Power Sources; Power Adapters; Power Injectors - Cisco Catalyst IW9165D Hardware Installation Manual

About Cisco Catalyst IW9165D Heavy Duty Access Point
The following table shows the M12-PWR adapter pinouts.
Table 2: M12-PWR Pinouts
Micro-FIT 4P
3
2
1
4

Power Sources

The IW9165D is supported on these power sources:
• DC power: 24 to 48 VDC
• Power over Ethernet (PoE): 802.3af (PoE), 802.3at (PoE+), Cisco Universal PoE (Cisco UPOE).
Warning

Power Adapters

The IW9165D supports the following DC power adapters::
• PID: IW-PWRADPT-MFIT4P=: Operating: -40°C to +65°C, 60W.

Power Injectors

The IW9165D supports the following power injectors:
• IW-PWRINJ-60RGDMG=: Operating: -40°C to +70°C. Power derating of 60W at 70°C, and 65W at
Warning
Caution
Connect the unit only to DC power source that complies with the safety extra-low voltage (SELV)
requirements in IEC 60950 based safety standards. Statement 1033
65°C. Supports 100M/1G/2.5G/5G/10G rates.
To reduce the risk of fire, use only No. 24 AWG or larger telecommunications line cord. Statement 1023
When the AP is installed outdoors or in a wet or damp location, the AC branch circuit powering the AP should
be provided with ground fault protection (GFCI), as required by Article 210 of the National Electrical Code
(NEC).
Cisco Catalyst IW9165D Heavy Duty Access Point Hardware Installation Guide
Wire
RED (22 AWG)
N/C
BLACK (22 AWG)
N/C
Power Sources
M12 A-Code
1
2
3
4
7
