Installation and Operating
Instructions for Microlene
Quick Connect
Underbench System
WARNING : Microlene underbench system installation must be in compliance with
all local legislative requirements, and installed by a licensed plumber.
Please pass these instructions on to the operator of this equipment.
Advertisement
Table of Contents
Related Manuals for Davey microlene
Summary of Contents for Davey microlene
- Page 1 Installation and Operating Instructions for Microlene Quick Connect Underbench System WARNING : Microlene underbench system installation must be in compliance with all local legislative requirements, and installed by a licensed plumber. Please pass these instructions on to the operator of this equipment.
- Page 2 KIT COMPONENTS Microlene Quick ® Connect Head with 6 x Screws Tap Spout 1 x Tubing Microlene ® 1 x Tap Purifier 2 x Push lock Fittings (female thread) 2 x Push lock Fittings 1 x Pressure C-Clamp Kit 1 x ½” Pipe Tap Kit...
- Page 3 ® with all local legislative requirements. Please note that C-Clamp kit may not be accepted in certain markets. INSTALLING YOUR MICROLENE® QUICK CONNECT UNDERBENCH SYSTEM Step One: INSTALLING THE TAP • Determine the most suitable location on your bench top for mounting the tap.
- Page 4 Step 3: CONNECTING THE PURIFIER • The Purifier has white packing tube inserted to protect it, remove the packing tube by holding down the round collet at each end of the purifier and pull out the tubing. Do not damage the collet or the internal fittings of the purifier as any damage may make them leak or blow out once water pressure enters the purifier.
- Page 5 To ensure the correct flow rate, place a bucket/container (one which you know what its capacity is) under the Microlene bench tap and turn the tap on. Time how long it takes to fill the bucket/container - adjust the outlet taps on the Pipe Tap (or C-Clamp) until a flow rate of no more than 4 litres per minute is achieved.
- Page 6 Notes...
- Page 8 0800 654 334 Member of the GUD Group Email: sales@davey.com.au Email: sales@dwp.co.nz ABN 18 066 327 517 Website: davey.com.au Website: daveynz.co.nz ® Davey is a registered trademark of Davey Water Products Pty Ltd. © Davey Water Products Pty Ltd 2017. P/N 402668-1...
