NOTE: Fixation of the Scoot Control on the bracket with 4 screws
(supplied with the bracket): torque 5Nm.

Actuator Keypad

R-net version
You can connect an external Curtiss-Wright CJSM2 compatible Actuator
Keypad to the Scoot Control R-net (P015-61) to control the actuators of the
power chair.
See the Scoot Control User Manual or contact mo-vis for an overview of the
Scoot Control parts and accessories.
Please refer to the Curtiss-Wright manual SK77981-14 | R-net Technical
Manual for actuator settings and controls.
In the Scoot Control default settings, a key press will send an axis command
to the R-net system.
NUMBER
1
2
...
Scoot Control Installation manual
Axis 1 moves UP
Axis 1 moves DOWN
...
ACTION
