Electrical connection

WARNING
- Disconnect the appliance from the mains power supply.
- Installation must be carried out by a qualified electrician who is fully aware of current safety
and installation regulations.
- The manufacturer declines all liability for injury to persons or animals and for damage to
property resulting from failure to observe the regulations provided in this chapter.
- The power supply cables must be long enough to allow the hob to be removed from the
worktop.
- Make sure the voltage specified on the appliance rating plate is the same as that of the
house electrical system.
- Do not use an extension cord.
Connecting to the terminal board
If the hob already has two power supply cables provided, follow the instructions in the bag attached to the
cable.
Connect the cables to the two terminal boards present on the bottom of the product.
IMPORTANT: for 400 V 3N~ connection only, use only one power supply cable (connecting it to the
terminal board of the main electronic module) in addition to the 3 x 1.5 mm
terminal board to that of the auxiliary electronic module. For electrical connection, see the instruction
attached to the 3 x 1.5 mm 2 wiring.
11
2 wiring to connect the main
