Installation Overview

Figure 12: Arrows on the Front of IW9165D

You must also ensure the access point is mounted in such a way as to ensure that all antenna ports and the

console port are accessible for future use.

Note

Wall Mounting the Access Point with the Fixed Mounting Kit

The optional fixed mounting kit contains a mounting bracket for wall or pole mounting. You can use the

mounting bracket as a template to mark the positions of the mounting holes for your installation. You then

install the mounting plate, and attach the access point when you are ready.

The following figure shows the mounting bracket dimensions.

Left arrow: -45° tilt

Righ arrow: +45° tilt

Omnidirectional antennas are vertically polarized and should be mounted vertically.

Cisco Catalyst IW9165D Heavy Duty Access Point Hardware Installation Guide

Wall Mounting the Access Point with the Fixed Mounting Kit

Middle arrow: straight installation
