User and Safety Manual
PLUS+1® JS1-H Steer by Wire
Steer by Wire Joystick
Environmental characteristics
10 |
©
Danfoss | December 2022
Joystick buttons
Buttons activation force
Buttons overload force
Joystick base
Lever deflection angle
Return to center tolerance
The system integrator must ensure an appropriate installation position.
JS1-H Steer by Wire must not be installed in environments where the ambient temperature exceeds 85°C.
In case of uncertainty, contact a Danfoss representative for further information.
EMC
Radiated EMI
Conducted EMI
Radiated EMS
Conducted EMS
Automotive transient pulses 1, 2a, 2b, 3a &
3b
Automotive starting profile
Automotive load dump protection
ESD Contact 8 kV, Air 15 kV
Temperature
Operating Temperature w/o force feedback function
Operating Temperature with force feedback function
Storage temperature
Environmental influences
Pressure
Chemical Resistance
Vibration Sinus Random
Vibration Shock
Humidity
5 N ±10%
100 N for 1000 activations
±30°, tolerance: ±3°
±1°
CISPR 25:2008, DIN EN 55025, class 3 (except GPS L1 & GLONASS L2 are
no compliance)
CISPR 25:2008, DIN EN 55025, class 4 (exception FM band: class 3)
ISO 11452-2:2004, 100 V/m
ISO 11452-4:2011, 200 mA
ISO 7637-2:2012
ISO 16750-2:2012 (Note: Us6=5.5V)
ISO 16750-2:2012 (12V system) (Only Force Feedback & Ext. Relay)
ISO 61000-4-2:2009 & ISO 10605:1994
Not applicable
ISO 16750-5:2010
ISO 16750-3:2012, 10 - 2000 Hz/21.3m/s^2 RMS
IEC 60068-2-27:2008, 30g/11ms
IP54
-20°C to +70°C
-20°C to +60°C
-40°C to +85°C
AX436683569858en-000101
