the seat belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Positioning The Lap Belt 5. Position the shoulder belt across the shoulder and chest with minimal, if any slack so that it is comfortable and Inserting Latch Plate Into Buckle not resting on your neck.
Page 175 174 SAFETY Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/ shoulder belt. 1. Position the latch plate as close as possible to the anchor point. 2. At about 6 to 12 inches (15 to 30 cm) above the latch plate, grasp and twist the seat belt webbing 180 degrees to create a fold that begins immediately above the latch plate.
Page 176 SAFETY NOTE: The adjustable upper shoulder belt anchorage is Second Row Center Seat Belt Operating Instructions equipped with an Easy Up feature. This feature allows the The second row center seat belt may feature a seat belt with shoulder belt anchorage to be adjusted in the upward a mini-latch plate and buckle.
Page 177 176 SAFETY 2. When the seat belt is long enough to fit, insert the 3. Sit back in seat. Slide the regular latch plate up the mini-latch plate into the mini-buckle until you hear a webbing as far as necessary to allow the seat belt to go “click.”...
Page 178 SAFETY 8. To disengage the mini-latch plate from the mini-buckle, insert the regular latch plate into the center red slot on the mini-buckle. Inserting Latch Plate Into Buckle 5. Position the lap belt so that it is snug and lies low across your hips, below your abdomen.
Page 179 178 SAFETY WARNING! (Continued) WARNING! • When reattaching the mini-latch plate and mini- • ONLY use a Seat Belt Extender if it is physically buckle, ensure the seat belt webbing is not twisted. required in order to properly fit the original seat belt If the webbing is twisted, follow the preceding system.
Page 180 SAFETY Seat Belts And Pregnant Women Seat Belt Pretensioner The front seat belt system is equipped with pretensioning devices that are designed to remove slack from the seat belt in the event of a collision. These devices may improve the performance of the seat belt by removing slack from the seat belt early in a collision.
Page 181 180 SAFETY Switchable Automatic Locking Retractors (ALR) ALR is activated, you will hear a clicking sound as the seat belt retracts. Allow the webbing to retract completely in The seat belts in the passenger seating positions are this case and then carefully pull out only the amount of equipped with a Switchable Automatic Locking Retractor webbing necessary to comfortably wrap around the occu- (ALR) which is used to secure a child restraint system.
Page 182: Supplemental Restraint Systems (Srs)
SAFETY How To Engage The Automatic Locking Mode WARNING! (Continued) 1. Buckle the combination lap and shoulder belt. • Do not use the Automatic Locking Mode to restrain occupants who are wearing the seat belt or children 2. Grasp the shoulder portion and pull downward until who are using booster seats.
Page 183 182 SAFETY • Steering Wheel and Column The ORC contains a backup power supply system that may deploy the air bag system even if the battery loses power or • Instrument Panel it becomes disconnected prior to deployment. • Knee Impact Bolsters The ORC turns on the Air Bag Warning Light in the •...
Page 184: Glove Compartment
SAFETY • The Air Bag Warning Light comes on intermittently or Redundant Air Bag Warning Light remains on while driving. If a fault with the Air Bag Warning Light is NOTE: If the speedometer, tachometer, or any engine detected, which could affect the Supplemental related gauges are not working, the Occupant Restraint Restraint System (SRS), the Redundant Air Bag Controller (ORC) may also be disabled.
Page 185 184 SAFETY WARNING! (Continued) • Never place a rear-facing child restraint in front of an air bag. A deploying passenger front air bag can cause death or serious injury to a child 12 years or younger, including a child in a rear-facing child restraint.
Page 186 SAFETY driver or front passenger seat belt is buckled. The seat belt WARNING! (Continued) buckle switch may adjust the inflation rate of the Ad- bags may no longer be functional. The protective vanced Front Air Bags. covers for the air bag cushions are designed to open This vehicle may be equipped with driver and/or front only when the air bags are inflating.
Page 187 186 SAFETY Because air bag sensors measure vehicle deceleration over The Occupant Classification System (OCS) consists of the time, vehicle speed and damage by themselves are not following: good indicators of whether or not an air bag should have • Occupant Restraint Controller (ORC) deployed.
Page 188 SAFETY The OCS will NOT prevent deployment of the Passenger Front Passenger Seat Front Passenger Air Bag Advanced Front Air Bag. The OCS may reduce the inflation Occupant Status Output rate of the Passenger Advanced Front Air Bag if the OCS Rear-facing child restraint Reduced-power estimates that:...
Page 189 188 SAFETY • Sitting in the center of the seat with their feet comfort- WARNING! ably on or near the floor • Never place a rear-facing child restraint in front of an • Sitting with their back against the seatback and the air bag.
Page 190 SAFETY Do not decrease OR increase the front passenger’s seated Examples of improper front passenger seating include: weight on the front passenger seat • The front passenger’s weight is transferred to another part of the vehicle (like the door, arm rest or instrument The front passenger’s seated weight must be properly panel).
Page 191 190 SAFETY The OCS determines the front passenger’s most probable classification. If an occupant in the front passenger seat is seated improperly, the occupant may provide an output signal to the OCS that is different from the occupant’s properly seated weight input, for example: Not Seated Properly Not Seated Properly...
Page 192 SAFETY Not Seated Properly Not Seated Properly WARNING! • If a child restraint system, child, small teenager or adult in the front passenger seat is seated improp- erly, the occupant may provide an output signal to the OCS that is different from the occupant’s prop- erly seated weight input.
Page 193 192 SAFETY The passenger seat assembly contains critical OCS compo- WARNING! (Continued) nents that may affect the Passenger Advanced Front Air the seatback, sitting upright, facing forward, in the Bag inflation. In order for the OCS to properly classify the center of the seat, with your feet comfortably on or seated weight of a front seat passenger, the OCS compo- near the floor.
Page 194 SAFETY be modified or replaced with any part except those WARNING! which are approved by FCA US LLC. • Do not drill, cut, or tamper with the knee impact WARNING! bolsters in any way. • Do not mount any accessories to the knee impact •...
Page 195 194 SAFETY The SABs may help to reduce the risk of occupant injury area where the SAB inflates. Children are at an even greater during certain side impacts, in addition to the injury risk of injury from a deploying air bag. reduction potential provided by the seat belts and body WARNING! structure.
Page 196 SAFETY positioned in the area where the SABICs inflate. Children are at an even greater risk of injury from a deploying air bag. The SABICs may help reduce the risk of partial or complete ejection of vehicle occupants through side windows in certain side impact events.
Page 197 196 SAFETY Side Impacts Side Air Bags are a supplement to the seat belt restraint system. Side Air Bags deploy in less time than it takes to The Side Air Bags are designed to activate in certain side blink your eyes. impacts.
Page 198 SAFETY The Side Air Bags will not deploy in all rollover events. The WARNING! rollover sensing system determines if a rollover event may be in progress and whether deployment is appropriate. In • Side Air Bags need room to inflate. Do not lean the event the vehicle experiences a rollover or near rollover against the door or window.
Page 199 198 SAFETY • Supplemental Side Air Bags quickly. However, if you haven’t healed significantly within a few days, or if you have any blistering, see your • Supplemental Knee Air Bags doctor immediately. • Front and Side Impact Sensors • As the air bags deflate, you may see some smoke-like •...
Page 200 SAFETY • Unlock the power door locks. NOTE: • Air bag covers may not be obvious in the interior trim, • Turn off the Fuel Pump Heater — If Equipped. but they will open during air bag deployment. • Turn off the HVAC Blower Motor. •...
Page 201 200 SAFETY Customer Action Customer Will See Customer Action Customer Will See NOTE: Each step MUST BE held for at least two sec- NOTE: Each step MUST BE held for at least two sec- onds onds 1. Turn ignition STOP/ 8.
Page 202 SAFETY If a reset procedure step is not completed within 60 WARNING! (Continued) seconds, then the turn signal lights will blink and the reset bag system service. If your seat, including your trim procedure must be performed again in order to be success- cover and cushion, needs to be serviced in any way ful.
Page 203: Child Restraints
202 SAFETY • How far (if at all) the driver was depressing the accel- small children ride in proper restraint systems. This is the erator and/or brake pedal; and, law, and you can be prosecuted for ignoring it. • How fast the vehicle was traveling. Children 12 years or younger should ride properly buckled up in a rear seat, if available.
Page 204 SAFETY Before buying any restraint system, make sure that it has a NOTE: label certifying that it meets all applicable Safety Stan- • For additional information, refer to www.safercar.gov/ dards. You should also make sure that you can install it in parents/index.htm or call: 1–888–327–4236 the vehicle where you will use it.
Page 205 204 SAFETY Recommended Type Of Child Re- Child Size, Height, Weight Or Age straint Children Too Large for Child Re- Children 12 years old or younger, Vehicle Seat Belt, seated in the rear straints who have outgrown the height or seat of the vehicle weight limit of their booster seat Infant And Child Restraints...
Page 206 SAFETY in a forward-facing child seat with a harness for as long as WARNING! (Continued) possible, up to the highest weight or height allowed by the • When your child restraint is not in use, secure it in child seat. the vehicle with the seat belt or LATCH anchorages, All children whose weight or height is above the forward- or remove it from the vehicle.
Page 207 206 SAFETY 4. Is the lap part of the belt as low as possible, touching the WARNING! child’s thighs and not the stomach? Never allow a child to put the shoulder belt under an 5. Can the child stay seated like this for the whole trip? arm or behind their back.
Page 208 SAFETY Recommendations For Attaching Child Restraints Restraint Type Combined Use Any Attachment Method Shown With An “X” Below Weight of the LATCH – Lower Seat Belt Only LATCH – Lower Seat Belt + Top Child + Child Anchors Only Anchors + Top Tether Anchor Restraint Tether Anchor...
Page 209 208 SAFETY Lower Anchors And Tethers For CHildren (LATCH) used with the top tether anchorage to install the child Restraint System restraint. Please see the following table for more information. LATCH Positions For Installing Child Restraints In This Vehicle LATCH Label Your vehicle is equipped with the child restraint anchorage system called LATCH, which stands for Lower Anchors and Tethers for CHildren.
Page 210 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH What is the weight limit 65 lbs Use the LATCH anchorage system until the combined weight of the (child’s weight + weight of (29.5 kg) child and the child restraint is 65 lbs (29.5 kg). Use the seat belt and the child restraint) for us- tether anchor instead of the LATCH system once the combined weight ing the LATCH anchorage...
Page 211 210 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Can the head restraints be The head restraints may be removed in every rear seating position. removed? Locating The LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback, below the anchorage sym- bols on the seatback.
Page 212 SAFETY Locating The Upper Tether Anchorages strap. The tether strap will have a hook at the end to attach to the top tether anchorage and a way to tighten the strap after it is attached to the anchorage. There are tether strap anchorages behind each rear seating position located on the back of the Center Seat LATCH seat.
Page 213 212 SAFETY To Install A LATCH-Compatible Child Restraint 4. If the child restraint has a tether strap, connect it to the top tether anchorage. See the section “Installing Child If the selected seating position has a Switchable Automatic Restraints Using the Top Tether Anchorage” for direc- Locking Retractor (ALR) seat belt, stow the seat belt, tions to attach a tether anchor.
Page 214 SAFETY path and then buckle it. Do not lock the seat belt. Remind Installing Child Restraints Using The Vehicle Seat all children in the vehicle that the seat belts are not toys and Belt that they should not play with them. Child restraint systems are designed to be secured in vehicle seats by lap belts or the lap belt portion of a WARNING!
Page 215 214 SAFETY The seat belts in the passenger seating positions are Lap/Shoulder Belt Systems For Installing Child equipped with a Switchable Automatic Locking Retractor Restraints In This Vehicle (ALR) that is designed to keep the lap portion of the seat belt tight around the child restraint so that it is not necessary to use a locking clip.
Page 216 SAFETY Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s Weight limit of the Child Restraint Always use the tether anchor when weight + weight of the child re- using the seat belt to install a for- straint) for using the Tether Anchor ward facing child restraint, up to the with the seat belt to attach a forward...
Page 217 216 SAFETY 1. Place the child seat in the center of the seating position. 6. Try to pull the webbing out of the retractor. If it is For some second row seats, you may need to recline the locked, you should not be able to pull out any webbing. seat and/or raise the head restraint to get a better fit.
Page 218 SAFETY Installing Child Restraints Using The Top Tether 1. Look behind the seating position where you plan to Anchorage: install the child restraint to find the tether anchorage. You may need to move the seat forward to provide WARNING! better access to the tether anchorage. If there is no top tether anchorage for that seating position, move the Do not attach a tether strap for a rear-facing car seat to child restraint to another position in the vehicle if one is...
Page 219: Transporting Pets
218 SAFETY Transporting Pets Air Bags deploying in the front seat could harm your pet. An unrestrained pet will be thrown about and possibly injured, or injure a passenger during panic braking or in a collision. Pets should be restrained in the rear seat in pet harnesses or pet carriers that are secured by seat belts.
Page 220: Exhaust Gas
SAFETY WARNING! (Continued) WARNING! (Continued) • Do not allow people to ride in any area of your • If it is necessary to sit in a parked vehicle with the vehicle that is not equipped with seats and seat belts. engine running, adjust your heating or cooling con- •...
Page 221: Safety Checks You Should Make Inside The Vehicle
220 SAFETY Safety Checks You Should Make Inside The Vehicle fault is cleared. If the light comes on intermittently or remains on while driving, have your authorized dealer Seat Belts service the vehicle immediately. Refer to “Occupant Inspect the seat belt system periodically, checking for cuts, Restraint Systems”...
Page 222 SAFETY WARNING! WARNING! (Continued) vehicle properly parked with the engine off, fully An improperly attached, damaged, folded, or stacked depress the accelerator, the brake, and the clutch floor mat, or damaged floor mat fasteners may cause pedal (if present) to check for interference. If your your floor mat to interfere with the accelerator, brake, floor mat interferes with the operation of any pedal, or clutch pedals and cause a loss of vehicle control.
Page 223: Periodic Safety Checks You Should Make Outside
222 SAFETY Lights WARNING! (Continued) Have someone observe the operation of brake lights and interference with the accelerator, brake, or clutch exterior lights while you work the controls. Check turn pedals then re-install the floor mats. signal and high beam indicator lights on the instrument •...
Page 224 ENGINE BLOCK HEATER — IF EQUIPPED ..230 ▫ Jeep Active Drive ..... . .250 ENGINE BREAK-IN RECOMMENDATIONS ..231 SELEC-TERRAIN —...
Page 225 224 STARTING AND OPERATING ▫ Possible Reasons The Engine Does Not ▫ Enabling And Disabling ParkSense ..266 Autostop ......255 ▫...
Page 226 STARTING AND OPERATING 225 ▫ Trailer And Tongue Weight ....284 ▫ Recreational Towing — Front-Wheel Drive (FWD) Models ......289 ▫...
Page 227: Starting The Engine
226 STARTING AND OPERATING STARTING THE ENGINE Start the engine with the gear selector in the NEUTRAL or PARK position. Apply the brake before shifting to any Before starting your vehicle, adjust your seat, adjust both driving range. inside and outside mirrors, and fasten your seat belts. Normal Starting WARNING! NOTE: Normal starting of either a cold or a warm engine...
Page 228 STARTING AND OPERATING 227 Automatic Transmission 4. If you wish to stop the cranking of the engine prior to the engine starting, push the button again. The gear selector must be in the NEUTRAL or PARK position before you can start the engine. Apply the brakes NOTE: Normal starting of either a cold or a warm engine before shifting into any driving gear.
Page 229: Cold Weather Operation (Below -22°F Or −30°C)
228 STARTING AND OPERATING Keyless Enter-N-Go Functions — Using The ENGINE 1. Push the ENGINE START/STOP button once to change START/STOP Button the ignition switch to the RUN position, 1. The transmission must be in NEUTRAL. 2. Push the ENGINE START/STOP button a second time to change the ignition switch to the OFF position, 2.
Page 230: After Starting - Warming Up The Engine
STARTING AND OPERATING 229 4. If the engine fails to start after eight attempts, allow the CAUTION! starter to cool for at least 10 minutes, then repeat the procedure. To prevent damage to the starter, do not continuously crank the engine for more than 25 seconds at a time. CAUTION! Wait 60 seconds before trying again.
Page 231: Stopping The Engine
230 STARTING AND OPERATING Stopping The Engine ENGINE BLOCK HEATER — IF EQUIPPED Vehicles Equipped With Electronic Key (Keyless Enter- The engine block heater warms the engine and permits N-Go): quicker starts in cold weather. To shut off the engine with vehicle speed greater than Connect the cord to a 110-115 Volt AC electrical outlet with 5 mph (8 km/h), you must push and hold the ignition or a grounded, three-wire extension cord.
Page 232: Engine Break-In Recommendations
STARTING AND OPERATING 231 NOTE: While cruising, brief full-throttle acceleration within the limits of local traffic laws contributes to a good break-in. • The engine block heater cord is a factory installed Wide-open throttle acceleration in low gear can be detri- option.
Page 233: Park Brake
232 STARTING AND OPERATING PARK BRAKE Electric Park Brake (EPB) Your vehicle is equipped with an Electric Park Brake System (EPB) that offers simple operation, and some additional features that make the parking brake more convenient and useful. The parking brake is primarily intended to prevent the vehicle from rolling while parked.
Page 234 STARTING AND OPERATING 233 NOTE: The EPB fault lamp will illuminate if the EPB NOTE: When parking on a hill, it is important to turn the switch is held for longer than 60 seconds in either the front wheels toward the curb on a downhill grade and released or applied position.
Page 235 234 STARTING AND OPERATING WARNING! (Continued) CAUTION! (Continued) fatally injured. Children should be warned not to indicated. Have the brake system serviced by an au- touch the parking brake, brake pedal or the gear thorized dealer immediately. selector. If exceptional circumstances should make it necessary to •...
Page 236 STARTING AND OPERATING 235 In the unlikely event of a malfunction of the Electric Park For automatic transmissions, the EPB will automatically Brake system, a yellow EPB fault lamp will illuminate. This engage if all of the following conditions are met: may be accompanied by the BRAKE warning lamp flash- •...
Page 237 236 STARTING AND OPERATING • The parking brake must be disabled. pressed. Once manually bypassed, SafeHold will be en- abled again once the vehicle reaches 12 mph (20 km/h) or • The transmission must be in park or neutral. the ignition is turned to the OFF position and back to •...
Page 238: Manual Transmission - If Equipped
STARTING AND OPERATING 237 NOTE: During cold weather, you may experience in- WARNING! creased effort in shifting until the transmission fluid warms up. This is normal. You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment.
Page 239: Shifting
238 STARTING AND OPERATING Shifting To engage REVERSE gear from the NEUTRAL position, lift the REVERSE ring, located below the knob and move the Fully press the clutch pedal before shifting gears. As you gear selector all the way left and then forward. release the clutch pedal, lightly press the accelerator pedal.
Page 240: Downshifting
STARTING AND OPERATING 239 NOTE: A certain amount of noise from the transmission is CAUTION! normal. This noise can be most noticeable when the vehicle is idling in NEUTRAL with the clutch engaged (clutch • Skipping gears and downshifting into lower gears at pedal released), but it may also be heard when driving.
Page 241: Parking
240 STARTING AND OPERATING Maximum Recommended Downshift Speeds CAUTION! Failure to follow the maximum recommended down- shifting speeds may cause the engine to overspeed and/or damage the clutch disc, even if the clutch pedal is pressed. Manual Transmission Shift Speeds in MPH (KM/H) Gear Selection 6 to 5 5 to 4...
Page 242: Automatic Transmission - If Equipped
STARTING AND OPERATING 241 NOTE: NEVER leave the car with the gearbox in neutral WARNING! (Continued) (or, if equipped with automatic transmission, before plac- foot is not firmly pressing the brake pedal, the ing the gear lever in PARK). vehicle could accelerate quickly forward or in re- verse.
Page 243: Ignition Park Interlock
242 STARTING AND OPERATING Ignition Park Interlock WARNING! (Continued) This vehicle is equipped with an Ignition Park Interlock be in a vehicle unattended is dangerous for a number which requires the transmission to be in PARK before the of reasons. A child or others could be seriously or ignition can be turned to the OFF mode.
Page 244: Six-Speed Or Nine-Speed Automatic Transmission
STARTING AND OPERATING 243 Six-Speed Or Nine-Speed Automatic Transmission and road conditions. The transmission electronics are self- calibrating; therefore, the first few shifts on a new vehicle NOTE: Your vehicle may be equipped with a six-speed or may be somewhat abrupt. This is a normal condition, and nine-speed automatic transmission, depending on model.
Page 245 244 STARTING AND OPERATING in the AutoStick position will manually select the transmis- Gear Ranges sion gear. Refer to AutoStick in this section for further Do not depress the accelerator pedal when shifting from information. PARK or NEUTRAL into another gear range. NOTE: If the gear selector cannot be moved to the PARK, NOTE: After selecting any gear range, wait a moment to REVERSE, or NEUTRAL position (when pushed forward)
Page 246 STARTING AND OPERATING 245 When exiting the vehicle, always: WARNING! (Continued) 1. Apply the parking brake. vehicle could accelerate quickly forward or in re- verse. You could lose control of the vehicle and hit 2. Shift the transmission into PARK. someone or something.
Page 247 246 STARTING AND OPERATING • When shifting into PARK, push the lock button on the WARNING! (Continued) gear selector, and firmly move the selector all the way of reasons. A child or others could be seriously or forward until it stops and is fully seated. fatally injured.
Page 248 STARTING AND OPERATING 247 select a lower gear (refer to AutoStick in this section for WARNING! (Continued) further information). Under these conditions, using a lower conditions. You might lose control of the vehicle and gear will improve performance and extend transmission have a collision.
Page 249 248 STARTING AND OPERATING • Six-speed transmissions will automatically upshift when AutoStick necessary to prevent engine over-speed. AutoStick is a driver-interactive transmission feature pro- • The transmission will automatically downshift as the viding manual shift control, giving you more control of the vehicle.
Page 250 STARTING AND OPERATING 249 NOTE: When Selec-Speed or Hill Descent Control is en- In the event of a momentary problem, the transmission can abled, AutoStick is not active. be reset to regain all forward gears by performing the following steps: To disengage AutoStick, return the gear selector to the DRIVE position.
Page 251: Four-Wheel Drive Operation - If Equipped
NOTE: It is not possible to carry out the change of mode when the vehicle exceeds the speed of 75 mph (120 km/h). Jeep Active Drive Enabling Four Wheel Drive (4x4) Your vehicle may be equipped with a Power Transfer Unit (PTU).
Page 252 STARTING AND OPERATING 251 Active Drive Control — If Equipped Active Drive With Low Control — (Trailhawk models only) Selec-Terrain Switch Selec-Terrain Switch (Trailhawk) The Power Transfer Unit (PTU) is locked to ensure imme- diate availability of torque to the rear drive axles. This The 4WD LOW mode helps to improve the off-road feature is selectable in AUTO mode and automatic in the performance in all modes.
Page 253: Selec-Terrain - If Equipped
252 STARTING AND OPERATING Mode Selection Guide NOTE: • Both LOCK and LOW LEDs will blink and then become Rotate the Selec-Terrain knob to select the desired mode. active on the Selec-Terrain switch until the shift is complete. • The instrument cluster display will illuminate the 4WD LOW icon.
Page 254 STARTING AND OPERATING 253 operating conditions), the transmission may use second gear (rather than first gear) during launches, to mini- mize wheel slippage. • SAND: For off-road driving or use on surfaces with poor traction, such as dry sand. The transmission is set to provide maximum traction.
Page 255: Power Steering
254 STARTING AND OPERATING POWER STEERING If the “POWER STEERING SYSTEM HOT - PERFOR- MANCE MAY BE LIMITED” message and an icon are The electric power steering system will give you good displayed on the instrument cluster display, it indicates vehicle response and increased ease of maneuverability in that extreme steering maneuvers may have occurred, tight spaces.
Page 256: Stop/Start System - If Equipped
STARTING AND OPERATING 255 STOP/START SYSTEM — IF EQUIPPED The engine will shut down, the tachometer will move to the zero position and the Stop/Start telltale will illuminate The Stop/Start function is developed to reduce fuel con- indicating you are in Autostop. Customer settings will be sumption.
Page 257: To Start The Engine While In Autostop Mode
256 STARTING AND OPERATING • The transmission is not in a forward gear. Conditions That Will Cause The Engine To Start Auto- matically While In Autostop Mode: • Hood is open. • The transmission selector is moved out of DRIVE. •...
Page 258: To Manually Turn Off The Stop/Start System
STARTING AND OPERATING 257 To Manually Turn Off The Stop/Start System 4. The STOP/START system will reset itself back to an ON condition every time the ignition is turned off and back 1. Push the STOP/START Off switch (located on the switch bank).
Page 259: To Activate
258 STARTING AND OPERATING WARNING! Speed Control can be dangerous where the system cannot maintain a constant speed. Your vehicle could go too fast for the conditions, and you could lose control and have an accident. Do not use Speed Control in heavy traffic or on roads that are winding, icy, snow-covered or slippery.
Page 260: To Set A Desired Speed
STARTING AND OPERATING 259 To Set A Desired Speed • If the button is continually pushed, the set speed will continue to increase until the button is released, then the Turn the Speed Control on. new set speed will be established. NOTE: The vehicle should be traveling at a steady speed Metric Speed (km/h) and on level ground before pushing the SET (+) or SET (-)
Page 261: To Accelerate For Passing
260 STARTING AND OPERATING • If the button is continually pushed, the set speed will To Deactivate continue to decrease until the button is released, then the A soft tap on the brake pedal, pushing the CANC (cancel) new set speed will be established. button, or normal brake pressure while slowing the vehicle will deactivate the speed control without erasing the set Metric Speed (km/h)
Page 262: Parksense Sensors
STARTING AND OPERATING 261 within the instrument cluster display indicating the vehicle The ParkSense Warning screen is located within the instru- speed is too fast. The system will become active again ment cluster display. It provides visual warnings to indi- when the vehicle speed is decreased to speeds less than cate the distance between the rear fascia/bumper and the approximately 6 mph (9 km/h).
Page 263 262 STARTING AND OPERATING If an obstacle is detected in the left and /or right rear region, the display will show a single flashing arc in the left and/or right rear region As the vehicle moves closer to the obstacle, the display will show the single arc moving closer to the vehicle and the audible chime increases as the objects gets close to the vehicle.
Page 264 STARTING AND OPERATING 263 Slow Tone/Solid Arc Fast Tone/Flashing Arc...
Page 265 264 STARTING AND OPERATING The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert opera- tion when the system is detecting an obstacle: Continuous Tone/Flashing Arc...
Page 266 STARTING AND OPERATING 265 WARNING ALERTS Rear Dis- Greater 79-59 inches 59-47 inches 47-39 inches 39-25 inches 25-12 inches Less than tance than (200-150 (150-120 (120-100 (100-65 cm) (65-30 cm) 12 inches (in/cm) 79 inches (30 cm) (200 cm) Arcs — Left None None None...
Page 267: Enabling And Disabling Parksense
266 STARTING AND OPERATING Enabling And Disabling ParkSense system is disabled, the instrument cluster display will show the “PARKSENSE OFF” message for as long as the ParkSense can be enabled and disabled with the ParkSense vehicle is in REVERSE. switch, located on the switch panel below the Uconnect display.
Page 268: Cleaning The Parksense System
STARTING AND OPERATING 267 If “PARKSENSE UNAVAILABLE SERVICE REQUIRED” • ParkSense, when on, will reduce the volume of the radio appears in the instrument cluster display, see your autho- when it is sounding a tone. rized dealer. • Clean the ParkSense sensors regularly, taking care not to scratch or damage them.
Page 269: Lanesense - If Equipped
268 STARTING AND OPERATING WARNING! CAUTION! • Drivers must be careful when backing up even when • ParkSense is only a parking aid and it is unable to using ParkSense. Always check carefully behind recognize every obstacle, including small obstacles. your vehicle, look behind you, and be sure to check Parking curbs might be temporarily detected or not for pedestrians, animals, other vehicles, obstructions,...
Page 270: Turning Lanesense On Or Off
STARTING AND OPERATING 269 Turning LaneSense On Or Off in the form of torque applied to the steering wheel, as well as a visual warning in the instrument cluster display, to The default status of LaneSense is “Off”. prompt the driver to remain within the lane boundaries. The LaneSense button is located on the switch panel below The driver may manually override the haptic warning by the Uconnect display.
Page 271: Lanesense Warning Message
270 STARTING AND OPERATING Base Instrument Cluster Display — If Equipped When the LaneSense system is on; the lane lines are gray when both of the lane boundaries have not been detected and the LaneSense telltale is solid white. Lane Sense On Message To turn the LaneSense system off, push the LaneSense button once to turn the system off (LED turns on).
Page 272 STARTING AND OPERATING 271 • When the LaneSense system senses the lane has been Left Lane Departure — Both Lanes Detected approached and is in a lane departure situation, the left • When the LaneSense system is on, the lane lines turn thick lane line flashes from white to gray, the left thin from gray to white to indicate that both of the lane line remains solid white and the LaneSense telltale...
Page 273 272 STARTING AND OPERATING green to solid yellow. At this time torque is applied to this time torque is applied to the steering wheel in the the steering wheel in the opposite direction of the opposite direction of the lane boundary. lane boundary.
Page 274 STARTING AND OPERATING 273 System On (Gray Lines/White Telltale Lane Approached (Flashing Yellow Thick Line, Solid Yellow Thin Line/Flashing Yellow Telltale Left Lane Departure — Only Left Lane Detected NOTE: The LaneSense system operates with the similar • When the LaneSense system is on, the LaneSense telltale behavior for a right lane departure when only the right is solid white when only the left lane marking has lane marking has been detected.
Page 275 274 STARTING AND OPERATING warnings in the instrument cluster display and a torque warning in the steering wheel if an uninten- tional lane departure occurs. Lane Sensed (Solid Yellow Thick Line, Solid Yellow Thin Line/Solid Yellow Telltale • When the LaneSense system senses the lane has been approached and is in a lane departure situation, the left Lanes Sensed (White Lines/Green Telltale thick lane line flashes yellow and the left thin line...
Page 276: Changing Lanesense Status
STARTING AND OPERATING 275 NOTE: • The system will not apply torque to the steering wheel whenever a safety system engages. (anti-lock brakes, traction control system, electronic stability control, for- ward collision warning, etc.). • Use of the turn signals and Hazard Warning flashers also suppresses the warnings.
Page 277 276 STARTING AND OPERATING When the vehicle is shifted out of REVERSE (with camera When enabled, active guide lines are overlaid on the image delay turned off), the rear camera mode is exited and the to illustrate the width of the vehicle and its projected previous screen appears again.
Page 278: Refueling The Vehicle
STARTING AND OPERATING 277 1. Open the fuel filler door by pushing on the outer edge of CAUTION! the Fuel Door. • To avoid vehicle damage, ParkView should only be used as a parking aid. The ParkView camera is unable to view every obstacle or object in your drive path.
Page 279 278 STARTING AND OPERATING Emergency Gas Can Refueling Most gas cans will not open the flapper door. A funnel is provided to open the flapper door to allow emergency refueling with a gas can. 1. Retrieve funnel from the spare tire storage area. 2.
Page 280: Vehicle Loading
STARTING AND OPERATING 279 5. Remove funnel from filler pipe, clean off prior to putting This label contains the month and year of manufacture, back in the spare tire storage area. Gross Vehicle Weight Rating (GVWR), Gross Axle Weight Rating (GAWR) front and rear, and Vehicle Identification NOTE: Number (VIN).
Page 281 280 STARTING AND OPERATING Each axle GAWR is determined by the components in the determined by weighing your vehicle on a commercial system with the lowest load carrying capacity (axle, scale before any occupants or cargo are added. springs, tires or wheels). Heavier axles or suspension Loading components sometimes specified by purchasers for in- The actual total weight and the weight of the front and rear...
Page 282: Trailer Towing
STARTING AND OPERATING 281 Gross Vehicle Weight Rating (GVWR) CAUTION! The GVWR is the total allowable weight of your vehicle. Do not load your vehicle any heavier than the GVWR This includes driver, passengers, cargo and tongue weight. or the maximum front and rear GAWR. If you do, parts The total load must be limited so that you do not exceed on your vehicle can break, or it can change the way the GVWR.
Page 283 282 STARTING AND OPERATING If equipped, the electronic Trailer Sway Control (TSC) WARNING! recognizes a swaying trailer and automatically applies individual wheel brakes and/or reduces engine power to It is important that you do not exceed the maximum attempt to eliminate the trailer sway. front or rear GAWR.
Page 284: Trailer Towing Weights (Maximum Trailer Weight Ratings)
STARTING AND OPERATING 283 sway caused by traffic and crosswinds and contributes WARNING! positively to tow vehicle and trailer stability. Trailer sway control and a weight distributing (load equalizing) hitch • An improperly adjusted Weight Distributing Hitch are recommended for heavier Tongue Weights (TW) and system may reduce handling, stability, braking per- may be required depending on vehicle and trailer formance, and could result in a collision.
Page 285: Trailer And Tongue Weight
284 STARTING AND OPERATING Trailer And Tongue Weight NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional Never exceed the maximum tongue weight stamped on factory-installed options, or authorized dealer-installed your trailer hitch.
Page 286 STARTING AND OPERATING 285 Maintenance” for the proper maintenance intervals. When WARNING! (Continued) towing a trailer, never exceed the GAWR or GCWR ratings. • Vehicles with trailers should not be parked on a grade. When parking, apply the parking brake on the WARNING! tow vehicle.
Page 287 286 STARTING AND OPERATING • Proper tire inflation pressures are essential to the safe • An electronically actuated trailer brake controller is and satisfactory operation of your vehicle. Refer to required when towing a trailer with electronically actu- “Tires” in “Servicing And Maintenance” for proper tire ated brakes.
Page 288 STARTING AND OPERATING 287 NOTE: CAUTION! • Disconnect trailer wiring connector from the vehicle If the trailer weighs more than 1,000 lbs (453 kg) before launching a boat (or any other device plugged loaded, it should have its own brakes and they should into vehicle’s electrical connect) into water.
Page 289: Towing Tips
288 STARTING AND OPERATING Automatic Transmission Select the DRIVE range when towing. The transmission controls include a drive strategy to avoid frequent shifting when towing. For increased engine braking on steep down- hill grades, select the LOW range. Speed Control — If Equipped •...
Page 290: Recreational Towing (Behind Motorhome, Etc.)
STARTING AND OPERATING 289 Highway Driving Air Conditioning Reduce speed. Turn off temporarily. RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle WHEELS OFF THE FRONT WHEEL DRIVE FOUR-WHEEL DRIVE TOWING CONDITION GROUND (FWD) (4WD) Flat Tow NONE NOT ALLOWED NOT ALLOWED Dolly Tow...
Page 291: Recreational Towing - 4X4 Models
290 STARTING AND OPERATING 3. Apply the Electric Park Brake (EPB). Place the transmis- be towed on flatbed or vehicle trailer provided all four sion in PARK. Turn the engine OFF. wheels are OFF the ground. 4. Properly secure the front wheels to the dolly, following CAUTION! the dolly manufacturer’s instructions.
Page 292: Off-Road Driving Tips
STARTING AND OPERATING 291 As with other vehicles of this type, failure to operate this CAUTION! vehicle correctly may result in loss of control or vehicle rollover. When driving through water, do not exceed 5 mph (8 km/h). Always check water depth before entering as Off-Road Driving Tips a precaution, and check all fluids afterward.
Page 293: Hill Climbing
292 STARTING AND OPERATING Standing Water information. Do not shift to a lower gear than necessary to maintain headway. Over-revving the engine can spin the Avoid driving in standing water deeper than 16 inches wheels and traction will be lost. (40.5 cm), and reduce speed appropriately to minimize wave effects.
Page 294 STARTING AND OPERATING 293 Traction Downhill WARNING! Shift the transmission into a low gear and the 4WD System If the engine stalls or you lose headway or cannot to 4WD LOW range or Select Hill Descent Control if make it to the top of a steep hill or grade, never attempt equipped (refer to Safety Features in the “Safety”...
Page 295 294 STARTING AND OPERATING After Driving Off-Road WARNING! Off-road operation puts more stress on your vehicle than Abrasive material in any part of the braking system does most on-road driving. After going off-road, it is may cause excessive wear or unpredictable braking always a good idea to check for damage.
Page 296 IN CASE OF EMERGENCY CONTENTS HAZARD WARNING FLASHERS ... .297 JACKING AND TIRE CHANGING ...326 ASSIST AND SOS MIRROR — IF EQUIPPED ..297 ▫...
Page 297 296 IN CASE OF EMERGENCY ▫ Without The Key Fob ....354 ENHANCED ACCIDENT RESPONSE SYSTEM (EARS) .......356 ▫...
Page 298: Hazard Warning Flashers
IN CASE OF EMERGENCY 297 HAZARD WARNING FLASHERS ASSIST AND SOS MIRROR — IF EQUIPPED The Hazard Warning flasher switch is located in the lower center area of the instrument panel. Push the switch to turn on the Hazard Warning flasher.
Page 299 298 IN CASE OF EMERGENCY • Roadside Assistance – If you get a flat tire, or need a tow, WARNING! just push the ASSIST button and you’ll be connected to someone who can help. Roadside Assistance will know ALWAYS obey traffic laws and pay attention to the what vehicle you’re driving and its location.
Page 300 IN CASE OF EMERGENCY 299 3. Once a connection between the vehicle and a SOS NOTE: operator is made, the SOS Call system may transmit the • Your vehicle may be transmitting data as authorized following important vehicle information to a SOS op- by the subscriber.
Page 301 300 IN CASE OF EMERGENCY WARNING! (Continued) WARNING! (Continued) APPS AND SERVICES, AMONG OTHERS, WILL Emergency Services Agent. All occupants should exit NOT OPERATE. the vehicle immediately and move to a safe location. • Modifications to any part of the SOS Call system •...
Page 302 IN CASE OF EMERGENCY 301 • An In-Vehicle Audio message will state “Vehicle device • The SOS Call system software and/or hardware are requires service. Please contact your dealer.” damaged during a crash. • The vehicle battery loses power or becomes discon- WARNING! nected during a vehicle crash.
Page 303 302 IN CASE OF EMERGENCY NOTE: NOTE: Changes or modifications not expressly approved by the party responsible for compliance could void the • Your vehicle may be transmitting data as authorized by user’s authority to operate the equipment. the subscriber. •...
Page 304: Bulb Replacement
IN CASE OF EMERGENCY 303 BULB REPLACEMENT Replacement Bulbs Interior Bulbs Lamps Bulb Number Front Courtesy Light Front Courtesy Lights (Sun Visors) Rear Dome Light (Models Without Retractable roof) Rear Interior Lights (Models With Retractable roof) Interior Lights HT-168 Dome Light (Glove Box) HT-168 Exterior Bulbs Lamps...
Page 305: High Intensity Discharge (Hid) Headlamps - If Equipped
304 IN CASE OF EMERGENCY Lamps Bulb Number Side Indicators (Front – HID) LED (Serviced At An Authorized Dealer) Side Indicators (Side View Mirror) LED (Serviced At An Authorized Dealer) Tail/Brake Lights Premium Tail Lights: LED (Serviced At An Authorized Dealer) Base Tail Lights: W21/5WLL Turn Indicators...
Page 306: Replacing Exterior Bulbs
IN CASE OF EMERGENCY 305 WARNING! A transient high voltage occurs at the bulb sockets of HID headlamps when the headlamp switch is turned ON. It may cause serious electrical shock or electrocu- tion if not serviced properly. See your authorized dealer for service.
Page 307 306 IN CASE OF EMERGENCY WARNING! Carry out the operation of replacing lamps only with the engine off. Also make sure that the engine is cold, to avoid the danger of burns. Turn Signal Light/Position Lights/Daytime Running Lights To replace the bulbs proceed as follows: 1.
Page 308 IN CASE OF EMERGENCY 307 7. Install the bulb and sockets and rotate them clockwise making sure that it is properly locked. 8. Reconnect the electrical connectors. 9. Reinstall the wheel liner. NOTE: We advise referring to an authorized dealer. Front Fog Lights To replace the bulbs proceed as follows: 1.
Page 309 308 IN CASE OF EMERGENCY Side Indicators The Side Indicators are LED. For their replacement see your authorized dealer. Rear Body Side Tail Lamps Contain the following: • Position lights • Stop lights • Direction indicator To replace the bulbs proceed as follows: Body Side Tail Lamp Opening 1.
Page 310 IN CASE OF EMERGENCY 309 Body Side Tail Lamp Reverse Side of Tail Lamp 1 — Rear Body Side Tail Lamp 1 — Direction Indicator Bulb / Stop Lamp Bulb 2 — Ball Stud 2 — Electrical Connector 3 — Ball Studs 5.
Page 311 310 IN CASE OF EMERGENCY Body Side Tail Lamp Liftgate 1 — Rear Body Side Tail Lamp 1 — Lift Gate Access Covers 2 — Ball Stud 3. Disconnect the electrical connector by pushing the re- 10. Install fasteners and tighten body side lamp assembly. lease.
Page 312: Replacing Interior Bulbs
IN CASE OF EMERGENCY 311 6. Reinstall the access panels making sure they are locked in correctly. 7. Finally close the tailgate. 3rd Stop Lamp The CHMSL is LED. For their replacement, see your authorized dealer. License Plate Lights The License Plate light is LED. For their replacement, see your authorized dealer.
Page 313 312 IN CASE OF EMERGENCY Front Courtesy Bulb Housing Front Courtesy Bulb Housing 4. Insert the new bulbs, making sure that they are properly 1 — Retaining Clips locked. 2 — Bulb Housing 5. Reassemble the bulb housing and courtesy light housing 3.
Page 314 IN CASE OF EMERGENCY 313 Dome Light Vanity Mirror 3. Reinstall the visor mirror light cover making sure that it is properly locked. To replace the bulbs proceed as follows: 4. Finally lower the visor mirror cover to the mirror. 1.
Page 315 314 IN CASE OF EMERGENCY Dome Light To replace the bulbs proceed as follows: 1. Lower the handle in the direction shown; remove the dome light. Bulb 3. Insert the new bulb, locking it between the contacts. 4. Reinstall the dome light. Grab Handle/Dome Light 2.
Page 316 IN CASE OF EMERGENCY 315 Interior Cargo Lights 2. Fully disengage the bulb holder from the housing. To replace the bulbs proceed as follows: 1. Using thumb with slight pressure – push bulb holder to the side. Bulb Holder 3. Rotate bulb holder to replace bulb. Bulb Holder...
Page 317: Fuses
316 IN CASE OF EMERGENCY WARNING! (Continued) • Halogen lamps must be handled by touching only the metallic part. If the transparent bulb is in contact with the fingers, reduces the intensity of the emitted light and you can also affect the life of the lamp. In case of accidental contact, rub the bulb with a cloth dampened with alcohol and allow to dry.
Page 318: General Information
IN CASE OF EMERGENCY 317 WARNING! (Continued) • Before replacing a fuse, make sure that the ignition is off and that all the other services are switched off and/or disengaged. • If the replaced fuse blows again, contact an autho- rized dealer.
Page 319: Engine Compartment Fuses/Distribution Unit
318 IN CASE OF EMERGENCY Engine Compartment Fuses/Distribution Unit Removing Fuse Cover and Locking Screw The engine compartment fuse panel is located on the left Proceed as follows: side of the engine compartment. 1. Slowly turn the screw counterclockwise. 2. Slowly release the screw. 3.
Page 320 IN CASE OF EMERGENCY 319 Mounting Fuse Cover and Locking Screw Proceed as follows: 1. Properly secure the fuse cover to the box, slide com- pletely from top to bottom. 2. Fully depress the screw, using the special screwdriver supplied. 3.
Page 321 320 IN CASE OF EMERGENCY Cavity Maxi Fuse Cartridge Fuse Mini Fuse Description – 30 Amp Pink with HID – Supply Body Computer Lamps 20 Amp Blue without HID Lamps – 40 Amp Tan – Brake Control Electron- ics Module –...
Page 322 IN CASE OF EMERGENCY 321 Cavity Maxi Fuse Cartridge Fuse Mini Fuse Description – – 10 Amp Red Engine Control Module Power, Automatic Transmission – – 10 Amp Red Engine Secondary Loads – – 20 Amp Yellow 12V Rear Cargo Outlet Ignition Powered –...
Page 323 322 IN CASE OF EMERGENCY Cavity Maxi Fuse Cartridge Fuse Mini Fuse Description 60 Amp Blue – – Glow Plug Module – 40 Amp Green – Diesel Fuel Filter Heater – 40 Amp Green – HVAC Fan – – 30 Amp Green Power Supply All Wheel Drive –...
Page 324: Interior Fuses
IN CASE OF EMERGENCY 323 Interior Fuses The interior fuse panel is located in the passenger compart- ment on the left side dash panel under the instrument panel. Cavity Blade Fuse Description 7.5 Amp Brown Occupant Restraint Controller 20 Amp Yellow Window Motor Passenger 20 Amp Yellow Window Motor Driver...
Page 325: Rear Cargo Fuse/Relay Distribution Unit
324 IN CASE OF EMERGENCY Cavity Blade Fuse Description 7.5 Amp Brown Electronic Climate Control, Occupant Classification, Rear View Camera, Climate Control, Headlamp Leveling, Terrain Select, Heated Rear Window, Trailer Tow, Haptic Lane Departure 7.5 Amp Brown Keyless Ignition Node Module, Electric Park Brake, RF Hub, Cluster 15 Amp Blue ECC (HVAC) Blower, Lumbar Adjust Driver Seat, Power Outlets...
Page 326 IN CASE OF EMERGENCY 325 Fuse Holder No. 1 Cavity Mini Fuse Description 30 Amp Green Power Inverter 30 Amp Green Memory Seat 20 Amp Yellow Sun Roof – If Equipped 30 Amp Green Power Seat (Passenger Side) 30 Amp Green Power Seat (Driver Side) 7.5 Amp Brown Power Lumbar (Power Seats)
Page 327: Jacking And Tire Changing
326 IN CASE OF EMERGENCY On the Rear Cargo Fuse/Relay Distribution Unit bracket, there is a Maxi Fuse holder for the Power Liftgate and an ATO / Uni Val fuse holder for the HIFI Audio System. Cavity Maxi Fuse Description 30 Amp Green Power Liftgate Cavity...
Page 328 IN CASE OF EMERGENCY 327 1. Open the liftgate. 2. Lift the access cover using the load floor handle. Jack And Tools Location 1 — Jack 2 — Alignment Pin Load Floor Handle 3 — Wheel Bolt Wrench 3. Remove the fastener securing the spare tire, and remove 4 —...
Page 329 328 IN CASE OF EMERGENCY Spare Tire Fastener Jack And Tools 4. Remove the alignment pin from the middle, rotate the 1 — Wheel Bolt Wrench jack counterclockwise, and lift it from the foam tray. 2 — Jack 3 — Emergency Funnel 5.
Page 330: Preparations For Jacking
IN CASE OF EMERGENCY 329 6. Block both the front and rear of the wheel diagonally WARNING! (Continued) opposite the jacking position. For example, if the right places provided. Have the deflated (flat) tire repaired front wheel is being changed, block the left rear wheel. or replaced immediately.
Page 331 330 IN CASE OF EMERGENCY WARNING! (Continued) • Never start or run the engine with the vehicle on a jack. • Do not let anyone sit in the vehicle when it is on a jack. • Do not get under the vehicle when it is on a jack. If you need to get under a raised vehicle, take it to a service center where it can be raised on a lift.
Page 332 IN CASE OF EMERGENCY 331 3. Before raising the vehicle, use the wheel bolt wrench to loosen, but not remove, the wheel bolts on the wheel with the flat tire. Turn the wheel bolts counterclockwise one turn while the wheel is still on the ground. 4.
Page 333 332 IN CASE OF EMERGENCY 7. Remove the alignment pin from the jack assembly and thread the pin into the wheel hub to assist in mounting the spare tire. 8. Mount the spare tire. CAUTION! Be sure to mount the spare tire with the valve stem facing outward.
Page 334: Road Tire Installation
IN CASE OF EMERGENCY 333 NOTE: Specifications” for the proper lug bolt torque. If in doubt about the correct tightness, have them checked • For vehicles equipped, do not attempt to install a with a torque wrench by your authorized dealer or at a center cap or wheel cover on the compact spare.
Page 335: Tire Service Kit - If Equipped
334 IN CASE OF EMERGENCY 5. Lower the jack until it is free. Remove the wheel blocks. WARNING! Reassemble the lug wrench to the jack assembly and stow it in the spare tire area. Secure the assembly using To avoid the risk of forcing the vehicle off the jack, do the means provided.
Page 336 IN CASE OF EMERGENCY 335 Tire Service Kit Storage Tire Service Kit And Components And Operation The Tire Service Kit is stowed under the load floor behind the rear seat. 1. Open the liftgate. 2. Lift the access cover using the load floor handle. Tire Service Kit Components 1 —...
Page 337 336 IN CASE OF EMERGENCY Using The Mode Select Knob And Hoses Using The Power Button Your Tire Service Kit is equipped with the following Push and release the Power Button once symbols to indicate the air or sealant mode. to turn On the Tire Service Kit.
Page 338 IN CASE OF EMERGENCY 337 • The Sealant Bottle is a one tire application use and needs WARNING! to be replaced after each use. Always replace these components immediately at your original equipment • Do not attempt to seal a tire on the side of the vehicle vehicle dealer.
Page 339 338 IN CASE OF EMERGENCY 2. Verify that the valve stem (on the wheel with the WARNING! (Continued) deflated tire) is in a position that is near to the ground. in injuries that are serious or fatal to you, your This will allow the Tire Service Kit Hose to reach the passengers, and others around you.
Page 340 IN CASE OF EMERGENCY 339 3. Remove the cap from the valve stem Injecting Tire Service Kit Sealant Into The Deflated Tire: and then screw the fitting at the end 1. Always start the vehicle before turn- of the Sealant Hose onto the valve ing ON the Tire Service Kit.
Page 341 340 IN CASE OF EMERGENCY NOTE: Sealant may leak out through the puncture in the If the sealant (white fluid) does flow through the Sealant tire. Hose: 1. Continue to operate the pump until If the sealant (white fluid) does not flow within 0 – 10 seconds through the Sealant Hose: sealant is no longer flowing through hose (typically takes 30 - 70 seconds).
Page 342 IN CASE OF EMERGENCY 341 2. The pump will start to inject air into 1. Push the Power Button to turn off the the tire immediately after the Sealant Tire Service Kit. Bottle is empty. Continue to operate the pump and inflate the tire to the cold tire inflation pressure found on the tire and loading information label located in the driver-side door open-...
Page 343 342 IN CASE OF EMERGENCY Drive Vehicle: After Driving: Immediately after injecting sealant and Pull over to a safe location. Refer to “Whenever You Stop inflating the tire, drive the vehicle 5 To Use Tire Service Kit” in this section before continuing. miles (8 km) or ten minutes to ensure 1.
Page 344 IN CASE OF EMERGENCY 343 5. Uncoil the Hose and screw the fitting If the tire pressure is 19 psi (1.3 Bar) or higher: at the end of the hose onto the valve 1. Push the Power Button to turn on stem.
Page 345 344 IN CASE OF EMERGENCY NOTE: When having the tire serviced, advise the autho- 3. Remove the bottle cover. rized dealer or service center that the tire has been sealed using the Tire Service Kit. Sealant Bottle Replacement: 1. Unwrap the power cord. 2.
Page 346: Jump Starting
IN CASE OF EMERGENCY 345 4. Rotate the bottle up beyond vertical to release. Remove The Bottle NOTE: Rotate The Bottle Up 5. Pull the bottle away from the Compressor. • For sealant bottle installation, follow these steps reverse order. •...
Page 347: Preparations For Jump Start
346 IN CASE OF EMERGENCY starting can be dangerous if done improperly, so please follow the procedures in this section carefully. NOTE: When using a portable battery booster pack, follow the manufacturer’s operating instructions and precautions. WARNING! Do not attempt jump starting if the battery is frozen. It could rupture or explode and cause personal injury.
Page 348: Jump Starting Procedure
IN CASE OF EMERGENCY 347 1. Apply the parking brake, shift the automatic transmis- CAUTION! sion into PARK (manual transmission in NEUTRAL) and turn the ignition to OFF/LOCK. Failure to follow these procedures could result in damage to the charging system of the booster vehicle 2.
Page 349 348 IN CASE OF EMERGENCY 6. Once the engine is started, remove the jumper cables in the reverse sequence: Disconnecting The Jumper Cables 1. Disconnect the negative (-) end of the jumper cable from the engine ground of the vehicle with the discharged battery.
Page 350: Refueling In Emergency
IN CASE OF EMERGENCY 349 CAUTION! CAUTION! Accessories plugged into the vehicle power outlets Driving with a hot cooling system could damage your draw power from the vehicle’s battery, even when not vehicle. If the temperature gauge reads “H,” pull over in use (i.e., cellular devices, etc.).
Page 351: Gear Selector Override
350 IN CASE OF EMERGENCY WARNING! You or others can be badly burned by hot engine coolant (antifreeze) or steam from your radiator. If you see or hear steam coming from under the hood, do not open the hood until the radiator has had time to cool. Never try to open a cooling system pressure cap when the radiator or coolant bottle is hot.
Page 352: Freeing A Stuck Vehicle
IN CASE OF EMERGENCY 351 back and forth between DRIVE and REVERSE (for auto- matic transmission) or SECOND GEAR and REVERSE (for manual transmission) while gently pressing the accelerator. NOTE: For vehicles with automatic transmission, shifts between DRIVE and REVERSE can only be achieved at wheel speeds of 5 mph (8 km/h) or less.
Page 353 352 IN CASE OF EMERGENCY NOTE: Push the “ESC Off” switch (if necessary), to place CAUTION! (Continued) the Electronic Stability Control (ESC) system in “Partial reduce the risk of clutch or transmission failure Off” mode, before rocking the vehicle. Refer to “Electronic during prolonged efforts to free a stuck vehicle.
Page 354: Towing A Disabled Vehicle
IN CASE OF EMERGENCY 353 TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. Towing Condition Wheels OFF FWD MODELS 4X4 MODELS The Ground Flat Tow NONE NOT ALLOWED NOT ALLOWED Wheel Lift Or Rear NOT ALLOWED...
Page 355 354 IN CASE OF EMERGENCY If you must use the accessories (wipers, defrosters, etc.) CAUTION! (Continued) while being towed, the ignition must be in the ON/RUN • Ensure that the Electric Park Brake is released, and mode. remains released, while being towed. Note that the Safehold feature will engage the Electric Park Brake whenever the driver’s door is opened (if the battery Without The Key Fob...
Page 356 IN CASE OF EMERGENCY 355 Emergency Tow Hooks — If Equipped CAUTION! If your vehicle is equipped with tow hooks, there will be Towing this vehicle in violation of the above require- one in the rear and two mounted on the front of the vehicle. ments can cause severe engine and/or transmission The rear hook will be located on the driver’s side of the damage.
Page 357 356 IN CASE OF EMERGENCY WARNING! (Continued) • Stand clear of vehicles when pulling with tow hooks. Tow straps may become disengaged, causing serious injury. CAUTION! Tow hooks are for emergency use only, to rescue a vehicle stranded off road. Do not use tow hooks for tow truck hookup or highway towing.
Page 358 IN CASE OF EMERGENCY 357 EVENT DATA RECORDER (EDR) This vehicle is equipped with an Event Data Recorder (EDR). The main purpose of an EDR is to record data that will assist in understanding how a vehicle’s systems per- formed under certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle.
Page 360 SERVICING AND MAINTENANCE CONTENTS SCHEDULED SERVICING ....361 ▫ Exhaust System ......372 ▫...
Page 361 360 SERVICING AND MAINTENANCE ▫ Body And Underbody Maintenance ..405 DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES ....402 ▫...
Page 362: Scheduled Servicing
SERVICING AND MAINTENANCE 361 SCHEDULED SERVICING NOTE: Under no circumstances should oil change inter- vals exceed 10,000 miles (16,000 km), one year or 350 hours Your vehicle is equipped with an automatic oil change of engine run time, whichever comes first. The 350 hours of indicator system.
Page 363: Maintenance Plan
362 SERVICING AND MAINTENANCE Maintenance Plan Required Maintenance Intervals. Refer to the “Maintenance Plan” on the following page for At Every Oil Change Interval As Indicated By Oil the required maintenance intervals. Change Indicator System: Change oil and filter Rotate the tires Rotate at the first sign of irregular wear, even if it oc- curs before the oil indicator system turns on Inspect battery and clean and tighten terminals as re-...
Page 364 SERVICING AND MAINTENANCE 363 Mileage or time passed (which- ever comes first) Or Years: Or Kilometers: If using your vehicle in dusty or off- road conditions, inspect the air cleaner filter, and replace if neces- sary. Inspect the brake linings, replace if necessary.
Page 365 364 SERVICING AND MAINTENANCE Mileage or time passed (which- ever comes first) Or Years: Or Kilometers: Flush and replace the engine cool- ant at 10 years or 150,000 miles (240,000 km) whichever comes first. Inspect and replace PCV valve if necessary.
Page 366: Engine Compartment
SERVICING AND MAINTENANCE 365 ENGINE COMPARTMENT 2.4L Engine 1 — Engine Air Cleaner Filter 5 — Battery 9 — Engine Coolant Pressure Cap 2 — Engine Oil Dipstick 6 — Power Distribution Center (Fuses) 10 — Engine Coolant Reservoir 3 — Engine Oil Fill Cap 7 —...
Page 367: Checking Oil Level
366 SERVICING AND MAINTENANCE Checking Oil Level Adding Washer Fluid To assure proper engine lubrication, the engine oil must be The fluid reservoir is located in the front of the engine maintained at the correct level. Check the oil level at compartment.
Page 368: Maintenance-Free Battery
SERVICING AND MAINTENANCE 367 Maintenance-Free Battery CAUTION! Your vehicle is equipped with a maintenance-free battery. • It is essential when replacing the cables on the You will never have to add water, nor is periodic mainte- battery that the positive cable is attached to the nance required.
Page 369: Engine Oil
368 SERVICING AND MAINTENANCE American Petroleum Institute (API) Engine Oil WARNING! Identification Symbol You can be badly injured working on or around a motor vehicle. Only do service work for which you This symbol means that the oil has have the knowledge and the proper equipment. If you been certified by the American Pe- have any doubt about your ability to perform a service troleum Institute (API).
Page 370: Engine Oil Filter
SERVICING AND MAINTENANCE 369 The engine oil filler cap also shows the recommended Disposing Of Used Engine Oil And Oil Filters engine oil viscosity for your engine. For information on Care should be taken in disposing of used engine oil and engine oil fill cap location, refer to “Engine Compartment”...
Page 371 370 SERVICING AND MAINTENANCE NOTE: Be sure to follow the “Severe Duty Conditions” cleaning of the condenser fins and a performance test. maintenance interval if applicable. Drive belt tension should also be checked at this time. WARNING! WARNING! The air induction system (air cleaner, hoses, etc.) can •...
Page 372: Body Lubrication
SERVICING AND MAINTENANCE 371 Refrigerant Recovery And Recycling R134a — If proper function. When performing other underhood ser- Equipped vices, the hood latch, release mechanism and safety catch should be cleaned and lubricated. R-134a Air Conditioning Refrigerant is a hydrofluoro- carbon (HFC) that is an ozone-friendly substance.
Page 373: Exhaust System
372 SERVICING AND MAINTENANCE NOTE: Life expectancy of wiper blades varies depending WARNING! on geographical area and frequency of use. Poor perfor- mance of blades may be present with chattering, marks, • Exhaust gases can injure or kill. They contain carbon water lines or wet spots.
Page 374: Cooling System
SERVICING AND MAINTENANCE 373 To minimize the possibility of catalytic converter damage: CAUTION! (Continued) • Do not interrupt the ignition when the transmission is in the event of engine malfunction, particularly involv- gear and the vehicle is in motion. ing engine misfire or other apparent loss of perfor- mance, have your vehicle serviced promptly.
Page 375 374 SERVICING AND MAINTENANCE refilled with fresh engine coolant (antifreeze). Check the WARNING! (Continued) front of the A/C condenser for any accumulation of bugs, • Keep hands, tools, clothing, and jewelry away from leaves, etc. If dirty, clean by gently spraying water from a the radiator cooling fan when the hood is raised.
Page 376 SERVICING AND MAINTENANCE 375 Adding Coolant CAUTION! Your vehicle has been built with an improved engine • Mixing of engine coolant (antifreeze) other than speci- coolant (OAT coolant conforming to MS.90032) that allows fied Organic Additive Technology (OAT) engine coolant extended maintenance intervals.
Page 377 376 SERVICING AND MAINTENANCE • Use only high purity water such as distilled or deionized Cooling System Pressure Cap water when mixing the water/engine coolant (anti- The cap must be fully tightened to prevent loss of engine freeze) solution. The use of lower quality water will coolant (antifreeze), and to ensure that engine coolant reduce the amount of corrosion protection in the engine (antifreeze) will return to the radiator from the coolant...
Page 378 SERVICING AND MAINTENANCE 377 community. To prevent ingestion by animals or children, Points To Remember do not store ethylene glycol-based coolant in open contain- NOTE: When the vehicle is stopped after a few miles/ ers or allow it to remain in puddles on the ground. If kilometers of operation, you may observe vapor coming ingested by a child or pet, seek emergency assistance from the front of the engine compartment.
Page 379: Brake System
378 SERVICING AND MAINTENANCE • Maintain engine coolant (antifreeze) concentration at a WARNING! minimum of 50% OAT coolant (conforming to MS.90032) and distilled water for proper corrosion pro- Riding the brakes can lead to brake failure and possi- tection of your engine which contains aluminum com- bly a collision.
Page 380: Manual Transmission - If Equipped
SERVICING AND MAINTENANCE 379 WARNING! WARNING! (Continued) • Do not allow petroleum based fluid to contaminate • Use only manufacturer’s recommended brake fluid. the brake fluid. Brake seal components could be Refer to “Fluids And Lubricants” in “Technical damaged, causing partial or complete brake failure. Specifications”...
Page 381: Automatic Transmission - If Equipped
380 SERVICING AND MAINTENANCE Frequency Of Fluid Change CAUTION! Under normal operating conditions, the fluid installed at Using a transmission fluid other than the manufactur- the factory will give satisfactory lubrication for the life of er’s recommended fluid may cause deterioration in the vehicle.
Page 382: Raising The Vehicle
SERVICING AND MAINTENANCE 381 Fluid Level Check Routine fluid and filter changes are not required. However, change the fluid and filter if the fluid becomes contami- The fluid level is preset at the factory and does not require nated (with water, etc.), or if the transmission is disas- adjustment under normal operating conditions.
Page 383 382 SERVICING AND MAINTENANCE Tire Markings NOTE: • P (Passenger) — Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designation. Example: P215/65R15 95H. • European — Metric tire sizing is based on European design standards.
Page 384 SERVICING AND MAINTENANCE 383 Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on U.S. design standards, or ..blank..= Passenger car tire based on European design standards, or LT = Light truck tire based on U.S.
Page 385 384 SERVICING AND MAINTENANCE EXAMPLE: Service Description: 95 = Load Index – A numerical code associated with the maximum load a tire can carry H = Speed Symbol – A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under cer- tain operating conditions –...
Page 386 SERVICING AND MAINTENANCE 385 EXAMPLE: DOT MA L9 ABCD 0301 DOT = Department of Transportation – This symbol certifies that the tire is in compliance with the U.S. Department of Transportation tire safety standards and is approved for highway use MA = Code representing the tire manufacturing location (two digits) L9 = Code representing the tire size (two digits) ABCD = Code used by the tire manufacturer (one to four digits)
Page 387 386 SERVICING AND MAINTENANCE Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located be- hind the front door. Cold Tire Inflation Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) after sitting for a minimum of three hours.
Page 388 SERVICING AND MAINTENANCE 387 Example Tire Placard Location (Door) Example Tire Placard Location (B-Pillar)
Page 389 388 SERVICING AND MAINTENANCE Tire And Loading Information Placard Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Loading Information placard in “Vehicle Loading”...
Page 390 SERVICING AND MAINTENANCE 389 Steps For Determining Correct Load Limit— this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (1) Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or Metric Example For Load Limit XXX lbs.”...
Page 391 390 SERVICING AND MAINTENANCE WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the rec- ommended load capacity for your vehicle. Never over- load them.
Page 392: Tires - General Information
SERVICING AND MAINTENANCE 391 Tires — General Information WARNING! (Continued) Tire Pressure • Overinflated or underinflated tires can affect vehicle handling and can fail suddenly, resulting in loss of Proper tire inflation pressure is essential to the safe and vehicle control. satisfactory operation of your vehicle.
Page 393 392 SERVICING AND MAINTENANCE Tread Wear CAUTION! Improper cold tire inflation pressures can cause abnormal After inspecting or adjusting the tire pressure, always wear patterns and reduced tread life, resulting in the need reinstall the valve stem cap. This will prevent moisture for earlier tire replacement.
Page 394 SERVICING AND MAINTENANCE 393 pressure should be increased by 3 psi (21 kPa), which Radial Ply Tires equals 1 psi (7 kPa) for every 12°F (7°C) for this outside temperature condition. WARNING! Tire pressure may increase from 2 to 6 psi (13 to 40 kPa) Combining radial ply tires with other types of tires on during operation.
Page 395 394 SERVICING AND MAINTENANCE Run Flat Tires — If Equipped WARNING! Run Flat tires allow you the capability to drive 50 miles Fast spinning tires can be dangerous. Forces generated (80 km) at 50 mph (80 km/h) after a rapid loss of inflation by excessive wheel speeds may cause tire damage or pressure.
Page 396 SERVICING AND MAINTENANCE 395 Life Of Tire The service life of a tire is dependent upon varying factors including, but not limited to: • Driving style. • Tire pressure - Improper cold tire inflation pressures can cause uneven wear patterns to develop across the tire tread.
Page 397 396 SERVICING AND MAINTENANCE Keep dismounted tires in a cool, dry place with as little It is recommended you contact your authorized tire dealer exposure to light as possible. Protect tires from contact with or original equipment dealer with any questions you may oil, grease, and gasoline.
Page 398: Tire Types
SERVICING AND MAINTENANCE 397 Summer Or Three Season Tires — If Equipped WARNING! (Continued) Summer tires provide traction in both wet and dry condi- • Failure to equip your vehicle with tires having ad- tions, and are not intended to be driven in snow or on ice. equate speed capability can result in sudden tire If your vehicle is equipped with Summer tires, be aware failure and loss of vehicle control.
Page 399: Spare Tires - If Equipped
398 SERVICING AND MAINTENANCE Spare Tires — If Equipped Snow Tires Some areas of the country require the use of snow tires NOTE: For vehicles equipped with Tire Service Kit instead during the Winter. Snow tires can be identified by a of a spare tire, please refer to “Tire Service Kit”...
Page 400 SERVICING AND MAINTENANCE 399 spare by looking at the spare tire description on the Tire WARNING! (Continued) and Loading Information Placard located on the driver’s needs to be replaced. Be sure to follow the warnings, side door opening or on the sidewall of the tire. Compact which apply to your spare.
Page 401: Tire Chains (Traction Devices)
400 SERVICING AND MAINTENANCE • For a 215/65R16 tire, use of a snow traction device with handling. Since it is not the same as your original equip- ment tire, replace (or repair) the original equipment tire a maximum projection of 7 mm beyond the tire profile is and reinstall on the vehicle at the first opportunity.
Page 402: Tire Rotation Recommendations
SERVICING AND MAINTENANCE 401 Rotation will increase tread life, help to maintain mud, CAUTION! (Continued) snow, and wet traction levels, and contribute to a smooth, • Install device as tightly as possible and then re- quiet ride. tighten after driving about ½ mile (0.8 km). Refer to the “Maintenance Plan”...
Page 403: Servicing And Maintenance
402 SERVICING AND MAINTENANCE DEPARTMENT OF TRANSPORTATION UNIFORM The suggested Four Wheel Drive (4WD) Tire rotation TIRE QUALITY GRADES method is the “rearward cross” shown in the following diagram. The following tire grading categories were established by the National Highway Traffic Safety Administration. The specific grade rating assigned by the tire’s manu- facturer in each category is shown on the sidewall of the tires on your vehicle.
Page 404: Temperature Grades
SERVICING AND MAINTENANCE 403 on wet pavement, as measured under controlled condi- represent higher levels of performance on the laboratory tions on specified government test surfaces of asphalt test wheel, than the minimum required by law. and concrete. A tire marked C may have poor traction WARNING! performance.
Page 405: Bodywork
404 SERVICING AND MAINTENANCE • Clean and protect the painted parts by applying protec- NOTE: When the vehicle has not been started or driven for tive waxes. at least 30 days, an Extended Park Start Procedure is required to start the vehicle. Refer to “Starting The Engine” •...
Page 406: Body And Underbody Maintenance
SERVICING AND MAINTENANCE 405 Body And Underbody Maintenance cold weather and other extreme conditions will have an adverse effect on paint, metal trim, and underbody protec- Wheel And Wheel Trim Care tion. All wheels and wheel trim, especially aluminum and The following maintenance recommendations will enable chrome plated wheels, should be cleaned regularly using you to obtain maximum benefit from the corrosion resis-...
Page 407 406 SERVICING AND MAINTENANCE When cleaning extremely dirty wheels including excessive Dark Vapor Chrome, Black Satin Chrome, or Low Gloss brake dust, care must be taken in the selection of tire and Clear Coat Wheels wheel cleaning chemicals and equipment to prevent dam- CAUTION! age to the wheels.
Page 408: Preserving The Bodywork
SERVICING AND MAINTENANCE 407 Do not use abrasive cleaning components, solvents, steel Special Care wool or other aggressive material to clean the lenses. • If you drive on salted or dusty roads or if you drive near the ocean, hose off the undercarriage at least once a Preserving The Bodywork month.
Page 409: Interiors
408 SERVICING AND MAINTENANCE • If a lot of driving is done on gravel roads, consider mud • For tough stains, apply Mopar Total Clean, or a mild or stone shields behind each wheel. soap solution to a clean, damp cloth and remove stain. Use a fresh, damp towel to remove soap residue.
Page 410: Plastic And Coated Parts
SERVICING AND MAINTENANCE 409 Cleaning Plastic Instrument Cluster Lenses WARNING! The lenses in front of the instruments in this vehicle are A frayed or torn belt could rip apart in a collision and molded in clear plastic. When cleaning the lenses, care leave you with no protection.
Page 411: Glass Surfaces
410 SERVICING AND MAINTENANCE Glass Surfaces NOTE: If equipped with light colored leather, it tends to show any foreign material, dirt, and fabric dye transfer All glass surfaces should be cleaned on a regular basis with more so than darker colors. The leather is designed for easy Mopar Glass Cleaner, or any commercial household-type cleaning, and FCA recommends Mopar total care leather glass cleaner.
Page 412: Technical Specifications
TECHNICAL SPECIFICATIONS CONTENTS IDENTIFICATION DATA....412 ▫ CNG And LP Fuel System Modifications ..416 ▫ Vehicle Identification Number ... . .412 ▫...
Page 413: Identification Data
412 TECHNICAL SPECIFICATIONS IDENTIFICATION DATA Vehicle Identification Number The Vehicle Identification Number (VIN) is found on the left front corner of the windshield and is visible from the outside of the vehicle. The VIN number also is stamped into the right front body, on the front floor. With the passenger seat in the rear most position, a door in the carpet can be opened to reveal the VIN.
Page 414: Wheel And Tire Torque Specifications
TECHNICAL SPECIFICATIONS 413 Torque Specifications Lug Nut/Bolt **Lug Nut/Bolt Lug Nut/Bolt Torque Size Socket Size 100 Ft-Lbs (135 M12 x 1.25 19 mm N·m) **Use only your authorized dealer recommended lug nuts/ bolts and clean or remove any dirt or oil before tightening. Inspect the wheel mounting surface prior to mounting the tire and remove any corrosion or loose particles.
Page 415: Fuel Requirements
414 TECHNICAL SPECIFICATIONS Tighten the lug nuts/bolts in a star pattern until each WARNING! nut/bolt has been tightened twice. Ensure that the socket is fully engaged on the lug nut/bolt (do not insert it half- To avoid the risk of forcing the vehicle off the jack, do way).
Page 416: Reformulated Gasoline
TECHNICAL SPECIFICATIONS 415 of gasoline with an octane number lower than 87 can cause CAUTION! engine failure and may void or not be covered by the New Vehicle Limited Warranty. DO NOT use E-85, gasoline containing methanol, or gasoline containing more than 15% ethanol (E-15). Use Poor quality gasoline can cause problems such as hard of these blends may result in starting and drivability starting, stalling, and hesitations.
Page 417: Cng And Lp Fuel System Modifications
416 TECHNICAL SPECIFICATIONS If a Non-FFV vehicle is inadvertently fueled with E-85 fuel, The manufacturer recommends that gasoline without MMT be used in your vehicle. The MMT content of gasoline may not be the engine will have some or all of these symptoms: indicated on the gasoline pump, therefore, you should ask your •...
Page 418: Fuel System Cautions
TECHNICAL SPECIFICATIONS 417 Fuel System Cautions NOTE: Intentional tampering with the emissions control system can result in civil penalties being assessed against CAUTION! you. Carbon Monoxide Warnings Follow these guidelines to maintain your vehicle’s performance: WARNING! • The use of leaded gasoline is prohibited by Federal law.
Page 419: Fluid Capacities
418 TECHNICAL SPECIFICATIONS FLUID CAPACITIES U.S. Metric Fuel (Approximate) 2.4 Liter Gasoline Engine 13.5 Gallons 51 Liters Engine Oil With Filter 2.4 Liter Gasoline Engine (SAE 0W- 5.5 Quarts 5.2 Liters 20, API Certified) Cooling System* 2.4 Liter Gasoline Engine (Mopar 6.8 Quarts 6.5 Liters Antifreeze/Engine Coolant 10 Year/...
Page 420: Fluids And Lubricants
TECHNICAL SPECIFICATIONS 419 FLUIDS AND LUBRICANTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant We recommend you use Mopar Antifreeze/Coolant 10 Year/150,000 Mile (240,000 Kilometers) Formula OAT (Or- ganic Additive Technology) meeting the requirements of FCA Material Standard MS.90032. Engine Oil –...
Page 421: Chassis
420 TECHNICAL SPECIFICATIONS Chassis Component Fluid, Lubricant, or Genuine Part Manual Transmission – If Equipped We recommend you use Mopar C Series Manual & Dual Dry Clutch Transmission Fluid. Six-Speed Automatic Transmission (FWD Models) – If Use only Mopar AW-1 Automatic Transmission Fluid, or Equipped equivalent.
Page 422 MULTIMEDIA CONTENTS UCONNECT RADIOS ....423 UCONNECT VOICE RECOGNITION QUICK TIPS ....... . .477 PERSONALIZED MENU BAR .
Page 423 422 MULTIMEDIA ▫ SiriusXM Travel Link (4C NAV)... . .488 ▫ Additional Information ....493 ▫...
Page 424: Uconnect Radios
MULTIMEDIA UCONNECT RADIOS For detailed information about your Uconnect radio or pairing a phone to your Uconnect radio, refer to your Uconnect Owner’s Manual Supplement. NOTE: Uconnect screen images are for illustration pur- poses only and may not reflect exact software for your vehicle.
Page 425: Cybersecurity
424 MULTIMEDIA CYBERSECURITY Your vehicle may be a connected vehicle and may be equipped with both wired and wireless networks. These networks allow your vehicle to send and receive informa- tion. This information allows systems and features in your vehicle to function properly. The risk of unauthorized and unlawful access to your vehicle systems may still exist, even if the most recent version of vehicle software (such as Uconnect software) is...
Page 426: Uconnect Settings
MULTIMEDIA For further information, refer to “Data Collection & Pri- WARNING! (Continued) vacy” in “Uconnect + SiriusXM Guardian” in your software, and if installed in your vehicle, it may Uconnect Owner’s Manual Supplement and “Onboard increase the possibility for vehicle systems to be Diagnostic System (OBD II) Cybersecurity”...
Page 427: Customer Programmable Features - Uconnect 3
426 MULTIMEDIA Customer Programmable Features — Uconnect 3 Your Uconnect system may also have Display Off and back Settings arrow buttons on the faceplate. Push the Display Off button on the faceplate to turn off the Uconnect screen. Push the Display Off button on the faceplate a second time to turn the screen on.
Page 428 MULTIMEDIA NOTE: Only one touchscreen area may be selected at a NOTE: All settings should be changed with the ignition in time. the “ON/RUN” position. When making a selection, press the button on the touch- The following tables list the settings that may be found screen to enter the desired mode.
Page 429 428 MULTIMEDIA Setting Name Selectable Options Touchscreen Beep Voice Settings Voice Response Length Show Command List Units After pressing the “Units” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Units Metric Custom NOTE: • The “Metric” option changes the instrument cluster display to metric units of measure. •...
Page 430 MULTIMEDIA Clock & Date After pressing the “Clock & Date” button on the touch- screen, the following settings will be available: Setting Name Selectable Options Set Time and Format 12 hour 24 hour NOTE: Within the “Set Time and Format” setting, press the corresponding arrow buttons on the touchscreen to adjust to the correct time.
Page 431 430 MULTIMEDIA Safety/Assistance After pressing the “Safety/Assistance” button on the touchscreen, the following settings will be available: Setting Name Selectable Options ParkView Backup Camera Delay — If Equipped NOTE: The “ParkView Backup Camera Delay” setting determines whether or not the screen will display the rear view image with dynamic grid lines for up to ten seconds after the vehicle is shifted out of REVERSE.
Page 432 MULTIMEDIA Setting Name Selectable Options NOTE: The “Forward Collision Warning Plus (FCW+) Sensitivity” setting determines at what relative distance the vehicle directly in front of you needs to be at, before the system will warn you of a possible collision with the vehicle directly in front of you, based on the option is selected.
Page 433 432 MULTIMEDIA Setting Name Selectable Options LaneSense Warning — If Early Medium Late Equipped NOTE: The “LaneSense Warning” setting determines at what distance the LaneSense system will warn you, through steering wheel feedback, of a possible lane departure. LaneSense Strength — If Medium High Equipped...
Page 434 MULTIMEDIA Setting Name Selectable Options Electric Park Brake Service Mode NOTE: The “Electric Park Brake Service Mode” feature provides a means for a technician or vehicle owner to utilize a vehicle integrated, menu driven system, to command the electric park brake retraction, to service the rear foundation brakes (brake pads, calipers, rotors, etc.).
Page 435 434 MULTIMEDIA Lights After pressing the “Lights” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Headlight Sensitivity — If Level 1: minimum Level 2: medium sen- Level 3: maximum sensitivity Equipped sensitivity sitivity NOTE: The greater the sensitivity set, the less the external light variation required to turn on the lights (e.g.
Page 436 MULTIMEDIA Setting Name Selectable Options NOTE: When the “Cornering Lights” feature is selected, if the steering wheel rotation angle is large or the turn signal indica- tors are on, a light (incorporated in the fog light) will turn on, on the relevant side to improve visibility at night. Flash Lights With Lock —...
Page 437 436 MULTIMEDIA Setting Name Selectable Options NOTE: When this feature is selected, all doors will unlock when the vehicle is stopped and the transmission is in the PARK or NEUTRAL position and the driver’s door is opened. Flash Lights With Lock Horn With Lock Horn With Remote Start —...
Page 438 MULTIMEDIA Auto Comfort Systems — If Equipped After pressing the “Auto-On Comfort Systems” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Auto-On Driver Heated/Ventilated Seat & Steering Remote Start All Starts Wheel With Vehicle Start — If Equipped NOTE: When this feature is selected, the driver’s heated seat and heated steering wheel will automatically turn on when tempera- tures are below 40°...
Page 439 438 MULTIMEDIA Audio After pressing the “Audio” button on the touchscreen, the following settings will be available: Setting Name Adjustable Options Equalizer Bass Treble NOTE: When in this display you may adjust the “Bass”, “Mid”, and “Treble” settings. Adjust the settings with the “+” and “–”...
Page 440 MULTIMEDIA Setting Name Adjustable Options Surround Sound — If Equipped Loudness NOTE: The “Loudness” feature improves sound quality at lower volumes when enabled. AUX Volume Offset — If Equipped NOTE: The “AUX Volume Offset” feature provides the ability to tune the audio level for portable devices connected through the AUX input.
Page 441 440 MULTIMEDIA Phone/Bluetooth After pressing the “Phone/Bluetooth” button on the touch- screen, the following settings will be available: Setting Name Selectable Options Paired Phones List of Paired Phones NOTE: This feature shows which phones are paired to the Phone/Bluetooth system. For further information, refer to the Uconnect Owner’s Manual Supplement.
Page 442 MULTIMEDIA Setting Name Selectable Options Subscription Info Sirius ID NOTE: New vehicle purchasers or lessees will receive a free limited time subscription to SiriusXM Satellite Radio with your radio. Following the expiration of the free services, it will be necessary to access the information on the Subscription Information screen to re-subscribe.
Page 443 442 MULTIMEDIA Clear Personal Data After pressing the “Clear Personal Data” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Clear Personal Data Cancel NOTE: When the “Clear Personal Data” feature is selected it will remove all personal data including Bluetooth devices and presets.
Page 444: Customer Programmable Features - Uconnect 4
MULTIMEDIA Customer Programmable Features — Uconnect 4 NOTE: Settings • Only one touchscreen area may be selected at a time. • Depending on the vehicles options, feature settings may vary. When making a selection, press the button on the touch- screen to enter the desired mode.
Page 445 444 MULTIMEDIA Language After pressing the “Language” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Language English Espanol Francais Display After pressing the “Display” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Display Mode...
Page 446 MULTIMEDIA Units After pressing the “Units” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Units Metric Custom NOTE: • The “Metric” option changes the instrument cluster display to metric units of measure. • The “Custom” option allows setting the “Distance, Fuel Consumption” (MPG (US), MPG(UK), L/100km, or km/ L),“Pressure”...
Page 447 446 MULTIMEDIA Time & Date After pressing the “Time & Date” button on the touch- screen, the following settings will be available: Setting Name Selectable Options Set Time Hours NOTE: The “Set Time Hours” feature will allow you to adjust the hours. Set Time Minutes NOTE: The “Set Time Minutes”...
Page 448 MULTIMEDIA Safety/Driving Assistance — If Equipped After pressing the “Safety/Driving Assistance” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Forward Collision Warning Warning Only Warning + Active Brake NOTE: The “Forward Collision Warning Plus (FCW+)” setting includes Advanced Brake Assist (ABA). The ABA applies ad- ditional brake pressure when the driver requests insufficient brake pressure to avoid a potential frontal collision.
Page 449 448 MULTIMEDIA Setting Name Selectable Options LaneSense Warning — If Equipped Early Medium Late NOTE: The “LaneSense Warning” setting determines at what distance the LaneSense system will warn you, through steering wheel feedback, of a possible lane departure. LaneSense Strength High ParkSense —...
Page 450 MULTIMEDIA Lights After pressing the “Lights” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Interior Ambient Lights NOTE: The “Interior Ambient Lights” setting can also be adjusted by selecting any point on the scale between the “+” and “-”...
Page 451 450 MULTIMEDIA Setting Name Selectable Options Cornering Lights NOTE: When the “Cornering Lights” feature is selected, if the steering wheel rotation angle is large or the turn signal indica- tors are on, a light (incorporated in the fog light) will turn on, on the relevant side to improve visibility at night. Flash Lights With Lock —...
Page 452 MULTIMEDIA Setting Name Selectable Options Personal Settings Linked To Key Fob — If Equipped Engine Off Options — If Equipped After pressing the “Engine Off Options” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Headlight Off Delay Radio Off Delay 0 min...
Page 453 452 MULTIMEDIA Setting Name Selectable Options Equalizer Bass Treble NOTE: When in this display you may adjust the “Bass”, “Mid”, and “Treble” settings. Adjust the settings with the “+” and “–” setting buttons on the touchscreen or by selecting any point on the scale between the “+” and “–” buttons on the touchscreen.
Page 454 MULTIMEDIA Setting Name Selectable Options Radio Off With Door NOTE: The “Radio Off With Door” feature will keep the radio on until the driver or passenger door is opened, or when the “Radio Off Delay” selected time has expired. Phone After pressing the “Phone”...
Page 455 454 MULTIMEDIA Radio Setup — If Equipped After pressing the “Radio Setup” button on the touch- screen, the following settings will be available: Setting Name Selectable Options Traffic Announcement DAB Announcement – If Equipped DAB Announcement Categories Alternative Frequency Regional SiriusXM Setup —...
Page 456 MULTIMEDIA Setting Name Selectable Options NOTE: New vehicle purchasers or lessees will receive a free limited time subscription to SiriusXM Satellite Radio with your radio. Following the expiration of the free services, it will be necessary to access the information on the Subscription Information screen to re-subscribe.
Page 457 456 MULTIMEDIA Clear Personal Data After pressing the “Clear Personal Data” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Clear Personal Data Cancel NOTE: When this feature is selected it will remove all personal data including Bluetooth devices and presets.
Page 458: Customer Programmable Features - Uconnect 4/4C Nav Settings
MULTIMEDIA Customer Programmable Features — Uconnect NOTE: 4/4C NAV Settings • Only one touchscreen area may be selected at a time. • Depending on the vehicles options, feature settings may vary. When making a selection, press the button on the touch- screen to enter the desired mode.
Page 459 458 MULTIMEDIA Language After pressing the “Language” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Set Language NOTE: When the “Set Language” feature is selected, you may select one of multiple languages (English / Français / Espa- ñol) for all display nomenclature, including the trip functions and the navigation system (if equipped).
Page 460 MULTIMEDIA Setting Name Selectable Options Display Brightness With Headlights OFF NOTE: To make changes to the Display Brightness with Headlights OFF setting, the headlights must be off and the interior dimmer switch must not be in the party or parade positions. Set Theme Options NOTE: When in this display, you may select the theme for the display screen.
Page 461 460 MULTIMEDIA Setting Name Selectable Options Phone Pop-ups Displayed in Cluster Units After pressing the “Units” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Units Metric Custom NOTE: • The “Metric” option changes the instrument cluster display to metric units of measure. •...
Page 462 MULTIMEDIA Clock After pressing the “Clock” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Sync Time With GPS — If Equipped Set Time Hours NOTE: The “Set Time Hours” feature will allow you to adjust the hours. The “Sync time with GPS” button on the touch- screen must be unchecked.
Page 463 462 MULTIMEDIA Safety & Driving Assistance After pressing the “Safety & Driving Assistance” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Forward Collision Warning Sensitivity — If Equipped Near Medium NOTE: The “Forward Collision Warning Plus (FCW+) Sensitivity” setting determines at what relative distance the vehicle directly in front of you needs to be at, before the system will warn you of a possible collision with the vehicle directly in front of you, based on the option is selected.
Page 464 MULTIMEDIA Setting Name Selectable Options ParkSense — If Equipped Sound Only Sound and Display Front ParkSense Volume Medium High Rear ParkSense Volume Medium High Blind Spot Alert — If Equipped Lights Lights & Chime NOTE: If your vehicle has experienced any damage in the area where the sensor is located, even if the fascia is not damaged, the sensor may have become misaligned.
Page 465 464 MULTIMEDIA Brakes After pressing the “Brakes” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Electric Park Brake Service Mode — If Equipped NOTE: This feature provides a means for a technician or vehicle owner to utilize a vehicle integrated, menu driven system, to command the electric park brake retraction, to service the rear foundation brakes (brake pads, calipers, rotors, etc.).
Page 466 MULTIMEDIA Setting Name Selectable Options Headlight Off Delay 0 sec 30 sec 60 sec 90 sec NOTE: When this feature is selected, it allows the adjustment of the amount of time the headlights remain on after the en- gine is shut off. Headlight Illumination On 0 sec 30 sec...
Page 467 466 MULTIMEDIA Setting Name Selectable Options Auto Dim High Beams — If Equipped NOTE: When the “Auto Dim High Beams” feature is selected, the high beam headlights will activate/deactivate automati- cally under certain conditions. Doors & Locks After pressing the “Doors & Locks” button on the touch- screen, the following settings will be available: Setting Name Selectable Options...
Page 468 MULTIMEDIA Setting Name Selectable Options NOTE: When Driver Door is selected with 1st Press Of Key Fob Unlocks, only the driver’s door will unlock with the first press of the key fob unlock button. You must press the key fob unlock button twice to unlock the passenger’s doors. When All Doors is selected for 1st Press Of Key Fob Unlocks, all doors will unlock on the first press of the key fob unlock button.
Page 469 468 MULTIMEDIA Auto Comfort Systems — If Equipped After pressing the “Auto-On Comfort Systems” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Auto-On Driver Heated/Ventilated Seat & Steering Wheel Remote Start All Starts With Vehicle Start — If Equipped NOTE: When this feature is selected the driver’s heated seat and heated steering wheel will automatically turn on when tem- peratures are below 40°...
Page 470 MULTIMEDIA Radio After pressing the Radio” on the touchscreen, the follow- ing settings will be available: Setting Name Selectable Options Radio Off Delay 0 min 20 min NOTE: When this feature is selected, the radio will stay on for 20 minutes, or until the first door is opened after the engine is shut off.
Page 471 470 MULTIMEDIA Setting Name Selectable Options Equalizer Bass Treble NOTE: When in this display you may adjust the “Bass”, “Mid”, and “Treble” settings. Adjust the settings with the “+” and “–” setting buttons on the touchscreen or by selecting any point on the scale between the “+” and “–” buttons on the touchscreen.
Page 472 MULTIMEDIA Setting Name Selectable Options Paired Phones List Of Paired Phones NOTE: This feature shows which phones are paired to the Phone/Bluetooth system. For further information, refer to the Uconnect Owner’s Manual Supplement. Paired Audio Sources List Of Paired Audio Sources NOTE: This feature shows which Audio Sources are paired to the Phone/Bluetooth system.
Page 473 472 MULTIMEDIA Setting Name Selectable Options Subscription Info Sirius ID NOTE: New vehicle purchasers or lessees will receive a free limited time subscription to SiriusXM Satellite Radio with your radio. Following the expiration of the free services, it will be necessary to access the information on the Subscription Information screen to re-subscribe.
Page 474 MULTIMEDIA Setting Name Selectable Options Regional NOTE: Forces the system to select from a network station when the system is present in a different region. Restore Settings After pressing the “Restore Settings” button on the touch- screen, the following settings will be available: Setting Name Selectable Options Restore Settings...
Page 475 474 MULTIMEDIA System Information After pressing the “System Information” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Software Licenses Software Information Screen NOTE: When this feature is selected, a “Licensing Information” screen will appear, displaying a licensing information website for the radio.
Page 476: Steering Wheel Audio Controls
MULTIMEDIA STEERING WHEEL AUDIO CONTROLS The left-hand control is a rocker-type switch with a push- button in the center. The function of the left-hand control is The remote sound system controls are located on the rear different depending on which mode you are in. surface of the steering wheel at the three and nine o’clock positions.
Page 477: Aux/Usb/Mp3 Control
476 MULTIMEDIA AUX/USB/MP3 CONTROL There is a USB and AUX Jack in the center console. This feature allows an external device to be plugged into the USB or AUX ports. Charge Only USB Port For further information, refer to the Uconnect Owner’s Manual Supplement.
Page 478: Tips
MULTIMEDIA not satisfactorily “clear” by the repositioning of the an- tenna, it is recommended that the radio volume be turned down or off during mobile phone operation when not using Uconnect (if equipped). UCONNECT VOICE RECOGNITION QUICK TIPS Introducing Uconnect Start using Uconnect Voice Recognition with these helpful quick tips.
Page 479: Get Started
478 MULTIMEDIA Get Started All you need to control your Uconnect system with your voice are the buttons on your steering wheel. 1. Visit UconnectPhone.com to check mobile device and feature compatibility and to find phone pairing instruc- tions. 2. Reduce background noise. Wind and passenger conver- sations are examples of noise that may impact recogni- tion.
Page 480: Basic Voice Commands
MULTIMEDIA Basic Voice Commands 5. You can interrupt the help message or system prompts by pushing the VR or Phone button and saying a Voice The basic Voice Commands below can be given at any Command from current category. point while using your Uconnect system. Push the VR button .
Page 481 480 MULTIMEDIA TIP: At any time, if you are not sure of what to say or want to learn a Voice Command, push the VR button and say “Help.” The system will provide you with a list of commands. Uconnect 4 Radio Uconnect 3 Radio...
Page 482: Media
MULTIMEDIA • “ Change source to Bluetooth” • “ Change source to AUX” • “ Change source to USB” • “ Play artist Beethoven”; “ Play album Greatest Hits”; “ Play song Moonlight Sonata”; “ Play genre Classical” TIP: Press the Browse button on the touchscreen to see all of the music on your USB device.
Page 483 482 MULTIMEDIA Uconnect 4 Media Uconnect 4/4C NAV Media...
Page 484: Phone
MULTIMEDIA Phone Making and answering hands-free phone calls is easy with Uconnect. When the Phonebook button is illuminated on your touchscreen, your system ready. Check UconnectPhone.com for mobile phone compatibility and pairing instructions. Push the Phone button . After the beep, say one of the following commands •...
Page 485: Climate
484 MULTIMEDIA Uconnect 4 Phone Uconnect 4/4C NAV Phone Climate Too hot? Too cold? Adjust vehicle temperatures hands-free and keep everyone comfortable while you keep moving ahead. (If vehicle is equipped with climate control.) Push the VR button . After the beep, say one of the following commands: •...
Page 486: Navigation (4C Nav)
MULTIMEDIA Navigation (4C NAV) • “ Set passenger temperature to 70 degrees” The Uconnect navigation feature helps you save time and TIP: Voice Command for Climate may only be used to become more productive when you know exactly how to adjust the interior temperature of your vehicle.
Page 487: Siriusxm Guardian (4C Nav) - If Equipped
486 MULTIMEDIA SiriusXM Guardian (4C NAV) — If Equipped TIP: To start a POI search, push the VR button . After the beep, say: “ Find nearest coffee shop.” CAUTION! Some SiriusXM Guardian services, including SOS Call and Roadside Assistance Call will NOT work without an operable LTE (voice/data) or 3G or 4G (data) net- work connection compatible with your device.
Page 488: Register (4C Nav)
MULTIMEDIA Send & Go 3. Select “Customer Care” to speak with a SiriusXM Guardian Customer Care agent who will activate ser- Vehicle Finder vices in your vehicle, or select “Enter Email” to activate Stolen Vehicle Assistance on the web. Remote Vehicle Start** •...
Page 489: Siriusxm Travel Link (4C Nav)
488 MULTIMEDIA • Press the Settings button in the upper left corner of the app to bring up app settings and access the Assist Call Centers. NOTE: further information please visit DriveUconnect.com (U.S. Residents) or DriveUconnect.ca (Canadian Residents). SiriusXM Travel Link (4C NAV) Need to find a gas station, view local movie listings, check a sports score or the 5 - day weather forecast? SiriusXM Travel Link is a suite of services that brings a wealth of...
Page 490: Apple Carplay - If Equipped
MULTIMEDIA Apple CarPlay — If Equipped TIP: Traffic alerts are not accessible with Voice Command. Apple CarPlay allows you to use your voice to interact with Siri through your vehicle’s voice recognition system, and use your smartphone’s data plan to project your iPhone and a number of its apps onto your Uconnect touchscreen.
Page 491 490 MULTIMEDIA Apple CarPlay On 7-inch Display Apple CarPlay On 8.4-inch Display Refer to your Uconnect Owner’s Manual Supplement for further information.
Page 492: Android Auto - If Equipped
MULTIMEDIA Android Auto — If Equipped Android Auto allows you to use your voice to interact with Android’s best-in-class speech technology through your vehicle’s voice recognition system, and use your smart- phone’s data plan to project your Android powered smart- phone and a number of its apps onto your Uconnect touchscreen.
Page 493: General Information
492 MULTIMEDIA General Information The following regulatory statement applies to all Radio Frequency (RF) devices equipped in this vehicle: This device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: 1.
Page 494: Additional Information
MULTIMEDIA Additional Information CD MAINTENANCE © 2017 FCA US LLC. All rights reserved. Mopar and To keep a CD in good condition, take the following Uconnect are registered trademarks and Mopar Owner precautions: Connect is a trademark of FCA US LLC. Android is a 1.
Page 496 CUSTOMER ASSISTANCE CONTENTS SUGGESTIONS FOR OBTAINING SERVICE FOR ▫ Customer Assistance For The Hearing Or Speech YOUR VEHICLE ......496 Impaired (TDD/TTY) .
Page 497: Suggestions For Obtaining Service For Your Vehicle
496 CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR IF YOU NEED ASSISTANCE YOUR VEHICLE The manufacturer and its authorized dealer are vitally interested in your satisfaction. We want you to be happy Prepare For The Appointment with our products and services. If you are having warranty work done, be sure to have the right papers with you.
Page 498: Fca Us Llc Customer Center
CUSTOMER ASSISTANCE 497 In Mexico Contact Any communication to the manufacturer’s customer center should include the following information: Av. Prolongacion Paseo de la Reforma, 1240 • Owner’s name and address Sante Fe C.P. 05109 • Owner’s telephone number (home and office) Mexico, D.
Page 499: Customer Assistance For The Hearing Or Speech
498 CUSTOMER ASSISTANCE Customer Assistance For The Hearing Or Speech questions about the service contract, call the manufactur- Impaired (TDD/TTY) er’s Service Contract National Customer Hotline at 1-800- 521-9922 (Canadian residents, call (800) 465-2001 English / To assist customers who have hearing difficulties, the (800) 387-9983 French).
Page 500: Warranty Information
CUSTOMER ASSISTANCE 499 REPORTING SAFETY DEFECTS WARNING! In The 50 United States And Washington, D.C. Engine exhaust (internal combustion engines only), If you believe that your vehicle has a defect that could some of its constituents, and certain vehicle compo- cause a crash or cause injury or death, you should nents contain, or emit, chemicals known to the State of immediately inform the National Highway Traffic...
Page 501: In Canada
500 CUSTOMER ASSISTANCE In Canada Diagnostic Procedure Manuals If you believe that your vehicle has a safety defect, you Diagnostic Procedure Manuals are filled with diagrams, should contact the Customer Service Department imme- charts and detailed illustrations. These practical manuals diately.
Page 502 INDEX...
Page 503 502 INDEX Adding Engine Coolant (Antifreeze) ... . .375 Alarm Additives, Fuel ......416 Arm The System .
Page 504 INDEX 503 Fluid Type ......380, 420 Brightness, Interior Lights ....60, 61 Special Additives .
Page 505 504 INDEX Child Restraints Console, Floor ......94 Booster Seats ......205 Contract, Service .
Page 506 INDEX 505 Dipsticks Emission Control System Maintenance... .132 Oil (Engine) ......366 Engine .
Page 507 506 INDEX Exterior Lighting......55 Fuel ........414 Exterior Lights .
Page 508 INDEX 507 Hazard Warning Flasher..... .297 Instrument Cluster ..... . .107 Headlights Instrument Cluster Display Automatic .
Page 509 508 INDEX Key, Replacement......23, 30 Exterior .......222 Keys .
Page 510 INDEX 509 Load Floor, Cargo ......91 Shift Speeds ......238 Loading Vehicle.
Page 511 510 INDEX Checking ......366 Personalized Menu Bar ..... .423 Dipstick .
Page 512 INDEX 511 Rear Seat, Folding ......39, 45 Rotation, Tires ......401 Rear Wiper/Washer.
Page 513 512 INDEX Extender .......178 Sentry Key Front Seat ..... . .168, 170, 172 Key Programming .
Page 514 INDEX 513 Resume .......260 Tie Down Hooks, Cargo ....91, 93 Speed Control (Cruise Control) .
Page 515 514 INDEX Snow Tires ......398 Trailer Towing Guide ......283 Spare Tire .
Page 516 INDEX 515 Vanity Mirrors ......55 Windows ....... . .80 Vehicle Identification Number (VIN) .
Page 517 INSTALLATION OF RADIO TRANSMITTING The antenna cable should be as short as practical and EQUIPMENT routed away from the vehicle wiring when possible. Use Special design considerations are incorporated into this only fully shielded coaxial cable. vehicle’s electronic system to provide immunity to radio Carefully match the antenna and cable to the radio to frequency signals.

Jeep Compass2018 Owner's Manual

Getting to Know Your Vehicle

Getting to Know Your Instrument Panel

Safety

Starting and Operating

In Case of Emergency

Servicing and Maintenance

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jeep Compass2018

Summary of Contents for Jeep Compass2018
