Operation Guide
Master/Slave Mode Settings
After connecting two hubs using a network cable, select Master/Slave on the
hub to set the hub mode. On one hub, select Master Device . On the other
hub, select Slave Device > Scan and then select the IP address of the corre-
sponding master hub .
Note that the IP Address Automatic function under the Network settings
needs to be turned OFF on both two hubs.
Hub Display
Select Network and set IP Address
Hub ①
Automatic to OFF.
Wired Network Setting
ON
Network
OFF
Settings IP Address :
Subnet Mask:
Gateway:
User Name:
Password:
Select Network and set I P Address
Hub ②
Automatic to OFF .
Wired Network Setting
ON
Network
OFF
Settings
IP Address :
Subnet Mask:
Gateway:
User Name:
Password:
After Scan is selected, the IP ad-
dresses of master devices will be
displayed. Then, select the desired
IP address using the arrow buttons
and press the Menu/Confirmation
button to confirm the IP address.
192.168.218.10
Modify
255.255.255. 0
Modify
192.168.218. 1
Modify
admi n
12345678
192.168.218.10
Modify
255.255.255. 0
Modify
192.168.218. 1
Modify
admi n
12345678
18
Select Master/Slave > Master
Device.
Master And Slave
Master Device
Slave Device
Select Master/Slave > Slave
Device > Scan.
Master And Slave
Master Device
Slave Device
Master-Slave Device
Master 1 IP: 192.168.218.0
Master 2 IP: 192.168.218.01
Master 3 IP: 192.168.218.01
Master 4 IP: 192.168.218.01
Master 5 IP: 192.168.218.01
11
2
3
4
5
