We are very pleased that you decided to
purchase this product from Swarovski Optik.
If you have any questions, please consult
your specialist dealer or contact us directly at
WWW.SWAROVSKIOPTIK.COM.
8
5
6
1 Carry strap
2 Rain cap
3 Screw-in-type eye cups
4 Focusing wheel
5 Dioptric scale
Please find our current product accessories at WWW.SWAROVSKIOPTIK.COM.
DE EN
6 Dioptric zero point
7 Objective cap
8 Snap Shot Adapter
Functional bag
(see page 13-14)
11
1
2
3
4
7
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Swarovski Optik EL 8x32 WB
Summary of Contents for Swarovski Optik EL 8x32 WB
- Page 1 We are very pleased that you decided to purchase this product from Swarovski Optik. If you have any questions, please consult your specialist dealer or contact us directly at WWW.SWAROVSKIOPTIK.COM. 1 Carry strap 2 Rain cap 3 Screw-in-type eye cups...
- Page 2 For your safety! WARNING! Never look at the sun with the binocular! This leads to injury of your eyes! Never look through the binocular when walking! You could encounter ob- stacles! General information Please protect your bino- culars from jolts and jars.
- Page 3 Attachment with pouch hooked in on one side. Operation Adjustment of the screw-in-type eye cups Adjustment of interpupillary distance To see a single round image, turn the two halves of the binoculars until no irritating shadows can be seen. Use without eyeglasses: Turn both eye cups (coun- ter-clockwise) until they stop.
- Page 4 Adjustment of focusing By turning the focusing wheel you can focus any object sharply at a distance of 2 m/6.6 ft to infinity. In the infinity position the little nose of the focusing wheel is at the top. Dioptric compensation To achieve optimal image quality, the possibly varying visual acuity between the left and right eye must be corrected.
- Page 5 We have designed all elements and surfaces to require little care. To ensure the long-lasting optical brilliance of your binocular, you should keep the glass surfaces free of dirt, oil and grease. When cleaning the lenses, first remove larger parti- cles with an optical lens brush.
