Intruder alarm system
DEFAULT ADDRESSES OF THE MODULES
System manufacturer has provided the modules with default addresses assigned to them. This is done in order to simplify the process of
registration for most frequently used combinations of the system modules (such as PAS808M, KM20B, GSV6U or PAS816, KM24A,
EXM800, EXT116S, GSV6U). While registering modules of a different type, you will not need to enter serial numbers of each module, as
the system will automatically assign default addresses for the modules that are listed below:
For all control panels
For the keypad KM20B, KM24, KM25
For the keypad with a temperature sensor
For extra power supply module
For the zone/PGM expansion module
For the remote control module
For the proximity reader PROX8
For the GSM/GPRS /LTE Cat-M1 communicators
GSV0c, GSV0e, GSV1eT, GSV1eJ
For the LAN/WiFi communicators LAN800, WL800

ENTERING SERVICE MODE

It is recommended to use the computer and software MASCAD for the installations with few partitions and more than 10 zones. For simple
installations it is more efficient to change the template manually by using the LCD keypad. Changes should be made in service mode when
the system is disarmed.
For security reasons permission to access the service mode has to be enabled by entering user's PIN (default PIN codes: first user -
0001,service - 0000). There are 2 ways to enter the service mode:
by navigating the menu:
Main Menu
1 Settings
Test
2
3 Event Log
4 Controls
Service Mode
5
by using the F-key:
F-key
F33
Service Mode
Press arrows to navigate
There is an option to set the system without entering the required user's PIN that is needed to access the service
mode. To do this, you will need to modify the template by using software MASCAD:
1. Connect the keypad to your computer using a USB cable.
2. Establish a connection with the computer. Using the keys with arrows go to the menu: Service Mode } Project
Loading }Start connection with PC.
3. Download data from the keypad to software MASCAD (use the tab Project data sending/receiving).
4. Go to F-key tab.
5. Click on row F33 SERVICE Mode and uncheck the box User PIN required from the settings (see Fig. 2).
6. Upload the customized project back to the keypad (use the tab Project data sending/receiving).
MANUAL REGISTRATION OF MODULES
Control panels S16cmR, S16emR, S16cm, S16em, S16cT, S16 eJ (further S16xx) supports up to 3 external
modules, control panel PAS808M supports up to 7 modules and control panels PAS816, PAS832, P16, P32, P64
supports up to 15 modules (
modules with the same default addresses in the system (for example: several EXM800 or GSV6U and LAN800
modules), only the module with a greater serial number will be registered during the module registration procedure.
All remaining modules (not registered) must be registered manually.
To register the module, an installer must enter the service mode, type in a 10 digit serial number, which is on the
module's label (see Fig. 3), then press the [ENT] key to jump to second row, enter module address of the system, and
press [ENT] again to start registration.
Service Mode } System setup } Modules } Manual registration
Service Mode
System Setup
1
2 Report Settings
Project Loading
3
4 Set Language
5 Unregister Modules
Programming Wizard
6
The module will start to flash its address with the green LED after a correct serial number and address is entered. If a mistake was made
while entering serial number, the module will stay unregistered. If a mistake was made while entering the address which is used by another
module, then the new module will overtake this address and the other module will stay unregistered.
Note: a registered module will slowly flash its address on a green LED, which is located on the module's PCB (excluding keypads and a
control panel).
Page 2
KM24A, KM24G
PWR20
EXM800
EXT016 EXT116S, EXT216 ,
GSV6U, GSVU, GSV0q,
Enable
Service
Enter User PIN
Enable
Service
Enter User PIN
incl. enabled virtual modules EXT116VM on P series control panels
System Setup Modules
Modules
1 1
2 Partitions 2
Zones
3 3
4 PGM outputs
5 System Times
Security Settings
6
- address
- address
- address
- address
- address
- address
- address
- address
- address
Service
Mode
Enter service PIN
Service
Mode
Enter service PIN
Module settings
Automatic registration
Manual registration
Serial No. 3221226046
Address
Systems with KM24x, KM25 keypads
00 ;
01 or 03 ;
02 or 04 ;
04 or none;
05 ;
06 ;
06 ;
07 or 11 (for GSVU) ;
07.
Entering
Service
Entering
Service
Fig. 2 Tab F - keys
). If there are a few
Fig. 3 EXM800 label
Manual
registration Registering
5
Programming manual
