Summary of Contents for Teltonika FMB930
- Page 1 FMB930 Small and smart tracker Quick Manual v1.3...
-
Page 2: Table Of Contents
Quick SMS configuration ....................................10 Mounting recommendations..................................12 Basic characteristics ......................................13 LED indications ......................................... 13 Electrical characteristics ....................................16 Safety information ......................................17 Certification and Approvals .................................... 18 Warranty ........................................... 19 Warranty disclaimer ....................................... 19 Quick Manual v1.3 // FMB930 Telematics... -
Page 3: Know Your Device
KNOW YOUR DEVICE TOP VIEW BOTTOM VIEW (WITHOUT COVER) POWER NAVIGATE STATUS MICRO-USB CABLE BATTERY MICRO-SIM SOCKET SLOT Quick Manual v1.3 // FMB930 Telematics... -
Page 4: Pinout
DIN1 channel 1. DEDICATED DIN1 FOR IGNITION INPUT DOUT2 (Grey) Digital output. DOUT2 Open collector output. Max. 0,5 A DC DOUT1 (White) Digital output. DOUT1 Open collector output. Max. 0,5 A DC FMB930 pinout Quick Manual v1.3 // FMB930 Telematics... -
Page 5: Wiring Scheme
WIRING SCHEME IGNITION +10...90 V DC DETECTION ALARM BUTTON DOOR SENSOR DIN1 DOUT2 DOUT1 BUZZER POWER SUPPLY STARTER 10 - 90V DC Quick Manual v1.3 // FMB930 Telematics... -
Page 6: Set Up Your Device
Teltonika Configurator components. Make sure that Micro- SIM card cut-off corner is pointing forward to slot. Page 7, "PC Connection wiki.teltonika-gps.com/view/ 1 (Windows)" FMB930_Security_info wiki.teltonika-gps.com/view/ 2 Teltonika_Configurator Quick Manual v1.3 // FMB930 Telematics... -
Page 7: Pc Connection (Windows)
” • Using Bluetooth • FMB930 Bluetooth is enabled by default. Turn on Bluetooth on your PC, then select Add Bluetooth or other device > Bluetooth. Choose your device named – “FMB930_last_7_imei_digits”, without LE in the end. • Enter default password 5555, press Connect and then select Done. -
Page 8: Configuration
CONFIGURATION At first FMB930 device will have default factory settings set. These settings should be changed according to the users needs. Main configuration can be performed via Teltonika Configurator software. Get the latest Configurator version from here . Configurator operates on Microsoft Windows OS and uses prerequisite MS .NET Framework. Make sure you have the correct version installed. - Page 9 Most important configurator section is GPRS – where all your server and GPRS settings can be configured and Data Acquisition – where data acquiring parameters can be configured. More details about FMB930 configuration using Configurator can be found in our Wiki wiki.teltonika-gps.com/view/FMB930_Status_info wiki.teltonika-gps.com/view/FMB930_Status_info#GNSS_Info wiki.teltonika-gps.com/view/FMB930_Status_info#GSM_Info wiki.teltonika-gps.com/view/FMB930_Status_info#I.2FO_Info wiki.teltonika-gps.com/view/FMB930_Status_info#Maintenance...
-
Page 10: Quick Sms Configuration
2003 – APN password (if there are no APN password, empty field should be left) SERVER SETTINGS: 2004 – Domain 2005 – Port 2006 – Data sending protocol (0 – TCP, 1 – UDP) Quick Manual v1.3 // FMB930 Telematics... - Page 11 120 seconds is off After successful SMS configuration, FMB930 device will synchronize time and update records to configured server. Time intervals and default I/O elements can be changed by using Teltonika Configurator SMS parameters wiki.teltonika-gps.com/view/Teltonika_Configurator...
-
Page 12: Mounting Recommendations
If the wire is fixed with the bolt, the loop must be connected to the end of the wire. • For better contact scrub paint from the spot where loop is going to be connected. Quick Manual v1.3 // FMB930 Telematics... -
Page 13: Basic Characteristics
Blinking fast for a Modem activity short time GPRS Multi-Slot Class 12 (up to 240 Data transfer Device is not working or Device is in kbps), GPRS Mobile Station Class B boot mode Data support SMS (text/data) Quick Manual v1.3 // FMB930 Telematics... - Page 14 Micro-SIM -20 °C to +35 °C for 1 month Battery storage Memory 128MB internal flash memory temperature -20 °C to +35 °C for 6 months Features teltonika.lt/product/bluetooth-sensor 1 Sensors Accelerometer wiki.teltonika.lt/view/How_to_connect_OBD_II_Blue-tooth_Dongle_to_ 2 FMB_device Quick Manual v1.3 // FMB930 Telematics...
- Page 15 FOTA Web FOTA Teltonika Configuration and Configurator (USB, Bluetooth), wiki.teltonika-gps.com/view/How_to_connect_OBD_II_Bluetooth_ firmware update 10 FMBT mobile application Dongle_to_FMB_device (Configuration) Configuration, Events, DOUT Control, Debug wiki.teltonika-gps.com/view/FMB930_Features_settings 3 wiki.teltonika-gps.com/view/FMB930_Sleep_modes 4 wiki.teltonika-gps.com/view/FMB930_Sleep_modes#Power_off_sleep_ mode wiki.teltonika-gps.com/view/FOTA_WEB 6 wiki.teltonika-gps.com/view/FOTA wiki.teltonika-gps.com/view/Teltonika_Configurator wiki.teltonika-gps.com/view/FMBT_Mobile_application Quick Manual v1.3 // FMB930 Telematics...
-
Page 16: Electrical Characteristics
Drain current (Digital µA Output OFF) Drain current (Digital Output ON, Recommended Operating Conditions) Static Drain-Source resistance (Digital mΩ Output ON) Digital input Input resistance (DIN1) kOhm Input voltage (Recommended Operating Conditions) Input Voltage threshold Quick Manual v1.3 // FMB930 Telematics... -
Page 17: Safety Information
DO NOT touch the device before unplugging the powe supply. All wireless data transferring devices produce This message contains information on how to operate FMB930 interference that may affect other devices which are safely. By following these requirements and recommendations, placed nearby. -
Page 18: Certification And Approvals
Full User‘s Manual version can be found in mixed with general household waste. Wiki 1 wiki.teltonika-gps.com/view/FMB930 CHECK ALL CERTIFICATES All newest certificates may be found in our Wiki wiki.teltonika-gps.com/view/FMB930_Certification_%26_Approvals Quick Manual v1.3 // FMB930 Telematics... -
Page 19: Warranty
WARRANTY TELTONIKA guarantees its products to be free of any manufacturing defects for a period of 24 months. With additional agreement we can agree on a different warranty period, for more detailed information please contact our sales manager. Contact us teltonika-gps.com/about-us/contacts All batteries carry a reduced 6 month warranty period.
