We are very pleased that you decided to
purchase this product from SWAROVSKI OPTIK.
If you have any questions, please consult your
specialist dealer or contact us directly at
WWW.SWAROVSKIOPTIK.COM.
8
5
1 Carry strap
2 Rain cap
3 Screw-in-type eye cups
4 Focusing wheel
5 Dioptric scale
Please find our current product accessories at WWW.SWAROVSKIOPTIK.COM.
EN
DE
1
2
3
4
6
7
6 Dioptric zero point
7 Objective cap
8 Snap Shot Adapter
Functional bag
(see page 14-15)
12
For your safety!
WARNING!
Never look at the sun with
the binocular! This leads to
injury of your eyes!
Never look through the
binocular when walking!
You could encounter ob-
stacles!
General information
Please protect your bino-
culars from jolts and jars.
Repairs should be carried
out only by authorized
workshops.
EN
DE
13
Advertisement
Table of Contents
Related Manuals for Swarovski Optik EL 10x42
Summary of Contents for Swarovski Optik EL 10x42
- Page 1 We are very pleased that you decided to purchase this product from SWAROVSKI OPTIK. If you have any questions, please consult your specialist dealer or contact us directly at WWW.SWAROVSKIOPTIK.COM. 1 Carry strap 6 Dioptric zero point 2 Rain cap...
- Page 2 Attaching the lift carrying strap Attachment without pouch or use with pouch detached. Attachment with pouch hooked in on one side.
- Page 3 Operation Adjustment of the screw-in-type eye cups Use without eyeglasses: Basically, there are two different adjustment posi- tions available with different distances between the eye and the lens. This allows you to adjust the eye cups individually to your personal preference. Pos.
- Page 4 Use with equal acuity of both eyes: 1. Pull the focusing wheel outwards. 2. By turning the focusing wheel, set the dioptric scale to “0”. 3. Push the focusing wheel back in. Use with varying acuity of both eyes: 1. Look through the left ocular with your left eye and turn the focusing wheel to focus sharply on a selected object.
- Page 5 In the event of hard-to-remove dirt (e.g. sand) the eye cups can be unscrewed and cleaned very easily. Storage You should keep your binocular in its bag in a well- ventilated, dry place. If the instrument is wet, it must be dried prior to storage.
