Intruder alarm system
By default, the LAN module is set to obtain IP automatically, which should be kept only if your ISP supports
LAN settings
DHCP or you are connecting through a dynamic IP address. If you are required to use a permanent IP address to
4 Obtain IP automatic. Yes
connect to the Internet, select No. In this case all IP settings must be manually entered.
Obtain DNS automatic. Yes
5
LAN settings
Obtain IP automatic. No
4
other hosts on remote networks.
IP address 192.168.0.248
Subnet mask 255.255.255.0
Gateway 192.168.0.254
(www.alarmserver.net) and the LAN module will automatically find that IP address on the internet.
DNS server 1 8.8.8.8
DNS server 2 4.4.4.4
PERIODIC TEST SETTINGS
The Periodic Test Settings menu contains parameters that enable the routing of a periodic test event to CMS receivers.
Service Mode }Report settings }Periodic test settings
Set the test time and hourly/daily interval for periodic test reporting.
Periodic Test Settings
1 Period in days x
2 Period in hours 1
periodic test reports to be sent. Use the list below to specify the daily testing intervals:
Report time (hh:mm) 01:00
3
Periodic Test Settings
1 Period in days 1
Period in hours x
2
3 Report time (hh:mm) xx:15
interval and the minute at the hour for periodic test reports to be sent. Disable the periodic reporting by setting
the Period in hours to 0.
SYSTEM TIMES SETTINGS
The System times settings menu contains parameters that specify the duration of an action.
Service Mode }System Setup }System times
The programmed exit delay will be applied for all enabled partitions.
System Times
1 Exit Delay 30 sec
The buzzer (or loudspeaker) housed inside the keypad emits (annunciates) sounds in case of alarm. The
System Times
duration of alarm sound is programmable within a 1 - 255 seconds range.
2 KM24 Alarm Time 180 sec
Used for all partitions. An audible Auto Arm Delay (warning) countdown will commence prior the automatic
System Times
arming. User, that has right to stop auto arming, can enter a valid PIN code at any time during the countdown to
Auto Arm Delay 30 sec
3
stop auto arming.
This time is related to special arming mode Pre-alarm. When a pre-alarm zone is violated, the system will trigger
System Times
the siren and a keypad buzzer (loudspeaker). The duration of pre-alarm is programmable within a 1 - 255
4 Pre-Alarm Time 10 sec
seconds range.
In case of AC power loss, this parameter specifies the delay period before reporting the event.
System Times
AC Loss Rep. Delay 10 min
5
Implemented on detection of smoke or fire for verification. When smoke of fire zone is violated, the system will
System Times
reset all smoke or fire detectors, then wait for detectors to settle. Detector's settling time is programmable within
6 Detector Settle Time 5 sec
a 1 - 255 seconds range.
Implemented on detection of smoke or fire for verification. When smoke or fire zone is violated, the system will
System Times
reset these detectors, then wait for detectors to settle. If a subsequent detection occurs in the same zone within
7 Fire Verific. Time 15 sec
the time that is programmed in Fire Verification Time, the system will emit a fire alarm.
Event reports from entry zones to the CMS are delayed for 30 seconds after they are detected. Select Yes if the
System Times
event report should be sent immediately.
Immediate entry alrm Yes
8

SECURITY SETTINGS

Service Mode }System Setup }Security Settings
Used for the [ ] key. If selected, then the keypad will skip the PIN entering procedure and will automatically enter
Security Settings
the 1st user's PIN.
1 Arm with PIN Yes
Used for the [ ] key. If selected, then the keypad will skip the PIN entering procedure and will automatically enter
Security Settings
the 1st user's PIN.
Pre-Alarm with PIN Yes
2
Page 10
IP address - enter IP address of the module in the network.
Subnet mask - enter a mask of the subnet in which the module works.
Gateway - the default gateway provides a default route for TCP/IP hosts to use when communicating with
DNS server 1 & 2 - DNS technology allows you to type names into receivers No.1 or No.2 address fields
Daily reporting - use the keypad's numeric keys [0] to [9] to type in the time of the day (in 24-hour format) for
0 - daily reporting is disabled
1 - Every day;
2 - Every other day;
...
30 Every 30th day;
31 Every 31th day.
Hourly reporting (except systems with PAS808M) - use the keypad's numeric keys [0] to [9] to type in the hour
Systems with KM24x, KM25 keypads
