- Page 1 READ AND SAVE THESE INSTRUCTIONS INSTALLATION & OPERATING MANUAL SELF-SERVICE COUNTERTOP UNIT - MODEL CSC3223 SCC P/N 99425 888 E. Porter Road · Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com I:\Oper Manuals\Impulse\CSC3223_99425.pub Rev F Date: 6.19.2012...
-
Page 2: Table Of Contents
TABLE OF CONTENTS OVERVIEW AND WARNINGS ……………….……………..…………………..…….…………..…..……… INSTALLATION ………….………………………………………………………………………………… START-UP AND OPERATION ……….. …..….…………………...………...…..……………………… MAINTENANCE FUNDAMENTALS: SHELF ASSEMBLY REMOVAL / DECKING REMOVAL ..MAINTENANCE FUNDAMENTALS: STD. DOOR MECHANISM / RYOBI DOOR MECHANISM .. LIGHT FIXTURES - FLUORESCENT ………………………………………………………………….. LIGHT FIXTURES - LED …………………………………………………………………………………. SERIAL LABEL LOCATION &... -
Page 3: Overview And Warnings
OVERVIEW AND WARNINGS OVERVIEW The Structural Concepts non-refrigerated service cases are designed to merchandise unpackaged bakery products at ambient temperatures. These cases should be installed and operated according to the following instructions to insure proper performance. This unit is designed for the display of products in ambient store conditions where temperatures and humidity are maintained at a maximum of 75°... -
Page 4: Installation
INSTALLATION Remove Unit From Skid Position the unit near a suitable electrical outlet. Caution: Case must always remain supported or center of gravity will allow case to fall. Slide unit to rear of skid and tip backward off skid. Position and Level Units For your safety, equipment is furnished with a properly grounded cord connector. -
Page 5: Start-Up And Operation
START-UP AND OPERATION For your safety, equipment is furnished with a properly grounded cord connector. Do not attempt to defeat the grounded connector. Light Switch Set-up Counter Top Unit Remove case from skid and place on counter in the position at which the case will reside. -
Page 6: Maintenance Fundamentals: Shelf Assembly Removal / Decking Removal
MAINTENANCE FUNDAMENTALS: SHELF ASSEMBLY REMOVAL / DECKING REMOVAL Shelf Assembly Removal Remove brackets. Note: It may be necessary to remove the nylon shipping bracket retainers. Shelves can be removed for repositioning, Pliers will be required to accomplish this task. removal (for individual merchandising requirements) and cleaning. - Page 7 MAINTENANCE FUNDAMENTALS: STANDARD DOOR MECHANISM / RYOBI DOOR MECHANISM Door “Hold Open” Feature To reposition the shelving or restock the shelves, it is first helpful to use the door ‘hold open” feature. Open the door all the way (See light fixture). ...
-
Page 8: Light Fixtures - Fluorescent
LIGHT FIXTURES - FLUORESCENT (SEE NEXT PAGE FOR LED LIGHT FIXTURES) Light Fixtures Light Assemblies (Inside Edge - Both Sides) Light fixtures are located on the sides of each door assembly, both sides (just inside the doors). Open the door all the way. ... -
Page 9: Light Fixtures - Led
LIGHT FIXTURES - LED (SEE PREVIOUS PAGE FOR FLUORESCENT LIGHT FIXTURES) Light Fixtures Light fixtures are located on the sides of each LED Light Assemblies door assembly, both sides (just inside doors). (Inside See illustrations at right. Edge Both Sides) LED Light Fixture Removal Removal of lamp:... -
Page 10: Serial Label Location & Information Listed / Tech Info & Service
SERIAL LABEL LOCATION & INFORMATION LISTED / TECH INFO & SERVICE Serial Label Location & Information Listed / Technical Information & Service Serial labels are located near the electrical access on your case. Serial labels contain electrical, temperature & refrigeration information, as well as regulatory standards to which the case conforms. -
Page 11: Troubleshooting
TROUBLESHOOTING Case Lights Not Working Check bulbs for proper installation and connection. Check for burned out bulbs. System is not Operating Confirm the utility power is on. Check the circuit breaker box for tripped circuits. - Page 12 CLEANING SCHEDULE Cleaning Daily Weekly Monthly Task Clean all case exterior surfaces with a household or Clean Case Exterior commercial glass cleaner and a soft cloth. Clean the interior case deck and shelving surfaces Clean Case Interior with a warm water and mild soap solution.
- Page 13 ILLUSTRATED PARTS BREAKDOWN (STANDARD CASE ONLY) Note: Depending Upon Features And Options Chosen, Above Illustration May Not Exactly Reflect Your Particular Case.
-
Page 14: Illustrated Parts Breakdown
ILLUSTRATED PARTS BREAKDOWN Note: Depending Upon Features And Options Chosen, Above Illustration May Not Exactly Reflect Your Particular Case. -
Page 15: Parts List
PARTS LIST Sign Upright Tube Light Ballast Acrylic Sign Side Light Assembly Shelf Assembly Deck Tissue Holder Shelf Support Front Front Panel or Storage Door Shelf Support Rear Acrylic End Glass Shelf Bracket Top Glass Bulb Acrylic Sign Light Socket Door Assembly Bulb Cover Single Pole Switch... -
Page 16: Technical Service Contact Information & Warranty Information
SCC TECHNICAL SERVICE CONTACT INFORMATION & WARRANTY INFORMATION STRUCTURAL CONCEPTS CORPORATION TECHNICAL SERVICE PHONE NUMBER: 1.800.433.9489 or For Your Master Service Agent See WWW.STRUCTURALCONCEPTS.COM/Contact/Master_Service_Agents.asp LIMITED WARRANTY All sales by Structural Concepts Corporation (SCC) are subject to the following limited warranty. “Goods” refers to the product or products being sold by SCC. Warranty Scope: Warranty is for equipment sold in the United States, Canada, Mexico and Puerto Rico.
