- Page 1 KERN & Sohn GmbH Ziegelei 1 Phone: +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 email: info@kern-sohn.com Internet: www.kern-sohn.com Operating instructions Platform/floor scales KERN EOB / EOE_L / EOE_XL / EOS Version 3.1 04/2015 EOB/EOE_L/EOE_XL/EOS-BA-e-1531...
-
Page 2: Table Of Contents
KERN EOB / EOE_L / EOE_XL / EOS Version 3.1 04/2015 Operating instructions Platform/floor scales Table of Contents Technical Specifications ................4 Appliance overview ..................10 Overview of displays ....................12 Keyboard overview ....................12 Basic Information (General) ................ 13 Proper use .......................13 Improper Use ......................13... - Page 3 Adjustment ....................18 Operation ...................... 19 Start-up ..........................19 Switching Off ........................19 Weighing ..........................19 Switch-over weighing unit ....................19 Taring ..........................20 Hold function (animal weighing function) ................21 Plus/minus weighing ......................22 Menu ......................23 Service, maintenance, disposal ..............24 10.1 Cleaning ........................24 10.2 Service, maintenance .....................24 10.3 Disposal........................24...
-
Page 4: Technical Specifications
1 Technical Specifications Models KERN EOB KERN 15K5 35K10 60K20 60K20L Readability (d) 10 g 20 g 20 g Weighing range (max) 15 kg 35 kg 60 kg 60 kg Reproducibility 10 g 20 g 20 g Linearity ±10 g ±20 g... - Page 5 KERN 150K50 150K50L 150K50XL Readability (d) 50 g 50 g 50 g Weighing range (max) 150 kg 150 kg 150 kg Reproducibility 50 g 50 g 50 g Linearity ±100 g ±100 g ±100 g Recommended 100 kg 100 kg...
- Page 6 KERN 300K100A 300K100L 300K100XL Readability (d) 100 g 100 g 100 g Weighing range (max) 300 kg 300 kg 300 kg Reproducibility 100 g 100 g 100 g Linearity ±200 g ±200 g ±200 g Recommended 200 kg 200 kg...
- Page 7 Models KERN EOE KERN 15K10 35K20 60K50 150K100 Readability (d) 10 g 20 g 50 g 100 g Weighing range (max) 15 kg 35 kg 60 kg 150 kg Reproducibility 10 g 20 g 50 g 100 g Linearity ± 20 g ±...
- Page 8 KERN 150K50L 150K50XL 300K100L 300K100XL Readability (d) 50 g 50 g 100 g 100 g Weighing range (max) 150 kg 150 kg 300 kg 300 kg Reproducibility 50 g 50 g 100 g 100 g Linearity ±100 g ±100 g ±200 g...
- Page 9 Models KERN EOS KERN 150K50XL 300K100XL Readability (d) 50 g 100 g Weighing range (max) 150 kg 300 kg Reproducibility 50 g 100 g Linearity ±100 g ±200 g Recommended 100 kg 200 kg adjustment weight, not (M2) (M2) added (class) Stabilization time (typical) 2.5 sec.
-
Page 10: Appliance Overview
2 Appliance overview Models EOB Weighing plate, stainless steel Models EOE Weighing plate varnished steel EOB/EOE_L/EOE_XL/EOS-BA-e-1531... - Page 11 Models EOS • Weighing plate, stainless steel • Anti-slip rubber mat Comfortable transport due to 2 rollers and 1 grab handle EOB/EOE_L/EOE_XL/EOS-BA-e-1531...
-
Page 12: Overview Of Displays
2.1 Overview of displays Description Is displayed, when the battery capacity is exhausted. Balance zero display: Should the balance not display exactly zero despite empty scale pan, press the TARE button. The balance will be set to zero after a short standby time. -
Page 13: Basic Information (General)
The balance may only be used according to the described conditions. Other areas of use must be released by KERN in writing. 3.3 Warranty Warranty claims shall be voided in case •... -
Page 14: Monitoring Of Test Resources
In KERN’s accredited DKD calibration laboratory test weights and balances may be calibrated (return to the national standard) fast and at moderate cost. 4 Basic Safety Precautions 4.1 Pay attention to the instructions in the Operation Manual... -
Page 15: Unpacking, Setup And Commissioning
6 Unpacking, Setup and Commissioning 6.1 Installation Site, Location of Use The balances are designed in a way that reliable weighing results are achieved in common conditions of use. You will work accurately and fast, if you select the right location for your balance. Therefore, observe the following for the installation site: •... -
Page 16: Scope Of Delivery / Serial Accessories
6.2.1 Scope of delivery / serial accessories • Platform and display unit, (see chap. 2) • 4 x adjustment feet (excepted platform size 314.5 x 304.5 cm) • Mains power supply • Wall fixture (with fixing screws) • Operating instructions 6.2.2 Assembly instructions for the use of the wall fixture EOB/EOE_L/EOE_XL/EOS-BA-e-1531... -
Page 17: Mains Connection
6.3 Mains connection Power is supplied via the external mains adapter. The stated voltage value must be the same as the local voltage. Only use original KERN mains adapters. Using other makes requires consent by KERN. 6.4 Battery operation On the rear side of the display unit remove the battery cover and connect 6 x 1.5V mignon cells. -
Page 18: Adjustment
7 Adjustment As the acceleration value due to gravity is not the same at every location on earth, each balance must be coordinated - in compliance with the underlying physical weighing principle - to the existing acceleration due to gravity at its place of location (only if the balance has not already been adjusted to the location in the factory). -
Page 19: Operation
8 Operation Press the ON/OFF key. Start-up The balance will carry out a self-test. The balance is ready for weighing when the weight display appears. Should the balance not display exactly zero despite empty weighing plate, press the TARE button. The balance will be set to zero after a short standby time. -
Page 20: Taring
Place an empty weighing container, the weight of the Taring weighing container will be displayed. Press the TARE button, the zero display disappears. The indicator [] under [NET] is displayed. The tare weight is saved until it is deleted. ... -
Page 21: Hold Function (Animal Weighing Function)
The balance has an integrated animal weighing function (mean Hold function value calculation). Using this function it is possible to weigh (animal weighing domestic or small animals exactly (min. load 1% of the max. function) one), although they do not stand quiet on the weighing plate. ... -
Page 22: Plus/Minus Weighing
For example for item weight check, production check etc. Plus/minus weighing switch-on the balance using ON/OFF button and wait for zero display. Put the nominal weight on the weighing plate and tare to zero using TARE key. Remove the nominal weight. ... -
Page 23: Menu
9 Menu Changes are only allowed on the functions (weighing units) and (automatic switch-off function). In weighing mode keep TARE button depressed for approx. 3 sec until "SETUP" is displayed followed by "UNIT" Press the HOLD button as often as necessary until the required function is displayed. -
Page 24: Service, Maintenance, Disposal
Remove spilled weighing goods immediately. 10.2 Service, maintenance The appliance may only be opened by trained service technicians who are authorized by KERN. Before opening, disconnect from power supply. 10.3 Disposal Disposal of packaging and appliance must be carried out by operator according to valid national or regional law of the location where the appliance is used. - Page 25 In case of an error in the program process, briefly turn off the balance and disconnect from power supply. The weighing process must then be restarted from the beginning. Help: Fault Possible cause • The balance is not switched on. The displayed weight does not glow.
- Page 26 310 x 305 mm...
- Page 27 550 x 550 mm...
- Page 28 945 x 505 mm...
