Parts list
4. APP 0.6 - 1.0 and APP 0.6 - 1.0 and
APM 0.8 - 1.2 APM 0.8 - 1.2
32
APP 0.6-38 / APM 0.8-2.9 / APPW 5.1-10.2
Note:
The parts listed are not sold separately, only in
various kits.
Parts for APM 0.8-1.2 are equivalent to the
parts for APP 0.6-1.0 except for valve plate sets.
Exploded view, see next page.
Pos. Qnt. Designation
1 1 Housing
2 1 Pin (Ø4x14)
61 1 Cylinder barrel
62 1 Spring
63 1 Spring guide
64 1 Retainer ball
65 1 Retainer plate
66 5 Piston
67 1 Key (5x5x20)
91 1 Port plate
92 1 Valve plate
93 5 Back-up ring
94 5 O-ring (Ø8.73x1.78)
121 1 Port flange
122 1 O-ring (Ø68x2)
123 1 O-ring (Ø40x2)
124 1 Shaft seal
125 1 Mounting flange
126 1 Pin (Ø4x9)
127 6 Screw M6x40
130 2 O-ring (Ø4.5x1.5)
152 1 Valve cone
153 1 Spring
154 1 Plug/guide
155 1 O-ring (Ø7.0x1.5)
1 Instruction
180R9262 / IOM APP 0.6-1.0 Appendices - v02 / 12.2012
Material
Duplex / PEEK
AISI 316
Super Duplex / PEEK
Duplex
PEEK
Super Duplex
Super Duplex
Super Duplex / PEEK
AISI 316
Super Duplex / PEEK
Super Duplex
PTFE
NBR
Duplex
NBR
NBR
AISI 316/NBR
Wetted part: PP
Dry parts: AISI 316
PEEK
AISI 316
NBR
PEEK
Duplex
Duplex
NBR
x
x
x
x
x
x
x
x x
x x
x x x
x x x
x
x
x
x
x
x
x
x
x
x
x x x x x
x
x
x
x
x
x
