Black Cross Legged Chair with Wheels
Instruction Manual
SKU: CHAIR-CL01B
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/chair-cl01b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo CHAIR-CL01B
Summary of Contents for Vivo CHAIR-CL01B
- Page 1 Black Cross Legged Chair with Wheels Instruction Manual SKU: CHAIR-CL01B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/chair-cl01b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
- Page 3 STEP 2 Place Gas Spring (B) into Base (A) as shown below. STEP 3 Place Lower Support (C) onto Gas Spring (B) and secure using M8x22mm Screws (S-C) and 5mm Allen Wrench (T-A).
- Page 4 STEP 4 Secure Foot Pad (H) to Lower Support (C) using M6x20mm Screws (S-A) and 5mm Allen Wrench (T-A). STEP 5 Place Seat Pad (G) onto Gas Spring (B) with curved side facing Foot Pad (H).
- Page 5 STEP 6 Slide Back Rest Support (E) into bracket on underside of Seat Pad (G) and secure using M8x30mm Screws (S-D) and 5mm Allen Wrench (T-A). STEP 7 Attach Back Rest Bracket (I) to Back Rest Pad (F) using M6x16mm Screws (S-B) and 5mm Allen Wrench (T-A).
- Page 6 STEP 8 Adjust height of seat by pressing the button below Seat Pad (G).
- Page 7 THIS PAGE INTENTIONALLY LEFT BLANK...
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
