- Page 1 MANUAL ENGLISH Floodlight HQ-150 A-symmetric V1 Ordercode: 30766 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Floodlight HQ-150 A-symmetric Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Connection with the mains ............................5 Return Procedure ................................5 Claims ....................................5 Description of the device ..............................6 Optional accessories ..............................6 Overview .................................. -
Page 3: Warning
Save the carton and all packing materials. In the event that the fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showtec Floodlight HQ-150 A-symmetric without power cable ● 1x bulb HQI-150 ●... - Page 4 ● If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 5: Operating Determinations
Floodlight HQ-150 A-symmetric Operating Determinations ● This device is not designed for permanent operation. Regular operation breaks will ensure that the device will serve you for a long time without defects. ● The minimum distance between light-output and the illuminated surface must be bigger than 0,5 meter. -
Page 6: Connection With The Mains
Floodlight HQ-150 A-symmetric Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power plug. Always check if the right color cable is connected to the right place. International EU Cable UK Cable... -
Page 7: Description Of The Device
Floodlight HQ-150 A-symmetric Description of the device Features The Showtec Floodlight HQ-150 is a A-symmetric floodlight with high output and great effects. ● Lamp: HQI ● Lamp socket: Rx7S ● Capacity: max 150W ● Type: A-Symmetric ● Input voltage: 230V, 50Hz ●... -
Page 8: Installation
Damages caused by non-observance are not subject to warranty. Installing the Lamp The Showtec Floodlight HQ-150 A-symmetric uses the HQI-150 (ordercode 81020) as manufactured by all popular manufacturers. Use only the appropriate lamp for your unit. Note that, product versions that use other lamps, may be offered in the future. Check your product specification label for information. -
Page 9: Set Up And Operation
Floodlight HQ-150 A-symmetric Fig. 04 Fig. 05 Fig. 06 Set Up and Operation Follow the directions below, as they pertain to your preferred operation mode. Before plugging the unit in, always make sure that the power supply matches the product specification voltage. -
Page 10: Maintenance
Floodlight HQ-150 A-symmetric Maintenance The operator has to make sure that safety-relating and machine-technical installations are to be inspected by an expert after every four years in the course of an acceptance test. The operator has to make sure that safety-relating and machine-technical installations are to be inspected by a skilled person once a year. -
Page 11: Troubleshooting
04) If you are unable to determine the cause of the problem, do not modify the Floodlight HQ-150, as this may damage the unit and the warranty will become void. 05) Return the device to your Showtec dealer. Problem Probable cause(s) -
Page 12: Product Specifications
Floodlight HQ-150 A-symmetric Product Specifications Model: Showtec Floodlight HQ-150 A-symmetric Input voltage: 230V, 50Hz Starting current: 1,5A max Capacity: max 150W Lamp socket: Rx7S Type: A-symmetric Color Temp.: 4200K Lumens @ 100Hr (lm): 11500 Housing: Die-cast aluminum Housing color: Black... -
Page 13: Dimensions
Floodlight HQ-150 A-symmetric Dimensions Ordercode: 30766... -
Page 14: Notes
Floodlight HQ-150 A-symmetric Notes Ordercode: 30766... - Page 15 Floodlight HQ-150 A-symmetric Ordercode: 30766...
- Page 16 ©2017 Showtec...
