Zone address is a 3-digit number represented in MA_Z format, where MA specifies a module address in the
Z01 Door
system and Z specifies a zone terminal in the module board. Example: 00_1 - where 00 means the control panel
2 Address 00_1
and 1 means zone terminal Z1. To program a doubled zone - detectors A and B must be specified. Use keypad
keys [A] or [B] to specify these detectors in the zone address field (example: 00_1 A, 00_1 B, ...).
Z01 Door
Note: use loop types NO/DEOL or NC/DEOL for the doubled zones.
Address 00_1 A
2
For a keypad firmware version to v.5.xxx, wireless zone loop type depends on zone address. For wireless zones
Z01 Door
MA_1 – MA_8 the system will automatically assign NO/DEOL loop type and for wireless zones MA_9 – MA_16
the Vibration loop type. Do not change the loop type of the zone!
2 Address 00_1 B
For a keypad firmware version v.5.xxx or higher the loop type is Wireless for all wireless zones MA_1 – MA_16.
Wireless module address:
Virtual wireless module EXT116VM address:
The Loop type menu enables you to program the connection type used for each of the system's zones. The
Z01 Door
actual (physical) loop type for each zone must comply with that selected in the Loop type menu. Available loop
3 Loop Type NC
types:
distinguish between alarms and tamper conditions;
distinguish between alarms and tamper conditions;
Wireless detectors can be enrolled using serial number in a system with following firmware version or higher:
Z01 Door
4 Serial No. N/A
Z01 Door
4 Serial No. 8388608
Model BK4
Loop (zone) Magnetas
Detect tamper Taip
Battery ER14250
Enrolment using serial number is a two step process:
Operation code 201
5
When the detector is successfully enrolled, the mode LR or ES will be displayed in the row. Phrase No SN. will be
Wireless communication
displayed when wireless zone is enabled, but serial number of the detector is not entered. Phrase only LR will be
Detector status
displayed when the detector supports only the LR mode (firmware version < 2.000).
1 Entry doors Not activ.
2 Window LR
Living room No SN.
3
4 Kitchen only LR
Wireless detector can also be enrolled using Operation code. Enter wireless detector's
Z01 Door
press the [ENT] key. When enrolment has started, immediately press the detector's tamper switch for a short
Operation code N/A
4
period of time (~1 sec).
200
Temperature Magnet
(BT1) (BK1, BK4)
input terminal 1, 2 or 3.
response (speed) time of 0,4
2 1 0 sec.
NC type detector
(BK2, BK3, BK4)
102
Wireless output BS100. Important!
used for enrolling BS100 indicates the wireless PGM output number in the module.
EXT116S - address 06 (default) or one that is given during the registration process.
P16, S16xx - address 12;
P32 - address 12 and 13;
P64 - address 12, 13, 14 and 15.
Not used
NC - uses normally closed contacts and no end of line resistor;
NO - uses normally open contacts and no end of line resistor;
NC/EOL - uses normally closed (NC) contacts in a zone terminated by a 1k end of line resistor;
NO/EOL - uses normally open (NO) contacts in a zone terminated by a 1k end of line resistor;
NC/DEOL - uses normally closed (NC) contacts in a zone using at least two 1k end of line resistors to
NO/DEOL - uses normally open (NO) contacts in a zone using at least two 1k end of line resistors to
Vibration - special purpose zone loop type;
Roller - special purpose zone loop type (exluding PAS808M);
Wireless
control panel P16, P32, P64 – v.5.00;
wireless zone expansion module EXT116S – v.5.000;
keypads KM24, KM24A or KM24G – v.5.000;
keypads KM25 – v.5.000;
software MASCAD – v.1.9403;
GSM/GPRS communicator GSVU or GSV6U – v.5.000;
LAN communicator LAN800 – v.5.00.
1 step. Enter detector serial number. The keypad will identify the detector's type and will show all other
related settings that are required for enrolment.
2 step. SERVICE MODE DOES NOT HAVE TO BE ENTERED AT THIS STEP! To complete enrolment,
the detector must be activated to send a signal to the receiver. It could be done by triggering the detector's
loop (zone) OR by pressing the tamper switch. All wireless
not enrolled, are marked with a phrase
}Technical information }Wireless communication
201 010
Water leakage Motion
detector (BF1) (BP2)
Zone
103 104
the LAST digit of the Operation code which
Systems with KM24x, KM25 keypads
detector
Not activ. in menu Wireless communication.
181 180
Temperature Delete single
detector
(BP2)
Input terminal (1, 2, 3).
2 1 1
Last digit defines the number of Roller
pulses (1, 2, 3, 4, 5, 7, 9).
105
was
Programming manual
zones that are still not activated, therefore
O peration code and
255 254
Delete all detectors
from module
