6.2: Alarm/Warning code list
(X) Dependent on parameter
1) Cannot be auto-reset via Par 14-20
A trip is the action taken when an alarm has
occurred. The trip will coast the motor and can
be reset by pressing the reset button or make
a reset by a digital input (Par. 5-1* [1]). The
event that causes an alarm cannot damage
the drive or result in dangerous conditions. A
trip lock is the action taken when an alarm oc-
curs that may cause damage to the drive or
Description
Tracking Error
Output Frequency at Maximum Limit
Mechanical Brake Low
Voltage Limit
Control Board Overtemperature
Heatsink Temperature Low
Option Configuration Has Changed
Safe Stop
Illegal FC configuration
PTC 1 Safe Stop
Dangerous Failure
Drive Initialized to Default Value
Encoder Loss
Analog input 54 wrong settings
See Instruction Manual for MCO 305
MG.33.A9.22 - VLT is a registered Danfoss trademark
Warning Alarm/Trip Alarm/Trip Lock
(X) (X)
X
(X)
X
X X X
X
X
(X) (X) 1)
X
X 1)
X
X
X
(X) (X)
X
X
X X
its connected parts. A trip lock situation can
only be reset by a power cycling.
LED indication
Warning
Alarm
Trip-locked
6. Troubleshooting
Parameter
Reference
4-30
2-20
5-19
5-19
5-19
1)
17-61
S202
14-23
yellow
flashing red
yellow and red
