About Cisco Catalyst IW9165D Heavy Duty Access Point
PID
IW-ANT-PNL-515-N=
IW-ANT-OMV-2567-N=
IW-ANT-OMH-2567-N=
AIR-ANT2547V-N=
AIR-ANT2547VG-N=
AIR-ANT2547VG-NS=
AIR-ANT2568VG-N=
AIR-ANT2568VG-NS=
AIR-ANT5180V-N=
AIR-ANT5114P2M-N=
For installation instructions and detailed information on any of these antennas, refer to the antenna data sheet
on Cisco.com, or see the antenna guides at:
• Cisco Industrial Routers and Industrial Wireless Access Points Antenna Guide
• http://www.cisco.com/c/en/us/support/wireless/aironet-antennas-accessories/
products-installation-guides-list.html
Follow all safety precautions when installing the antennas. For information on safety, see
when Installing Antennas, on page
Antenna Gain (dBi)
— 15 15
4 7 7
4 7 7
4 — 7
4 — 7
4 — 7
6 — 8
6 — 8
— 7 8
— — 13
41.
Cisco Catalyst IW9165D Heavy Duty Access Point Hardware Installation Guide
Supported External Antennas
Connector Antenna Name
N female Cisco 5 GHz 15 dBi Dual-Port
(x2) Polarization Diverse Directional
Panel Antenna
N male 2.4/5 GHz Tri-Band Omnidirectional
Dipole Antenna, Vertically Polarized,
Self-Identifying
N male 2.4/5 GHz Tri-Band Omnidirectional
Dipole Antenna, Horizontally
Polarized, Self-Identifying
N male Cisco Aironet Dual-Band
Omnidirectional Dipole Antenna
(White)
N male Cisco Aironet Dual-Band
Omnidirectional Dipole Antenna
(Gray)
N male Cisco Aironet Dual-Band
Omnidirectional Dipole Antenna
(Gray), Self-Identifying
N male Cisco Aironet Dual-Band
Omnidirectional Dipole Antenna
(Gray)
N male Cisco Aironet Dual-Band
Omnidirectional Dipole Antenna
(Gray), Self-Identifying
N male Cisco Aironet 5 GHz 8 dBi
Omnidirectional Dipole Antenna
N male (x2) Cisco Aironet 5 GHz 13 dBi
Dual-Port Dual-Polarized Directional
Panel Antenna
