Hollyland Solidcom C1 Pro Hub User Manual page 16

Operation Guide
4-Wire Settings
After connecting two hubs using a network cable, select 4 Wire > Line
Sequence Switching on the hubs, and then select Standard on one hub and
Cross on the other.
Hub Display
Select 4 Wire > Line Sequence
Hub ①
Switching .
4-Wire Settings
Select 4 Wire > Line Sequence
Hub ②
Switching.
4-Wire Settings
Two-System Cascaded Connection via the IP Network
Use a standard network cable to connect two hubs via the RJ45 interface.
Either of the two RJ45 interfaces on the hub works. The length of the network
cable is up to 300 meters.
4 Wire Setting
Input Gain
Output Gain
Line Sequence Switching
4 Wire Setting
Input Gain
Output Gain
Line Sequence Switching
Network cable of 300 meters
17
Select Standard.
Line Sequence Switching
34 56
Standard
IN+ OUT+ OUT- IN-
34 56
Cros s
OUT+ IN + IN- OUT-
Select Cross.
Line Sequence Switching
34 56
Standard
IN+ OUT+ OUT- IN-
34 56
Cros s
OUT+ IN + IN- OUT-
