Instruction Manual
Operation
This section describes the main functions provided by USBVGADOCK:
USB to Ethernet
USBVGADOCK supports the 10/100Mbps LAN transfer capability, and
is compliant with IEEE specifications 802.3u 100BASE-TX and 802.3
10BASE-T.
USB to Audio
USBVGADOCK provides one microphone input and one stereo speaker
output.
USB to VGA
USBVGADOCK supports three distinct display modes: Primary, Extended
and Mirror.
To configure how the VGA monitor connected to USBVGADOCK is used,
right-click on the UVD logo, situated in the task bar (typically near the
clock).
Click on Resolution
to change the display resolution
of the monitor connected to the
USBVGADOCK unit
Click on
High Resolution
to activate more
display options
8
