Setting up the Appliance

1. Remove the Quantum Spark 1535 / 1555Appliance from the shipping carton and place it on a
tabletop.
2. Optional: Remove the transparent protective sticker from the front panel of the appliance.
3. Attach antennas to the model (WiFi model only).
4. Identify the network interface marked as LAN1. This interface is preconfigured with the IP address
192.168.1.1.

Wall Mounting

To mount the appliance to the wall:
1. Place the wall-mount sticker on the wall and drill two holes for the screws.
2. Insert the 2 screw anchors in the wall.
3. Attach the 2 screws in the accessory kit (M4*6) to the wall.
4. Mount the appliance and verify the 2 screws are fastened well to the appliance.
Key Item
1 Holes on the bottom of the appliance
Description
Attach screws here
Quantum Spark 1535 / 1555 Appliance Getting Started Guide | 8
