We are very pleased that you have decided to purchase this
product from SWARovSkI oPtIk. If you have any questions,
please consult your specialist dealer or contact us directly at
WWW.SWarovSkIoptIk.com.
1. overview
1 Comfort carrying strap
2 Eyepiece cover
3 twist-in eyecup
4 Focusing wheel
5 Dioptric adjustment ring, right
6 Dioptric adjustment ring, left
7 Measurement button
please find our current product accessories at WWW.SWarovSkIoptIk.com.
DE EN
8 Battery compartment
cover
9 Mode button
10 objective lens cover
11 Snap Shot Adapter
12 Coin opener
13 Spare battery
18
WEEE/ElektroG
this symbol indicates that this product must not
be disposed of as household waste under the
WEEE Directive (Waste Electrical and Electronic
Equipment Directive) and national laws.
this product must be returned to a dedicated
collection site. You can obtain information about collection
sites for waste equipment from your local authorities or from
an authorised site for the disposal of waste electrical and
electronic equipment.
Disposing of this product correctly helps to protect the envi-
ronment and prevents potential damage to both the environ-
ment and human health which could occur if the products
are not handled correctly.
2. For your safety!
2.1. WarNING!
the product meets the requirements of a Class 1 laser pur-
suant to the applicable standards EN 60825-1, IEC 60825-1,
FDA 21 CFR 1040.10 and 1040.11 respectively except for
deviations pursuant to Laser Notice No. 50, dated June 24,
2007. As such, the instrument is safe for eyes and can be
used for any application, but must not be aimed at people
directly.
2.2. General information
Under no circumstances should the housing be opened by
unauthorized personnel!
Never point the instrument at people
from close distances!
DE
EN
19
