DMX protocol

► 2-channel mode
Automatic mode, sound control, master dimmer
DMX channel DMX value
000 – 249
1
250 – 255
2 000 – 225
► 3-channel mode
Preset programs, sound control, master dimmer, speed
DMX channel DMX value
000 – 009
010 – 029
030 – 049
050 – 069
070 – 089
090 – 109
110 – 129
1
130 – 149
150 – 169
170 – 189
190 – 209
210 – 229
230 – 249
250 – 255
2 000 – 225
3 000 – 225
► 4-channel mode
Brightness
DMX channel DMX value
1 000 – 225
2 000 – 225
3 000 – 225
4 000 – 225
► 5-channel mode
Master dimmer, sound control, strobe control
DMX channel DMX value
1 000 – 225
000 – 000
001 – 005
2
006 – 010
011 – 225
3 000 – 225
4 000 – 225
5 000 – 225
Function
Automatic mode
Sound control
Dimming from 0 – 100%
Function
No function
Program 1
Program 2
Program 3
Program 4
Program 5
Program 6
Program 7
Program 8
Program 9
Program 10
Program 11
Program 0
Sound control
Dimming from 0 – 100%
Running speed slow → fast
Function
Spot 1 dimming from 0 – 100%
Spot 2 dimming from 0 – 100%
Spot 3 dimming from 0 – 100%
Spot 4 dimming from 0 – 100%
Function
Dimming from 0 – 100%
No function
Sound control
On
Strobe slow → fast
No function
No function
No function
