- Page 1 ASSEMBLY INSTRUCTIONS Description : MISSION ENTERTAINMENT STAND Item No. : TV-36 Printed in Vietnam ITEM NO.: TV-36 REVISED JAN 10, 2015 - 1 -...
-
Page 2: Before Assembly
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the finish of your product. Protect the surface of the product with cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED Printed in Vietnam ITEM NO.: TV-36 REVISED JAN 10, 2015 - 2 -... -
Page 3: Part List
SHELF BOTTOM SIDE FRAME SHELF (L&R) DRAWER BOTTOM BOTTOM SUPPORT PANEL RAIL DRAWER BACK FRONT PANEL (L&R) DRAWER DRAWER BACK SIDE PANEL PANEL (L&R) DRAWER - SUPPORT Printed in Vietnam ITEM NO.: TV-36 REVISED JAN 10, 2015 - 3 -... -
Page 4: Hardware List
(6.5x19mm) SPRING LONG SCREW WASHER (M4x30mm) (6.5x11mm) SHELF SHORT SCREW SUPPORT PIN (M3.5x15mm) CAMLOCK CAMBOLT PAN HEAD KNOB SCREW (M3.5x35mm) STEEL BAND Warning label ALLEN KEY (4x80mm) Printed in Vietnam ITEM NO.: TV-36 REVISED JAN 10, 2015 - 4 -... - Page 5 Attach the Cambolt (7) to the side frames (D) as shown below. Tighten with a screwdriver. STEP 2 Attach the support rail (F) to the side frames (D) with the camlock (8). Tighten with Allen key (13). Printed in Vietnam ITEM NO.: TV-36 REVISED JAN 10, 2015 - 5 -...
- Page 6 Attach the bottom self (C) to the side frames (D) with bolts (1), and washers (2) and (3). Tighten with Allen key (13). Attach the support rail (F) to the side frames (D) with the camlock (8). Tighten with Allen key (13). Printed in Vietnam ITEM NO.: TV-36 REVISED JAN 10, 2015 - 6 -...
- Page 7 Insert shelf support pins (6) into the side frames (D). Place the shelf (B) on the shelf support pin and attach with screws (5) as shown below. Tighten with a screwdriver. Printed in Vietnam ITEM NO.: TV-36 REVISED JAN 10, 2015 - 7 -...
- Page 8 Attach drawer sides (J) to the drawer front (H) with screws (4) as shown below. Tighten with a screwdriver. STEP 8 Slide the drawer bottom panel (E) into the grooves as shown below. Printed in Vietnam ITEM NO.: TV-36 REVISED JAN 10, 2015 - 8 -...
- Page 9 Attach the drawer back panel (I) to the drawer (from step 8) with screws (4) as shown below. Tighten with a screwdriver. STEP 10 Attach the drawer support bar (K) underneath the drawer with screws (4) as shown below. Tighten with a screwdriver. Printed in Vietnam ITEM NO.: TV-36 REVISED JAN 10, 2015 - 9 -...
- Page 10 Attach steel bands (11) to the unit with screws (5). Then attach the steel band to a wall with screw (4) as shown below (to secure the product and prevent tipping). Tighten with a screwdriver. Printed in Vietnam ITEM NO.: TV-36 REVISED JAN 10, 2015 - 10 -...
