Testing; Check The Scoot Control For Intactness; Operational Test - Mo-vis coot Control R-net Installation Manual

Testing

After installation of the device, execute the following tests before the
wheelchair is delivered or put into service, in according order:
1 Check the Scoot Control for intactness on page 32
2 Operational test on page 32
3 Test drive on page 35
4 Stop test on page 35

Check the Scoot Control for intactness

Check whether:
1 The device is not bent or damaged.
2 Housing, cabling and all connectors are not damaged.
3 The handlebar and throttles return to their default position when
moving them respectively to the left and right and up and down.

Operational test

CAUTION:
metre of free space around the wheelchair.
32
Execute this test only on a level surface, with at least one
Scoot Control Installation manual
