Instruction Manual
Universal Laptop USB Docking Station with
VGA Audio Ethernet
USBVGADOCK2
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 03/10/2011
Advertisement
Table of Contents
Related Manuals for StarTech.com USBVGADOCK2
Summary of Contents for StarTech.com USBVGADOCK2
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 03/10/2011...
- Page 2 Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges...
-
Page 3: Table Of Contents
Table of Contents Introduction ................................1 Packaging Contents ..........................1 System Requirements ..........................1 Rear View ................................2 Side Views ..............................2 Installation................................3 Driver Installation ............................3 Verifying Installation ..........................4 Configuring the USB Video Adapter ....................5 Display ID ...............................5 Display Resolution ............................5 Display Rotation ............................6 Display Modes .............................6 Identify Monitors ............................7 Multi-Display Control Panel ........................7 Display Settings ............................7... -
Page 4: Introduction
10/100Mbps RJ45 network port, dual (3.5mm mini-jack) audio ports and four additional USB 2.0 ports. Packaging Contents • 1 x USBVGADOCK2 docking station • 1 x Driver Installation CD • 1 x Universal Power Adapter • 3 x Interchangable Power Adapter Plug (NA/GB/EU) • 1 x Instruction Manual... -
Page 5: Rear View
Rear View RJ45 Ethernet DC Power USB 2.0 connector connector connector USB Link LED VGA connector Side Views 3.5mm mini-jack Audio (Mic/Speaker) USB mini-B connector (Host) Instruction Manual... -
Page 6: Installation
Installation * Please ensure that the driver installation is complete prior to the physical installation of the USB 2.0 to VGA Docking Station Driver Installation 1. Insert the Driver CD into your CD/DVD-ROM drive. 2. If the installation program does not begin automatically, locate the Setup.exe application. This file will be located in the root directory of the Driver CD. - Page 7 8. A Hardware Installation Wizard dialog will show up, please select “No, not this time” and click “Next” to continue. 9. Please select “Install the software automatically (Recommended)”. And click ”Next” to continue. 10. Click “Finish” to complete the Hardware Wizard.
-
Page 8: Verifying Installation
Verifying Installation From the main desktop, right-click on “My Computer” (“Computer” in Vista), then select Manage. In the new Computer Management window, select Device Manager from the left window panel. In the Device Manager view, ensure that the indicated devices are present. * actual device names may vary Instruction Manual... -
Page 9: Configuring The Usb Video Adapter
Configuring the USB Video Adapter Look for the USB Video Adapter icon ( ) on your Windows Start bar. Right-click this icon to access the variety of functions associated to the adapter. NOTE: The Aero desktop theme is not supported by this adapter, so should be disabled prior to use of the USB Video Adapter. -
Page 10: Display Modes
Display Modes “EXTENDED” DISPLAY MODE (DEFAULT) A default display mode; this feature allows the attached USB Video Adapter enabled display to work as an “Extended” display to the on-board display. The extended working space improves work efficiency. You may change the relative position of this extended display through the Display Settings. -
Page 11: Identify Monitors
Identify Monitors Easy display identification via an overlay will be shown in the upper right corner of all attached display devices. Multi-Display Control Panel A unique feature to allow quicker and simpler management of a multi-display environment. A series of hotkeys to quickly move the active window or mouse cursor to the desired display (either on-board or each USB Video Adapter). -
Page 12: Supported Video Resolutions
Supported Video Resolutions Resolution Color Depth Refresh Rate 800x600 16/32-bit 60/75Hz 1024x768 16/32-bit 60/75Hz 1152x864 16/32-bit 60Hz 1280x768 16/32-bit 60Hz 1280x800 16/32-bit 60Hz 1280x960 16/32-bit 60Hz 1280x1024 16/32-bit 60Hz 1400x1050 16/32-bit 60Hz 1440x900 16/32-bit 60Hz 1680x1050 16/32-bit 60Hz 1600x1200 16/32-bit 60Hz Instruction Manual... -
Page 13: Specifications
Specifications Bus Interface USB 2.0 Video Signal VGA (RGBHV) LAN: SMSC LAN9500 Chipset ID Video: Trigger UV-185CB-128 1 x USB type mini-B 1 x DE-15 VGA female Connectors 4 x USB type A 1 x RJ45 2 x 3.5mm mini-jack audio Maximum Video Resolution 1600x1200@32-bit LAN Link Speed... -
Page 14: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, conse- quential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 15 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
