Fibreglass Media Filters
Installation and Operating
WARNING: Failure to follow these instructions and comply
with all applicable codes, may cause serious bodily injury
and/or property damage.
The installation of this product should be carried out by a person
knowledgeable in swimming pool plumbing requirements following
the installation instructions provided in this manual.
Please pass these instructions on to the owner of this equipment.
CrystalClear
Models: DCC2140, DCC2540,
DCC2550 & DCC2850
Instructions
®
Advertisement
Table of Contents
Related Manuals for Davey CrystalClear DCC2550
Summary of Contents for Davey CrystalClear DCC2550
- Page 1 CrystalClear ® Fibreglass Media Filters Models: DCC2140, DCC2540, DCC2550 & DCC2850 Installation and Operating Instructions WARNING: Failure to follow these instructions and comply with all applicable codes, may cause serious bodily injury and/or property damage. The installation of this product should be carried out by a person knowledgeable in swimming pool plumbing requirements following the installation instructions provided in this manual.
- Page 2 Your Davey Crystal Clear Media Filter Congratulations on your purchase of a quality product from the Davey Water Products range of Pool and Spa Equipment. You are assured of many years of reliable and efficient performance from your Davey Crystal Clear Media Filter backed by Davey’s Ten Year Tank Guarantee and Three Year Valve Guarantee.*...
- Page 3 8. Ensure the closure o-ring is clean and in the correct position. If necessary, apply a thin film of oring lubricant to the o-rings. Assemble the multiport valve to the tank aligning the ports to the appropriate plumbing. 9. Connect barrel unions utilising O-Rings supplied on fittings and screw into the multiport valve body.
- Page 4 Typical Installation *Vacuum Breaker Water Pump Media Filter One Way Valve * Vacuum breaker required if installation is greater than 3m above pool water line and is greater than12m in length. Commissioning Filter Refer to “operating instructions” below for safety warning and multiport valve control prior to the filter start-up.
- Page 5 Valve Position Function FILTER Normal filtration and vacuuming through filter. BACKWASH Clean the filter. RINSE Used on initial filter start-up and after backwash to prevent dirt in the sand returning to the pool. WASTE By-passes the filter; used for vacuuming to waste, or draining the pool.
- Page 6 1080 Filter Care The Davey media filter is the heart of the pool equipment installation. Proper care and maintenance will add many years of service and enjoyment to your pool. Keep the exterior of the filter clean, using a mild detergent and water.
- Page 7 NOTE: When making any enquiries about your Davey Filter, be certain to quote the Model Number from the nameplate on the equipment. To avoid explosion and possible severe or fatal injury, filter pressure must not exceed 280kPa.
- Page 8 To the fullest extent permitted by law or statute, Davey shall not be liable for any loss of profits or any consequential, indirect or special loss, damage or injury of any kind whatsoever arising directly or indirectly from Davey products. This limitation does not apply to any liability of Davey for failure to comply with a consumer guarantee applicable to your Davey product under local laws and does not affect any rights or remedies that may be available to you under local laws.
