> Provides greater flexibility for using your notebook as a desktop
Specifications
> Color White
> Product Height 0.75 in [19.1 mm]
> Product Length 7.99 in [203 mm]
> Number of Ports 4
> Power Adapter Included Yes
> Power Adapter - Amperage 3
> Power Adapter - DC Voltage 5
> Center Tip Polarity Positive
> Carton Quantity 20
> Shipping (Package) Weight 1.55 lb [0.7 kg]
> Product Width 2.75 in [69.8 mm]
> LAN Speed 10/100
> USB Transfer Rate USB 2.0, supports up to 480 Mbps
> Maximum Resolution 1600x1200 @ 32 bits and 1920 x 1200 @ 16 bits
> OS Support Windows 2000, XP, and Vista
> Connector Types 4 - USB A Female
> Connector Types 1 - USB Mini B 5 pin Female
> Connector Types 1 - DB15 High Density Female
> Connector Types 1 - RJ45 Female
> Connector Types 2 - Phono 3.5 mm Female
