Data sheet
Data sheet for
APP 0.6-1.0 pumps
(521B1136)
Table of Contents
1.
General information
4
APP 0.6-1.0
1.
General information
2.
Benefits
3.
Technical data
4.
5.
6.
7.
Temperature and corrosion
7.1
7.2
8.
9.
10.
10.1
Pump
10.2
11.
11.1
11.2
11.3
12.
12.1
12.2
12.3
APP 0.6, APP 0.8 and APP1.0 pumps are designed
to supply low viscosity and corrosive fluids under
high pressure, eg in seawater reverse osmosis
filtration applications and for high-pressure salt
water pumping.
The pumps are based on the axial piston
principle enabling a very light and compact
design. The design ensures that lubrication of
the moving parts in the pumps is provided by
the fluid itself. No oil lubrication is thus required.
All parts included in the pumps are designed to
provide long service life, ie long service life with
1: Shaft sealing
2: Mounting flange
3: Retaining ring
4: Piston/shoe
5: Valve plate
6: Swash plate
7: Cylinder barrel
8: Spring
9: Port plate
10: Connecting flange
11: Housing with bearing
12: Flushing valve
180R9262 / IOM APP 0.6-1.0 Appendices - v02 / 12.2012
a constantly high efficiency and minimum of
service required.
The pumps are fixed displacement pumps in
which the flow is proportional to the number of
revolutions of the input shaft and the pump
displacement, regardless of any counter-pres-
sure.
The pumps are supplied with an integrated
flushing valve that allows the salt water to flow
from inlet to the outlet, when the pump is not
running.
1
2
12
10
9
7
11
4
6
5
11
8
3
