Hollyland Solidcom C1 Pro Hub User Manual page 7

Operation Guide
2.2 Select Slave Device and then select Scan to scan the IP addresses of
master devices on the network. Select the IP address of the corresponding
master device in the displayed list and confirm it. Then, the hub is success-
fully set as the slave device.
• When a single hub is used, the hub needs to be set as the master
device.
• When more than two hubs are used in a cascaded connection, one
hub needs to be set as the master device and the other hubs as the
slave devices.
3. Select Group to perform group settings and view group status.
3.1 There are three options: Group A (All devices are in group A), Group A/B
(All devices are in groups A and B), and Custom (The group settings can
be customized on the web. All devices are in group A by default).
Master-Slave Device
Master 1 IP: 192.168.218.011
Master 2 IP: 192.168.218.012
Master 3 IP: 192.168.218.013
Master 4 IP: 192.168.218.014
Master 5 IP: 192.168.218.015
Group Presets
Group A
Group A/B
Custom
8
