Page 2
Table de FICHE D’INFORMATION SUR LE PRODUIT.....................16 SERVICE DE RÉPARATION ET PIÈCES DE RECHANGE................18...
Page 3
ATTENTION Si le câble d'alimentation est endommagé, il doit être remplacé par le fabricant, son service après vente ou des personnes de qualification similaire afin d'éviter un danger. Cet appareil peut être utilisé par des enfants âgés d'au moins 8 ans et par des personnes ayant des capacités physiques, sensorielles ou mentales réduites ou dénuées d’expérience ou de connaissance, s'ils (si elles) sont correctement surveillé(e)s...
Page 4
MISE EN GARDE: Ne pas utiliser de dispositifs mécaniques ou autres moyens pour accélérer le processus de dégivrage autres que ceux recommandés par le fabricant. MISE EN GARDE: Ne pas endommager le circuit de réfrigération. MISE EN GARDE: Ne pas utiliser d'appareils électriques à l'intérieur du compartiment de stockage des denrées, à...
Page 5
Installation et mise en service: L’appareil doit être installé sur le sol, sur une surface plane et horizontale en s’assurant que les ouvertures d’aération sont correctement dégagées. Ne jamais essayer de remplacer ou de réparer vous même une partie ou un composant de l’appareil, demandez de l’aide à un personnel professionnel et qualifié, si besoin.
Page 6
MISES EN GARDE IMPORTANTES Si vous souhaitez vous débarrasser d’un vieux congélateur ou d’un vieux réfrigérateur comportant une serrure sur la porte, veillez à ce que celle-ci soit désactivée afin d'éviter que des enfants enfermés à l'intérieur en jouant. retrouvent ...
Page 7
DESCRIPTION 1. Compartiment à glace 2. Bouton de réglage de la température (au dos) 3. Étagère 4. Pieds réglables 5. Bac d’égouttage 6. Porte du compartiment à glace 7. Étagère de porte 8. Étagère de porte inférieure Agencement reommandé des aliments Compartiment du réfrigérateur (4°C) Étagères de porte de réfrigérateur (2°C ~ 8°C) L’air froid coule de sorte que la partie inférieure est...
Page 8
L'appareil doit être mis à la terre. Le fabricant n'est pas responsable des dommages pouvant résulter du branchement sur une prise sans mise à la terre. INSTALLATION Installez l’appareil dans une pièce sèche et suffisamment aérée. L’emplacement ne doit pas être directement exposé...
Page 9
AVANT DE REMPLIR LE RÉFRIGÉRATEUR Enlevez tous les matériaux d'emballage. x Laissez l’appareil fonctionner à vide pendant 2 ou 3 heures, le temps que chacun des compartiments arrive à la température adéquate. x Nettoyez l'intérieur de l'appareil avec de l'eau chaude et un peu de produit nettoyant, afin d'enlever les poussières liées à...
Page 13
DÉGIVRAGE DU COMPARTIMENT À GLACE Le compartiment à glace doit être dégivré régulièrement ou dès que l’épaisseur du givre dépasse 3 mm. 1. Débranchez l’appareil. 2. Sortez les bacs à glaçons. Vérifiez que le bac d’égouttage est correctement positionné sous le compartiment à glace. 3.
Page 14
4. Dévissez les vis (8) de fixation de la charnière du bas (2) et enlevez-la. 5. Enlevez le pied avant gauche (4) et mettez-le à droite. 6. Avant de monter la charnière du bas (2), enlevez le gond (9) et inversez la charnière du bas (2). 7.
Page 15
DÉPANNAGE En cas de problème avec l'appareil, vérifiez les points suivants avant de faire appel au service clients. Problème Causes possibles Solution possible L'appareil ne La prise n'est pas sous tension. Vérifiez que l'appareil est bien branché et marche pas. que la prise est sous tension.
Page 16
SPÉCIFICATIONS Classe de protection contre les chocs électriques Tension et fréquence nominales 220-240V~ 50Hz Puissance d’entrée R600a / 12.5 g Réfrigérant/Quantité Intensité nominale 0,55A Poids net 1 kg Mousse isolante Cyclopentane FR-15...
Page 19
SERVICE DE RÉPARATION ET PIÈCES DE RECHANGE Ne démontez pas et ne réparez pas l'appareil vous-même. Ne pas respecter cette consigne peut entraîner un choc électrique ou des blessures. Pour demander une réparation professionnelle et commander des pièces de rechange, veuillez vous adresser au service après-vente FNAC DARTY.
Page 20
MISE AU REBUT En tant que distributeur responsable, nous accordons une grande importance à la protection de l’environnement. Nous vous encourageons à respecter les procédures correctes de mise au rebut de votre appareil, des piles et des éléments d’emballage. Cela aidera à préserver les ressources naturelles et à...
Table of Contents WARNINGS ..............................2 IMPORTANT SAFETY INSTRUCTIONS ......................NAMES OF PARTS ............................BEFORE INSTALLING THE FRIDGE ........................INSTALLATION ..............................AMBIENT TEMPERATURE ..........................BEFORE PLACING FOOD IN THE FRIDGE ......................TEMPERATURE CONTROL..........................MOVING YOUR APPLIANCE ..........................STORING FOOD IN THE FRIDGE ........................MAKING ICE CUBES ............................
WARNINGS If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Page 24
recommended by the manufacturer. WARNING: Do not damage the refrigerant circuit. WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer. Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
Page 25
components by yourself, ask the service agency for help if necessary. For handling: Always handle the appliance to avoid any damage. GB-4...
IMPORTANT SAFETY INSTRUCTIONS x If you are discarding an old fridge with a lock / catch fitted to the door, ensure that it is left in a disabled condition to prevent the entrapment of young children when playing. x Unplug the appliance from the mains socket when not in operation and before cleaning. Remove food before cleaning the appliance.
NAMES OF PARTS 1. Ice box 2. Temperature control knob (at the rear) 3. Shelf 4. Levelling feet 5. Drip tray 6. Ice box door 7. Door shelf 8. Lower door shelf Recommended food arrangement Refrigerator compartment (4°C) Refrigerator door shelves (2°C ~ 8°C) Cold air sinks so the bottom part is the coldest.
INSTALLATION Install the appliance in a dry, well ventilated room. The installation location should neither be exposed to direct sunlight nor near a heat source, e.g. a cooker, radiator, etc. To ensure adequate ventilation for the appliance, allow a minimum of 10 cm of airspace on each side of the cabinet.
TEMPERATURE CONTROL The fridge is controlled with a temperature control knob located at the back of the appliance. Adjust the control knob as desired to suit your individual preference. 0 is off setting 1 is warmest setting 5 is coldest setting In the off position (0) the appliance does not operate (the cooling system is switched off), but power supply is not interrupted.
DEFROSTING THE ICE BOX Defrosting the ice box The ice box will need defrosting periodically or when the frost is more than 3mm thick. 1. Unplug the appliance. 2. Remove the ice trays. x Ensure the drip tray is located correctly under the ice box. 3.
DOOR CONVERSION If you need to hinge your door on the opposite side it is recommended that you call your local authorised service agent to make this conversion or ask a technician. Before you reverse the door, you should ensure the appliance is unplugged and empty. It is recommended to use a crosshead screwdriver and a spanner (both not supplied).
OPERATING NOISES Normal noises x Motors are running. x Refrigerant is flowing through the tubing. CLEANING AND MAINTENANCE Do not use abrasive cleaning agents or solvents. Set the temperature control knob to the off position (0) and disconnect the mains plug from the mains socket.
TROUBLESHOOTING If there is a problem with your appliance, please check the following points before contacting customer service. Problem Possible causes Possible solution Appliance does No electricity at power outlet. Check that the plug is correctly connected not operate. and power switched on. Noises Cabinet not stable or level.
REPAIR AND SPARE PARTS SERVICE Do not disassemble or repair the appliance by yourself. Failure to do so may result in an electric shock or personal injury. To access to professional repair and order spare parts, please get the support from FNAC DARTY after-sales service.
Page 39
DISPOSAL As a responsible retailer we care about the environment. As such we urge you to follow the correct disposal procedure for the appliance and packaging materials. This will help conserve natural resources and ensure that it is recycled in a manner that protects health and the environment. You must dispose of this appliance and its packaging according to local laws and regulations.
Page 40
THE COLDEST PART OF THE REFRIGERATOR The symbol indicates the location of the coldest part of your refrigerator. This area is in between the vegetable compartment at the bottom and the symbol at the top, or the shelf at the same height. In order to maintain the temperature in this area, make sure not to change the position of this shelf.
Page 41
Inhoudsopgave WAARSCHUWINGEN ............................ 2 BELANGRIJKE VEILIGHEIDSVOORZORGEN ....................BENAMING VAN DE ONDERDELEN ........................ VOORDAT U DE DIEPVRIEZER INSTALLEERT ....................INSTALLATIE ............................... OMGEVINGSTEMPERATUUR ........................VOORDAT U LEVENSMIDDELEN IN DE KOELKAST ................. TEMPERATUURREGELING ......................... UW APPARAAT VERPLAATSEN ........................LEVENSMIDDELEN IN DE KOELKAST ......................IJSBLOKJES MAKEN ...........................
Page 42
WAARSCHUWINGEN Dit apparaat is bedoeld voor gebruik in huishoudelijke en soortgelijke toepassingen zoals - keukenkeukens in winkels, kantoren en andere werkomgevingen; - boerderijen en door klanten in hotels, motels en andere typen woonomgevingen; - bed & breakfast-type omgevingen; - catering en soortgelijke niet-retailtoepassingen. Een beschadigd netsnoer mag uitsluitend worden vervangen door de fabrikant, een erkende reparatieservice of vaklui met gelijkwaardige kwalificaties om gevaar te voorkomen.
Page 43
apparatuur of middelen dan diegene door de fabrikant worden aanbevolen om het ontdooiproces te versnellen. WAARSCHUWING: zorg ervoor dat het koelvloeistofcircuit niet wordt beschadigd. WAARSCHUWING: gebruik geen elektrische apparaten in de voedselvakken van het apparaat, tenzij dit door de fabrikant ervan wordt aanbevolen.
Page 45
BELANGRIJKE VEILIGHEIDSVOORZORGEN Voordat u een oude diepvries of koelkast met slot/vergrendeling afdankt, dient u ervoor te zorgen dat het slot/de vergrendeling wordt stukgemaakt om te voorkomen dat jonge kinderen tijdens het spelen opgesloten kunnen raken Haal de stekker van het apparaat uit het stopcontact wanneer het niet in werking is en voordat u het gaat schoonmaken.
Page 46
BENAMING VAN DE ONDERDELEN 1. IJsvak 2. Temperatuurregelaar (achteraan) 3. Schap 4. Regelbare voetjes 5. Opvangbak 6. Deur van ijsvak Deurschap 8. Onderste deurschap Aanbevolen rangschikking van de levensmiddelen Deurvakken van de koelkast (2°C ~ 8°C) Koelgedeelte (4°C) Koude lucht dealt zodat het onderste gedeelte het Bovenste gedeelte: eieren, boter, kaas…...
Page 47
INSTALLATIE Installeer dit apparaat in een droge, goed geventileerde ruimte. De plaats waar het apparaat wordt geïnstalleerd mag niet aan rechtstreeks zonlicht of een andere warmtebron zijn blootgesteld, zoals een fornuis, radiator enz. Zorg voor een tussenruimte van minstens 10 cm aan elke kant van de behuizing om een goede ventilatie van het apparaat te garanderen.
Page 48
TEMPERATUURREGELING De koelkast wordt geregeld door een temperatuurregelaar die zich achteraan het apparaat bevindt. Stel deze regelknop naar wens en volgens uw persoonlijke voorkeur in. 0 is de uit-stand 1 is de warmste stand 5 is de koudste stand In de uit-stand (0) werkt het apparaat niet (het koelsysteem is uitgeschakeld), maar blijft het apparaat wel onder spanning.
Page 49
erse levensmiddelen uivel en eieren NL-9...
Page 50
ood vlees evogelte is en zeevruchten NL-10...
Page 51
ant-en-klaar voedingsmiddelen en restjes roentelade IJSBLOKJES MAKEN NL-11...
Page 52
HET IJSVAK ONTDOOIEN Ontdooi het ijsvak regelmatig of wanneer de ijslaag meer dan 3mm dik is. 1. Haal de stekker uit het stopcontact. 2. Verwijder de bakjes voor ijsblokjes. Zorg dat de opvangbak zich juist onder het ijsvak bevindt. 3. Eenmaal het ijsvak volledig is ontdooid, maak de binnenkant schoon (zie 'Reiniging en onderhoud'). 4.
Page 53
TIPS OM ENERGIE TE BESPAREN Voor het meest energie-efficiënte gebruik van uw apparaat: * Zorg voor voldoende ventilatie van uw koelkast-diepvries als aanbevolen in de installatie-instructies. * Laat warme gerechten afkoelen voordat u deze in het apparaat zet. * Open de deur zo weinig mogelijk. * Sluit de geopende deur altijd zo snel mogelijk.
Page 54
PROBLEMEN OPLOSSEN Als er een probleem met u uw apparaat is, kunt de onderstaande punten controleren voordat u contact opneemt met een klantenservice. Probleem Mogelijke oorzaken Mogelijke oplossing Het apparaat Geen spanning bij het Controleer of de stekker goed in het werkt niet stopcontact.
Page 58
SERVICE VOOR REPARATIES EN RESERVEONDERDELEN Demonteer of repareer het apparaat niet zelf om het risico op een elektrische schok of persoonlijk letsel te vermijden. Voor professionele reparaties of het bestellen van reserveonderdelen, neem contact op met de klantenservice van FNAC DARTY. Reserveonderdelen voor uw apparaten worden binnen 15 werkdagen na het ontvangen van de bestelling geleverd.
Page 59
VERWIJDERING Als verantwoordelijke handelaar dragen we zorg voor het milieu. We moedigen u aan om de juiste verwijderingsprocedure voor uw apparaat en verpakkingsmateriaal te volgen. Dit draagt bij tot het behoud van de natuurlijke rijkdommen door deze te recyclen zodat zowel de menselijke gezondheid en het milieu worden beschermd.
Page 60
KOUDSTE ZONE VAN DE KOELKAST Het hiernaast vermelde symbool geeft de plaats van de koudste zone in uw koelkast aan. Deze zone is aan de onderkant afgebakend door het glas van de groentelade en aan de bovenkant door het symbool of het rek dat zich op dezelfde hoogte bevindt.
Page 62
Reference number Title 2014/30/EU EMC Directive (EMC) 2014/35/EU Low Voltage Directive (LVD) 2009/125/EC Eco design requirements for energy-related products (ErP) 2011/65/EU & (EU) 2015/863 RoHS EMC: EN 55014-1:2017 EN 55014-2:2015 EN IEC 61000-3-2:2019 EN 61000-3-3:2013/A1:2019 LVD : EN 60335-1:2012/A2:2019 EN 60335-2-24:2010/A2:2019 EN 62233:2008 ErP : (EU) 2019/2016...
