Hollyland Solidcom C1 Pro Quick Manual
Roaming hub
Hide thumbs
Also See for Solidcom C1 Pro:
- User manual (144 pages) ,
- Manual (24 pages) ,
- Quick manual (12 pages)
Advertisement
Quick Links
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hollyland Solidcom C1 Pro
Summary of Contents for Hollyland Solidcom C1 Pro
- Page 1 Solidcom C1 Pro - Roaming Hub Quick Guide V1.0...
- Page 2 Foreword Thank you for choosing the Solidcom C1 Pro - Roaming Hub to facilitate your on-site communication. This Quick Guide will show you how to get started with the product.
-
Page 3: Product Overview
Product Overview ⑩ ⑨ ⑨ ⑧ ⑦ ① ② ③ ④ ⑤ ⑥ ① Bluetooth Indicator ⑦ Menu/Confirm Button ② IP Indicator (Long press to enter menu; ③ Display Screen press to confirm) ④ Left Button ⑧ Up Button ⑤ Down Button ⑨... - Page 4 Product Overview ⑪ ⑫ ⑬ ⑭ ⑯ ⑰ ⑱ ⑲ ⑮ ⑳ ⑪ RJ45 Port 1 ⑯ USB-A Port (for headset pairing) ⑫ RJ45 Port 2 ⑰ USB-C Port (for UAC audio) ⑬ 3/8" Threaded Hole ⑱ DC Input ⑭ 5/8" Mount Hole ⑲...
- Page 5 Pinout Introduction RJ45 1/2 Pinout RJ45 Standard Pinout PIN1 Transceive Data+ PIN5 Not connected PIN2 Transceive Data- PIN6 Receive Data- PIN3 Receive Data+ PIN7 Not connected PIN4 Not connected PIN8 Not connected RJ45 3 Pinout 4 WIRE Standard Pinout Crossover Pinout PIN1 PIN5...
-
Page 6: Home Page Introduction
Home Page Introduction ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ① Hub ID ② Hub Name ③ Hub Connection Status (PC connection/IP connection) ④ Bluetooth Status (white: on; gray: off) ⑤ Power Voltage and Battery Level ⑥... -
Page 7: Product Installation
Product Installation 1. Install the antennas as shown in the diagram. 2. Install the battery or connect the power adapter. - Page 8 Product Installation 3. Mount the Hub on the tripod and secure it. ① ②...
-
Page 9: Product Connection
Product Connection Single Hub Connection Condition One For headsets in the Solidcom C1 Pro - Roaming Hub package, since the Hub and headsets have already been paired at the factory, they can be used immediately after power-on. - Page 10 Product Connection Condition Two For previously purchased Solidcom C1 and Solidcom C1 Pro headsets, the Hub and headsets need to be manually paired before use. The pairing procedures are as follows. 1. Power on the Hub and headset, and then use a USB-A to USB-C cable to connect them.
- Page 11 Product Connection 3. After the upgrade is complete, a pop-up window appears on the Hub, prompting you to assign a number to the pairing headset. Numbers in yellow are in use and hence not selectable, while numbers in gray are selectable. Select an appropriate number and choose Confirm to complete the pairing process.
- Page 12 Product Connection Dual Hub Cascade Connection To ensure that headsets maintain connection across the signal areas of two cascaded Hubs connected via an RJ45 Port, strictly follow the steps below for a reliable cascade connection. 1. Before cascading the Hubs, power on all headsets and Hubs to be used. Ensure that all headsets remain powered on until the cascade connection is successfully established.
- Page 13 Product Connection 2. When all headset indicators stop flashing and display a steady light, it indicates that the headsets have successfully connected to the respective Hub. Then, you can connect the Hubs using an Ethernet cable as shown in the diagram. Note: Ensure that all headsets are powered on and connected to the corresponding Hub before cascading the Hubs.
-
Page 14: Operation
Operation Group Configuration on Hub The Hub supports 6-group talking and role assignment. You can assign a specific type of role to each headset and configure the parameters for each type through the Hub, webpage, or app, thus obviating the need to manually configure each headset’ s parameters. - Page 15 Operation 3. The Hub supports a total of 10 preset roles: Production (head/member), Cam A (cameraman group A head/member), Cam B (cameraman group B head/member), Lighting (head/member), Grip (equipment team head/member). Each role’s group and corresponding button (A/B) are in the table below. Role Group 1 Group 2...
- Page 16 Operation Hub Configuration on App 1. Download the Solidcom app. 2. Turn on your phone’s Bluetooth, search for the device beginning with HLD, and click it to connect. 3. Launch the Solidcom app, wait for the software to fully load, tap Connect and then begin to configure the Hub.
- Page 17 Operation Hub Upgrade Note: You can obtain the firmware upgrade file from Hollyland’s official website or by contacting Hollyland online technical engineers. 1. Use a standard RJ45 Ethernet cable to connect the Hub to your computer. Ethernet Cable 2. Set your computer’s IPv4 information to be on the same subnet as the Hub, open the default browser, and enter the Hub’s IP address to navigate to the login page.
-
Page 18: Specifications
Specifications LOS Range 1,600ft (500m) 1904 - 1919 MHz: China 1880 – 1900 MHz: Europe, South Africa, much of Asia, Hong Kong SAR, Australia, and New Zealand (10 channels) 1880 – 1895 MHz: Taiwan (8 channels) Operating Frequency 1893 – 1906 MHz: Japan (J-DECT) 1910 –... -
Page 19: Safety Precautions
Safety Precautions Do not place the device near or inside heating devices (including but not limited to microwave ovens, induction cookers, electric ovens, electric heaters, pressure cookers, water heaters, and gas stoves) to prevent the battery from overheating and exploding. Use the original charger, data cables, and batteries provided with the product. - Page 20 All copyrights belong to Shenzhen Hollyland Technology Co., Ltd. Trademark Statement Without the written approval of Shenzhen Hollyland Technology Co., Ltd., no organization or individual may copy or reproduce part or all of any written or illustrative content and disseminate it in any form.
- Page 21 Shenzhen Hollyland Technology Co., Ltd. 8F, 5D Building, Skyworth Innovation Valley, Tangtou Road, Shiyan Street, Baoan District, Shenzhen, 518108, China MADE IN CHINA...
