ILLUSTRATED PARTS BREAKDOWN

12
11
1 Header_Sign_Upper_End
2 Header_Sign_Upper_Left
3 Header_Sign_Upper_Right
4 Bin_Tray_Shelf_Fiberglas
2
1
10
5 Exterior_Glass_End_Right
6 Door_Glass_Frt_Right
7 Knob_Door_Plastic_Right
8 Knob_Door_Plastic_Left
10
Note: Depending Upon Features And
Options Chosen, Illustration Shown May
Not Exactly Reflect Your Particular Case.
3
8
9
9 Deck_Base_Wood
10 Door_Glass_Frt_Left
11 Frame_Base
12 Exterior_Glass_End_Left
4
5
6
7
