- Page 1 ASSEMBLY INSTRUCTIONS Description : SIDE TABLE ACACIA Item No. : T-519 ITEM NO.: T-519 Printed in Vietnam REVISED SEP 20, 2016 - 1 -...
- Page 2 Sketch Description Sketch Long bolt Lock Washer (M6 x 50mm) (6.5 x11mm) Flat Washer Allen Key (6.5 x19mm) (M4 x 30mm x 120mm) Nail Somer’s Pointe (10mm) ITEM NO.: T-519 Printed in Vietnam REVISED SEP 20, 2016 - 2 -...
- Page 3 Attach legs (B) to the top (A) with bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (4). STEP 1 STEP 1 STEP 2 Attach Somer’s Pointe (5) to top frame (A) with nails (6) as shown below. ITEM NO.: T-519 Printed in Vietnam REVISED SEP 20, 2016 - 3 -...
